- Page 1 ELECTRIC BIKE EB ROAMER ST ELECTRIC BIKE COPYRIGHT 2024 JASION.ALL RIGHTS RESERVED. USER MANUAL USER MANUAL The manufacturer reserves the right to make changes to the product and manual at any time Visit www.jasionbike.com to download the latest user manuals...
-
Page 2: Table Of Contents
Congratulatuions on Contents your purchase ! Home Page Product Safety Notice This user manual will help you assemble and operate your new elec- tric bike. Be sure to read all the information in this manual before Warning Message riding. Package Contents NOTE TO ALL RIDERS UNDER 18 YEARS OF AGE: It's very important that you get parental permission before riding Product Overview... -
Page 3: Product Safety Notice
Abuse - We do not cover physical damage due to negligent care and extreme riding. Always wear a helmet when riding your electric bike. Whenever you ride the Jasion Electric Bike, you risk severe injury or even death from loss of control, collisions, and falls. Use caution and ride at your own risk. -
Page 4: Package Contents
Package Contents Product Overview Carefully check package contents, if anything is missing or damaged,please contact Jasion customer service for support: support@jasionbike.com LCD Display Shifter Unpack the bike. Open the bike box and remove the small box inside. With the help of another person capable of safely lifting a heavy object, remove the bike from the bike box. -
Page 5: Assembly
Assembly Assembly Step 1 - Front Fork Step 2 - Front Fender & Headlight If you do not feel comfortable assembling the bike yourself, we recommend taking your new bike to a bike shop for assembly and inspection. If you are willing to assemble the bike yourself, Headlight be sure to follow all instructions, properly adjust gears and brakes, and set tire pressure. - Page 6 Assembly Assembly Step 3 - Stem Step 4 - Kickstand Take out the kickstand and loosen the Make sure the kickstand is align with the Loosen the screws to Take out the stem and Tighten the screws to fix two screws on top. two holes in the frame.
- Page 7 Assembly Assembly Step 5 - Rear Rack & Taillight Step 6 -Seat For better pedaling, safety and overall riding comfort, positioning the seat at the right height is important. The rider's leg length is used to determine the seat's position. When you pedal, your hips should remain level and your legs should be almost fully extended at the bottom of the pedal stroke, but not over-extended.
-
Page 8: Start-Up Procedure
Note: If the pedal/ chain doesn't run smoothly or something seems misaligned, please contact Jasion Support at support@jasionbike.com. -
Page 9: Remove The Battery
Remove the Battery Charge Your E-Bike Before using the electric bike, you must fully charge the battery. Charging port Put the key into the lock, turn it to the When the battery is unlocked, it will pop left which is the direction for unlocking. down. -
Page 10: Display And Setting
Charge Your E-Bike Display and Setting The battery can be charged off the bike. To remove the battery, turn the key to the left position (see the previous remove battery section for details). Error Display Backlight Power Level Speed Speed Unit Remove the rubber cover on the charging port Speed Mode on the opposite side of the battery from the key... - Page 11 LCD Display Controls Operation Directions Number Set up the item Specific The screen appears Turn on bike Press and hold button (2) Long Press button (2) Turn off bike Backlight brightness 1 level darkest, Setting 3 levels brightest Increase pedal assist(PAS) level Press button (1) Decrease pedal assist (PAS) level...
- Page 12 In daily use, try to avoid recharging the bike after completely exhausting the battery. lf the battery is low, charge it as soon as possible. Please charge the bike every other month to preserve the battery. Note: Please do not change the setting values of P09-P20, contact Jasion at support@jasionbike.com if you have any questions.
- Page 13 Notice: Before every ride, and after every 35-50 miles(56km-80km), we advise following the pre-ride safety checklist. Regular inspection and maintenance are key to ensure bikes from jasion function as intended, Safety Check and to reduce wear and tear on their systems. Recommended service intervals are meant to beused as guidelines.
- Page 14 Check that the seat is adjusted properly, and seatpost quick-release lever is securely tightened. Jasion recommends 45-60 PSI for the stock tires on the Jasion. Always stay within the manufac- turer's recommended air pressure range as listed on the tire sidewall.
-
Page 15: Troubleshooting
ITEM SPECIFICATIONS Symptoms Possible Causes Most Common Solutions Model EB5 Roamer ST 1. Insu cient battery power 1. Charge the battery 2. Faulty connections 2. Clean and repair connectors 3. Battery not fully seated in tray 3. Install battery correctly... -
Page 16: Faqs
We will deduct the shipping fee or restocking $180/pc when we are making a refund for non-defective products and non-longer needed products. For the return request, Jasion is not responsible for lost packages due to the carrier, or products received that can not be verified. - Page 17 All accessories originally included with your purchase must be included with your return. lf you return a product to Jasion, (a) without an RMA from Jasion(b) without all parts included in the original package, Jasion retains the right to refuse delivery of such return.
-
Page 18: Contact Us
Contact Us Contact us if you experience issues relating to riding,maintenance and safety, or errors/faults with your JASION Scan the QR code and join our Facebook Group. Share your riding experience with other rides and get an exclusive bonus! JASION LTD www.jasionbike.com...
