Page 2
WARNING Read this operator’s guide thoroughly. It contains important safety information. Minimum recommended operator age: See your states laws regarding operator age and licensing requirements. Keep this operator’s guide with the vehicle at all times. The removal or modification of evaporative emission-related parts on this OHRV is illegal. Violators may be subject to civil and/or criminal penalties under California and federal law.
Page 3
WARNING YOUR VEHICLE CAN BE HAZARDOUS TO OPERATE. A roll-over can occur quickly even during routine maneuvers such as turning and driving on hills or over obstacles. For your safety, understand and follow all the warnings contained in this operator's guide and on the labels on the labels on your vehicle.
Page 4
2. All high voltage electrical connections are colored orange. Ensure that any orange cables or connectors are in good repair, free from debris, and fully connected. Contact your approved VANDERHALL dealer if you see any worn or damaged cables or connectors.
Page 5
The Vanderhall Brawley™ vehicle does NOT comply with Federal Motor Vehicle Safety Standards (FMVSS) and regulations of the United States Department of Transportation (DOT) applicable to passenger cars in the USA. Always wear a proper fitting DOT approved helmet when operating or riding in a Vanderhall Brawley™.
Introduction ..............8 Lighting ..............60 Safety Information.............21 Driving and Operation ..........65 Quick Overview ............26 Vehicle Care ..............76 Charging and Energy Consumption......39 Service and Maintenance ..........95 Customer Information ..........105 Seats and Restraints..........41 Instruments and Controls ......... 48...
Page 9
The features appearing within this WARNING including, but not limited to, Vanderhall™ manual may be subject to change. and Brawley™ are trademarks of Wireless updates to your Brawley™ Warning indicates a hazard that Vanderhall North America, LLC.
Page 10
Symbols Vehicle symbol Chart : Do Not Puncture Your Vanderhall Brawley™ has components and labels that : Do Not Service utilize symbols instead of text. Symbols are often shown with : Coolant Temperature text describing the operation or : Flame/Fire Prohibited...
Page 23
SAFETY INFORMATION WARNING Require Proper Use of Your Vehicle. Do your part to prevent injuries: 1. Do not allow careless or reckless driving. 2. Always wear and ensure all passengers wear a properly fitted DOT approved helmet when operating or riding. 3.
Page 24
Operating Ability Operators must be qualified and meet the age restrictions of the state in which the vehicle is operating in with a valid driver's license. The safe use of this vehicle depends on many conditions such as visibility, speed, weather, environment, traffic, vehicle condition and the condition of the operator.
Page 25
Off-Road Operation Off-road operation is dangerous. The terrain itself presents a constant element of danger, which must be knowingly accepted by anyone venturing over it. An operator should always exercise care in selecting the safest path and keeping a close watch on the terrain ahead of them. The vehicle should never be operated by anyone who is not completely familiar with the driving instructions applicable to the vehicle, nor should it be operated on steep or dangerous terrain.
Quick Overview 28-29 Door, Hood, Hatch and Operation Vehicle Features (cont.) Stereo Bluetooth Audio Unlocking the vehicle Cruise Control USB Outlets Frunk 31-32 Introduction to vehicle features Controlling Access Instrument Panel Introduction Parking Brake Quick Start Guide How to use the Mobile App 39-40 Charging Opening the Charge Port...
Page 28
Operating the Doors Operating the Hood CAUTION To open the frunk: 1. Press the button located on the inner edge of the hood. Do not use door pull strap as leverage when exiting the vehicle. If you do, you will likely damage the mechanism. After the frunk pops, lift from the windshield side.
Page 29
Opening the Rear Hatch/Glass WARNING Make sure area around the opening of the glass is clear before closing. 1. To open the rear hatch/glass, press the button on the underside of the license plate overhang. 2. The glass will pop up enough to insert fingers under edge of glass.
Page 30
1. Hold the key card against the drivers side door below the window and above the door handle or press to unlock in the Vanderhall™ mobile app. 2. The vehicle will unlock after a valid key card or command from the app has been detected. The vehicle will not fully power on until it is unlocked.
