- Page 1 User guide Bridge Version 0.1 11/22...
- Page 2 In the meantime, you should follow us on Facebook and Youtube! Like us on Facebook Visit our Youtube As our igloohome app is frequently updated, there may be changes to this manual. Please refer to our website igloohome.co/support for the latest version of the manual.
-
Page 3: Table Of Contents
Compatible igloohome Locks Setting up Bridge Placement of Bridge Power Up App Onboarding Using the Bridge Managing Locks/Devices in App Retrieving Activity Logs Bridge & Linked Device Status Push Notifications Night Mode Unpairing the Bridge Hard Reset LED Indications Troubleshooting... -
Page 4: What's Included
What’s Included Bridge Adhesive Mounting Tape USB-C Cable... -
Page 5: Specifications
Net: 0.04kg / 0.1lbs Gross: 0.2kg / 0.4lbs Front Side 64mm (2.5”) 24mm (0.9”) For damage resulting from incorrect use of Bridge, or use of Bridge outside of stipulated specifications, the customer bears sole responsibility. igloocompany accepts no liability whatsoever. -
Page 6: Bridge Anatomy
Bridge Anatomy WiFi LED Bluetooth LED USB-C Port Multi-Function Button... -
Page 7: Features
Lock & Unlock as and when you want to. Stay in the loop Connects to your home’s WiFi Network Retrieve activity logs on the go. The Bridge uses 2.4GHz WiFi to connect to the internet. Others Near real-time notifications Link up to 5 Devices... - Page 8 Bridge. The near real-time notifications of activity logs will not be available. You will need to do a Bluetooth sync to retrieve them. You will still be able to remotely unlock your door via the Bridge. The distance stated above are for reference only and are for line of sight between the Bridge and the device.
- Page 9 NOTE: The Bridge functions best when locks are within close proximity to the Bridge. Please refer to the table on the previous page for the maximum distance between the Bridge and the igloohome device. The Bridge also needs to be placed within WiFi range of your router.
-
Page 10: Power Up
Power Up Plug in the USB-C end of the provided USB cable into the USB-C port on the Bridge. Insert the other end of the cable into a USB-A Power Adapter* and then plug the adapter into a power outlet. - Page 11 App Onboarding Register as a Lock User a) Download the igloohome app from the App Store / Play Store b) Create an account and login Sync your Locks Before linking the Bridge to a lock, 1. On the igloohome app, select the lock that you want linked 2.
- Page 12 Pairing the Bridge Go to [Add and Manage], select [Bridges], and select the [+] sign at the top right corner. Follow the onscreen instructions and wait for the pairing to complete. Once the Bridge is paired, enter a name for the Bridge.
- Page 13 Connect the Bridge to your WiFi Network a) Select [Start WiFi configuration] b) If your phone is already connected to a WiFi network and you would like the Bridge to connect to the same WiFi network, please enter the password for that WiFi network.
- Page 14 Add / Link a Lock to your Bridge a) Select [Create Link] b) Select a lock to begin linking, wait for the linking to complete. Select [Test all links] to complete your setup or select [Create more links] to link...
- Page 15 5. Select [+] icon on the top right hand corner Unlink Locks from your Bridge To Unlink locks, repeat steps 2 - 4 above. Select the Bridge you want to unlink the locks from and select the unlink icon to the right of the lock.
- Page 16 If your lock is from an earlier batch, the activity logs will not be automatically retrieved by the Bridge. You will have to upgrade the Firmware on the lock in order for the Bridge to automatically retrieve activity logs from the lock. Please check the availability of a Firmware update for your lock.
- Page 17 Bridge and lock depending on the type of lock(s) you are using. Please note that the actual range will be lower when there are obstacles between the Bridge and the lock as well as interference from other electronic devices.
- Page 18 This will ensure that the WiFi status of the Bridge as well as the individual device status, battery level as well as the Bluetooth signal strength gets automatically updated.
-
Page 19: Night Mode
Night Mode Activate Night Mode turns off the Bridge’s status indicator lights to ensure that they do not disturb the user at night. To activate Night Mode, press the Multi-function button twice in quick succession. Deactivate To deactivate Night Mode, press the Multi-Function button twice. -
Page 20: Unpairing The Bridge
1. Go to [Add and Manage], select [Bridges] 2. Select on the Bridge you want to remove 3. Select on the [Delete Bridge] button Note: The Bridge can be paired to other igloohome accounts after the bridge has been unpaired from your igloohome account. - Page 21 Hard Reset initiated LEDs turned off Hard reset will result in all settings and data being reset on the Bridge. The Bridge will not be able to be deleted from the igloohome account when the Bridge is hard reset and the user will have to contact igloohome customer support to remove the Bridge from their account.
- Page 22 Bridge is unpaired and dormant or Powered Off Blinking Red when button Blinking Red when button Multi-function button pressed pressed for more than pressed for more than (Bridge will hard reset when 5 seconds 5 seconds button pressed for 10 seconds)
- Page 23 Bridge is paired to WiFi signal strength is very weak Can’t pair the Bridge • Move the Bridge to a power outlet that is closer to the WiFi router • Consider moving the router closer to the Bridge •...
- Page 24 Compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 25 For inquiries go to: igloohome.co/support...
