BENDIX ADF-T12B Maintenance Manual page 99

C A U T I O N
Lead lengths must allow lamps to locate in the lens recess.
To remove azimuth dial and gear plate assembly:
R e m o v e a z i m u t h c o n t r o l k n o b .
( a )
Remove two screws holding dust cover, and withdraw
( b )
u n i t f r o m d u s t c o v e r .
Remove three holding screws from rear of front bezel
( c )
a s s e m b l y.
H o l d t h e a z i m u t h c o n t r o l s h a f t a n d l i f t o ff t h e e n t i r e
( d )
front bezel assembly.
C A U T I O N
The azimuth control shaft is not captive in the front bezel
assembly, and will drop out if not held.
( e ) R e m o v e p o i n t e r a s s e m b l y.
(f)Remove two screws holding the azimuth dial.
(g)Remove two screws holding the gear plate assembly to
posts on the motor and gear train assembly.
I L L U S T R A T E D P A R T S B R E A K D O W N
The attached table, when used in conjunction with figure 303 and table 5-3, pro¬
vides acomparison of part differences.
B e n d i x A v i o n i c s D i v i s i o n
I . B . 2 0 1 2 A 9 6 9
S u p p l e m e n t N o . 1
3 o f 7