Page 32
UPPER CONTROLS Heated Seats Auxiliary Windshield Wipers (Driver & Rear Left Seat) (Rear) Drive Mode Selector Heated Seats Light Bar Dome Lights (Passenger & Rear Right Seat) (top) (bottom) Traction Control Auxiliary (top) (Front) Windshield Washer Spray (bottom)
Page 33
To Use the Mobile App Quick Start Guide Starting the vehicle 1. Download the Vanderhall™ mobile app. If prompted, allow Bluetooth® permissions for the app. Turn the power knob to the "ON" 2. Complete the vehicle warranty position. The vehicle will remain on Your phone and vehicle connect via information.
Page 34
Windshield Wipers The Brawley™ comes equipped with 2 full-size windshield wipers. The wipers have 3 speeds. To turn on the windshield wipers, flip the switch up. Flip it up or down to increase or decrease speed.
Page 35
Climate Control Mirror Adjustment Steering Wheel Adjustment To adjust the steering wheel: Pull the lever down. 1. The climate control temperature can Move the steering wheel up, be raised or lowered by pressing the down, forward, and backward. temperature switch up or down. Pull the lever up to lock the The mirrors are manually adjustable.
Page 36
Seats Seat Adjustment Safety Belts To adjust the seat Heated Seats Pull the handle at the front of the seat To turn on or increase the temperature of the Slide the seat to the desired position heated seats, press the switch up. Press the and release the handle switch up again to increase the heat and to Try to move the seat back and...
Page 37
Vehicle Features Cruise Control (To Come) USB Outlet Stereo Bluetooth ® Cruise Control is an optional feature. this The Brawley™ is equipped with 2 The Bluetooth® system allows section will describe its operation if it USB (type A) outlets on the side of users with a Bluetooth®...
Page 38
Controlling access to your vehicle with your phone and the Vanderhall Mobile App Frunk Each Brawley™ comes with 2 physical key *Some of these features will be To access the frunk, power on and unlock the cards. In addition to these keys, the available at initial vehicle release.
Page 39
Charging Opening the Charge Port WARNING 1. The charge port is located at the Do not pull the release cable while simultaneously attempting to remove rear of the Brawley™, behind the the charge cable from the charge port. center panel. 2.
Page 40
You can also reference your battery level gauge on the dashboard or the Vanderhall™ application on your phone to monitor the level of charge. If the charge port light is not pulsing green but...
Page 42
Seats and Restraints Seats Seat Adjustment Unlatching the Harness Heated Seats Safety Harness Speed Limiter Feature Safety Belts Why Safety Belts Work Drivers Checks How to Wear Safety Belts Properly Remove Cargo from Seats Securing the Harness...
Page 44
Seats Heated Seats Seat Adjustment The heated seats have 3 To adjust the seat: temperature levels. To turn the heated Warning seats on, press the upper toggle 1. Pull up on the handle at the front of the If you cannot feel temperature change switch up or down, depending on if seat.
Page 45
Why Safety Belts Work Safety Belts Warning The Brawley™ comes equipped with Do not let anyone ride where a safety 4 full-size sport seats with built-in, belt cannot be worn properly. In a 4-point harness safety belts. crash, if you or your passenger(s) are not wearing safety belts, injuries can be This section of the manual describes much worse than if you are wearing...
Page 46
If you ever have any questions or concerns Follow these rules for everyone's The following instructions explain how to about your harness safety belts, contact protection. It is especially important for all your Vanderhall™ dealer for assistance. occupants to buckle up. wear a harness properly:...
Page 47
Remove Cargo From Seats (To Come) Unlatching The Harness Drivers Checks To unlatch the harness, press the In the event that cargo is placed in a Do your driver checks before setting red button on the buckle on your seat, the vehicle may believe that seat off and ensure all riders are fully and waist and pull the thin black nylon to be occupied by an unbuckled...
Instruments and Controls Controls Climate Control Systems Steering Wheel Adjustment Regenerative Braking Climate Control Interface Steering Wheel Warning Light Horn High-Beam On Ligh t Air Vents USB outlets Warning Lights, Gauges, and Cruise Control Light Defrost Indicators Bluetooth® Audio Inspection and Maintenance Instrument Cluster Programs Introduction...
Page 51
Steering Wheel Controls Steering Wheel Adjustment Reverse side Select gear by pushing the up or down arrow buttons. Horn To adjust the steering wheel: Pull the lever down. Move the steering wheel up, down, forward, and backward. Pull the lever up to lock the Right turn indicator button steering wheel in place.
Page 52
Vanderhall™ dealer. shows there may be a problem, contact your Vanderhall™ dealer. Waiting to do When adding electrical equipment, be sure repairs can be costly and even dangerous. to follow the proper installation Remove the cover to access and instructions included with the equipment.
Page 54
Speedometer Dimming the Gauges Power Gauge The power gauge indicates how much 1. Press and hold trip meter button The speedometer shows the energy you are using while operating the from odometer screen vehicle's speed in miles per hour vehicle. (mph).
Page 55
If this light is on while the vehicle is on, a repairs. malfunction has been detected and the vehicle may require service. Contact your Vanderhall™ dealer for service. Caution The battery level gauge indicates about Modifications to the vehicle or the use...
Page 56
Regenerative Brake Warning Alert High-Beam On Light Cruise Control Symbol (To Come) (To Come) For vehicles equipped with cruise control, the cruise control alert When the battery is charged more symbol appears in the odometer than 90% full, a brake warning display screen when the cruise message will display indicating that control is set and active.
Page 57
Bluetooth® Audio Pairing Devices Audio Controls Set Bluetooth® to the up position Power up and unlock the Warning vehicle. Play music: Flip Switch up once Taking your eyes off the trail for too Go to settings on your device. long or too often while using any radio Turn on Bluetooth®...
Page 58
Climate Control Systems Climate Control Interface Temperature Control: The climate control systems control 1. Press the switch up or down to the heating, cooling, ventilation speed, turn on to increase or decrease circulation and defrost for the vehicle the temperature. •...
Page 59
Data Link check engine light is on when the Connector (DLC). vehicle is powered on. Contact your Vanderhall™ dealer if the vehicle’s check engine light is illuminated, will not pass or cannot be made ready for the test.
Page 61
Lighting Exterior Lighting Halo Running Lights Headlamps Headlamp High/Low-Beam Changer Hazard Warning Flash Turn And Lane Change Signals Lightbar Dome Lights...
Page 63
Exterior Lighting Headlamp High/Low-Beam Changer: Fog Light Switch To activate of deactivate the high-beam Halo Running Lights lights, press the high-beam button on 2. Toggle the switch down to activate The halo running lights turn on the rear of the steering wheel under the and deactivate the fog lights.
Page 64
Push the buttons on the back of the steering wheel to indicate which direction you want to signal. A light on either side of the Vanderhall Logo in the speedometer will flash in the direction of the turn or lane change.
Driving and Operation Automatic Parking Brake Cruise Control Shifting out of Park High-Voltage Battery System Park, Reverse, Neutral and Drive Drive Modes Exiting the Vehicle without Park Drivers Seat Exiting AWD - All Wheel Drive Keep Your Key Card and Phone With You RWD- Rear Wheel Drive Brakes...
Page 68
Automatic Parking Brake Shifting out of Park The electronic parking brake in your To shift the vehicle out of Park, press Brawley™ will automatically engage or and hold the brake pedal down and disengage depending on the drive press the upward arrow button on the position the vehicle has been shifted right side of the steering wheel.
Page 69
Shifting P (Park): Use this gear to fully stop and exit the vehicle. The parking brake will automatically engage in Park. R (Reverse): Use this gear to back up. N (Neutral): In this position, the motors are isolated from the wheels. Allowing the vehicle to be moved while not powered on.
Page 70
Park and engage the automatic In the event you find that you are locked parking brake. out of your Brawley™, contact your Vanderhall™ dealer for support and If the vehicle is stopped and the door assistance. is opened, it will shift into Park and...
Page 71
Brakes Regenerative Braking Using Regenerative Brakes WARNING Note Slowly lift off the accelerator pedal and Regenerative braking may be reduced the vehicle will begin slowing down. Do not rely solely on the regenerative temporarily when the vehicle battery is Regenerative braking is not available braking system to stop your vehicle.
Page 72
Traction Control Turning Traction Control Off and On The vehicle can monitor the traction Take care to familiarize yourself Traction Control (TC) can be turned and wheel speed of your wheels and off and on by pressing up on the with with the vehicle by practicing at tires.
Page 73
Setting Cruise Control: Cruise Control (To Come) WARNING When the vehicle is traveling at the desired speed, push the Cruise Control NEVER move your feet away from the button on the back of the steering pedals while in cruise control. Vehicles wheel located under the right turn and obstacles ahead may require you to signal indicator button to turn the...
Page 74
Battery. Always contact a Vanderhall™ dealer to arrange for Battery servicing. • If you are in an accident, exit the vehicle as soon as safely possible.
Page 75
eCrab™ Drive Modes WARNING This mode turns the front and back wheels in opposite directions, enabling the vehicle to • Press the brake pedal and ensure the make a tighter turn than standard vehicle is stationary before changing front wheel turning. drive modes.
Page 76
Regular Speed Drive Modes Low Speed Drive Modes All Wheel Drive - AWD (Default) eCrawl™ The default driving mode when the Available Low Speed Drive vehicle is turned on. In this mode, Modes may vary depending on all four motors are powered on and vehicle model.
Page 78
Vehicle Care General Information Vehicle Storage Appearance Care 80 California Proposition Exterior Lighting Exterior Care 65 Warning Headlamp Aiming Interior Care Bulb Replacement California Perchlorate Floor Mats Electrical System Materials Requirement Towing the Vehicle Electrical System Overload Accessories and Headlamp Wiring Modifications Fuses and Circuit Breakers Vehicle Checks...
Page 80
Certain types of automotive applications such modifications to the vehicle can affect vehicle your Vanderhall™ dealer for the as lithium batteries contained in Remote Key- performance and safety, including such highest quality replacement parts. less Entry transmitters, may contain things as braking, stability, ride and handling, perchlorate materials.
Page 81
Brawley™ is in use. Service the vehicle with an authorized Do not fill the reservoir with water as Vanderhall™ dealer at regular intervals freezing temperatures can damage the to maintain your Brawley™and to reservoir and washer system.
Page 82
Always use the proper Have the braking system repaired brake fluid from a clean, sealed as soon as possible. Contact your container and clean the cap and area Vanderhall™ dealer for around the reservoir before opening. information on vehicle servicing.
Page 83
High connectors. Always contact your voltage cables and connections The Brawley™ has been designed and Vanderhall™ dealer to schedule are colored orange for easy built with safety as a priority. Be aware Battery servicing. identification.
Page 84
All of the vehicles exterior lighting including headlamps, tail lights, turn signals, and license plate light are LED and are not serviceable. Should a lamp fail contact your Vanderhall™ dealer for a replacement...
Page 85
Electrical System Fuses and Circuit Breakers Headlamp Wiring Electrical System Overload The wiring circuits in the vehicle are An electrical overload may cause the protected from short circuits by a lamps to go on and off, or in some cases The vehicle has fuses and circuit breakers combination of fuses, circuit breakers, and to remain off.
Page 86
Instrument Panel Fuse Block The internal fuse block can be located under the dash on the passenger side of the vehicle. To access the fuse block, remove the fuse block cover.
Page 87
Fuses Amp rating [A] Usage Usage Relays Condenser Fan Relay Spare Fuse Defrost Relay Front Accessory Plug Spare Fuse Horn Relay Rear Accessory Plug A/C Compressor and MCU 1 MCU 2 Windshield Washer Pump (To Come) (To Come) Condenser Fan Rear Defrost Radio Amplifier Horn...
Page 88
Tires Caution Remove the valve cap from the tire valve This vehicle comes with high performance Neither tire under inflation nor over stem. Press the tire gauge firmly onto the off-road tires, with a tread and compound inflation is good. Underinflated tires, or valve to get a pressure measurement.
Page 89
Poorly maintained and improperly maintenance affect how fast aging takes •There is cord or fabric showing used tires are dangerous. place. Vanderhall™ recommends that tires through the tire's rubber. • Underinflated tires pose a danger and be replaced after six years, regardless of •The tread or sidewall is cracked, cut,...
Page 90
Hand wash the vehicle using a non- To keep the paint finish looking new, keep Exterior Care abrasive cleaner marked safe for glossy the vehicle garaged or covered whenever Appearance Care surface. Rinse the area immediately with possible. cool clean water. Cleaning Exterior Lamps and Emblems Caution Do not allow cleaning agents to dry on...
Page 91
Windshield Caution Brake System To clean, use a terry cloth fabric To avoid surface damage, do not use Visually inspect for leaks, cracks, chafing, dampened with water. Wipe droplets left strong soaps, chemicals, abrasive etc. from brake fluid reservoir and any behind with a clean dry cloth.
Page 92
Do not use laundry detergents or scratches with touch-up materials surfaces being cleaned to prevent dish washing soaps with degreasers. available from your Vanderhall™ dealer permanent damage. Apply all cleaners A concentrated soap solution will to avoid further damage. Larger areas directly to the cleaning cloth.
Page 93
Caution To clean: Soaking or saturating leather may Saturate a clean, lint-free colorfast Gently blot liquids with a paper • cause permanent damage. Wipe excess cloth with water. Microfiber cloth is towel. Continue blotting until no moisture from these surfaces after recommended to prevent lint more soil can be removed.
Page 94
Floor Mats Cleaning the Floor Mats WARNING The Brawley™ floors are water-proof and can be sprayed-out with water when Do not allow water to fill above cleaning is desired. the top edge of the floor mats. There are 4 drain plugs on each side of the Brawley™. The plugs can be removed by twisting them counter-clockwise 1/2 turn and pulling.
Page 95
Towing the Vehicle Caution Incorrectly towing a disabled vehicle may cause damage. Do not lash or hook to suspension components. Use the proper straps around the tires to secure the vehicle. Have the vehicle towed on a flatbed car carrier. Consult a professional towing service if the disabled vehicle must be towed.
Service and Maintenance Maintenance Schedule Additional Maintenance cont. Tires Owner checks Maintenance schedule Alignment Additional Maintenance Windshield Battery Adjusting the Suspension Brakes Recommended Fluids and Lubricants Fluids Vehicle Identification Number Lamps Capacities and Specifications Shocks...
Page 99
Caution Owner Checks Owner Checks Damage caused by improper maintenance can lead to costly repairs. Checks and Services Once a Month Checks and Services Every 6 Months Maintenance intervals, checks, Check the tire inflation 1. Check the windshield wiper inspections, recommended fluids, and pressures.
Page 100
Servicing your Brawley™ regularly at the recommended intervals will help protect and maintain the condition of your vehicle. If an issue is present with your vehicle before a scheduled interval comes due, contact your Vanderhall™ dealer to schedule a maintenance inspection.
Page 101
If charging, power, or wheel vibration, bounce/ sway while range issues are present, contact your braking, longer stopping distance, or Vanderhall™ dealer. uneven tire wear. SEE BATTERY 83 AND VEHICLE STORAGE • Inspect for signs of damage such as ...
Page 102
Vehicle Care Tires Windshield Tires need to be properly inflated, rotated, To help keep the vehicle looking like new For safety, appearance, and the best and balanced. Maintaining the tires can the vehicle should be cleaned frequently. viewing, keep the windshield clean and save money and fuel, and can reduce the clear.
Page 103
Tools needed to adjust sway bar arms Adjusting the suspension The suspension can be configured to The tools needed to complete the alter the vehicle's performance on adjustment procedure include: different surfaces. The default • (1) 14mm socket with ratchet configuration of the suspension is set up and (1) 14mm wrench or (2) 14 for best results on hard surfaces such as...
Page 104
Vanderhall™ dealer. until it aligns with the inner control arm Loosen but do not fully remove the bolt bracket.
Page 105
Recommended Fluids Recommended Fluids and Lubricants Fluids and lubricants identified below by name, part number, or specification can be obtained from your dealer. Fluid/ Lubricant Usage Power train Oil Use only DEXRON VI oil 50/50 mixture of clean, distilled water and use only DEX-COOL® Coolant. Power train Coolant DOT 4 Hydraulic Brake Fluid Hydraulic Brake System...
Page 106
Vehicle Identification 1. Vehicle Identification Number This legal identifier is on the front right corner of the chassis, located behind the Wheel. The VIN also appears on the Vehicle Identification Label affixed to the bottom side of the hood.
Page 107
Capacities and Specifications The following approximate capacities are given in metric and English conversions. SEE RECOMMENDED FLUIDS AND LUBRICANTS 105 Capacities Application Metric English For the air conditioning system refrigerant type and charge Air Conditioning Refrigerant amount, see the refrigerant label affixed under the hood. Powertrain Cooling Systems 600 ml 0.63 qt...
Page 110
This warranty is provided only to the original purchaser from an authorized Vanderhall NA dealer, but it can be transferred to subsequent owners during the warranty period through an authorized Vanderhall NA dealer. Any transfer of this warranty to a subsequent owner will not extend the warranty coverage period.
Page 111
PRODUCT WARRANTY, LIMITATIONS AND EXCLUSIONS Vanderhall NA warrants, subject to the limitations and exclusions below, that the VNA Products will be free from defects in workmanship and materials for a period of six (6) months after the VNA Product was first delivered to the first retail (non- commercial) customer.
Page 112
Certain items are excluded from warranty coverage by Vanderhall NA, and this limited warranty coverage does not apply to: Modifications, including the use of aftermarket Normal and routine maintenance, or improper or or unapproved components and any damage inadequate maintenance (see applicable Vanderhall they cause.
Page 113
BATTERY PACK LIMITED WARRANTY The lithium-ion battery pack (the “Battery Pack”) in your Vanderhall NA electric vehicles is a very technical component and is covered under this Limited Warranty. Any warranty replacement may not restore your vehicle to a condition that is “like new”.
Page 114
The vehicle’s estimated range is an imperfect measure of Battery Pack capacity. REMEDIES UNDER THIS LIMITED WARRANTY If a defect covered by this warranty occurs, Vanderhall NA (or one of its authorized dealers, as determined by Vanderhall NA) will repair and replace the defective component, in its sole discretion.
Page 115
Vanderhall NA. ▪ If the dealer from whom the vehicle was purchased is no longer an authorized Vanderhall NA dealer, contact Vanderhall NA for instructions on how to obtain warranty service.
Page 116
To the extent that the arbitration rules stated herein conflict with the law, you and Vanderhall NA agree to be bound by the laws, regulations, and rules of Utah regarding arbitration between customers and manufacturers.
Page 117
OTHER INFORMATION This Limited Warranty is the sole and exclusive statement of the warranty coverage provided by Vanderhall NA. The terms of this written warranty cannot be changed or modified, except by a written agreement signed by an officer of Vanderhall NA. Vanderhall NA’s dealers are independent business and are not the agents of Vanderhall NA for any purpose.
Page 118
Index Battery ........74, 88 Fan Speed ........58 Wheels ......... 91 Battery Charging ......39 Windshield ........91 Recirculation ......... 58 Discharge Protection ....88 Exterior Lighting ....... 64 Temperature ......... 58 Finish Care ........90 Cruise Control Battery Level Gauge ......55 Activation ........
Page 119
Index Maintenance........100 Unlatching........47 Suspension Maintenance and Care ....100 Why Safety Belts Work ....45 Adjusting the suspension ..103 Maintenance Schedule ....101 Seat Adjustment ......... 44 Sway Bar Adjustment ....104 Malfunction Indicator Lamp Shifting Tires Overview .........
