CAUTION
Net to Net Technologies strongly recommends the use of proper electrostatic discharge (ESD) precautions when
handling this equipment.
Installation
1. Unpack and inspect the equipment.
The following components should be included:
1 UIM-DS3
4 #6 Phillips Panhead Internal Locking Screws
2 #6 Phillips Beige Flathead Screws
If there is any visible damage, do not attempt to connect the device. Contact Customer Support at 1-
877-638-2638 (001-603-427-0600 for international customers) or Support@NetToNet.com.
2. Verify switch configuration.
Ensure that the DIP switches on the UIM-DS3 circuit board are positioned correctly (according to
desired configurations) prior to installing the UIM-DS3 on a Multiplexer Uplink Module or in a Mini
DSLAM. There are two DIP switches located on the top side of the circuit board, opposite the
faceplate. Switches are numbered from left to right; Switch #1 (on the left) is not used, Switch #2
(on the right) is configured as follows:
Transmit Line Buildout
Switch Configuration
Switch #1 Switch #2 Tx Line Buildout
not used
not used
220-0000072 rev01
UIM-DS3
DS3 Uplink Interface Module
down
0-255 ft.
up
255-450 ft.
Installation Instructions
Advertisement
Table of Contents
Related Manuals for Net to Net Technologies UIM-DS3
Summary of Contents for Net to Net Technologies UIM-DS3
- Page 1 Ensure that the DIP switches on the UIM-DS3 circuit board are positioned correctly (according to desired configurations) prior to installing the UIM-DS3 on a Multiplexer Uplink Module or in a Mini DSLAM. There are two DIP switches located on the top side of the circuit board, opposite the faceplate.
- Page 2 Affix the UIM-DS3 to a Multiplexer Uplink Module (MUM). NOTE The UIM-DS3 may be attached to a MUM that has already been in service, although you must remove the MUM from the IP DSLAM in order to do so. Removal of a MUM from an IP DSLAM chassis that is powered up will not affect the operational status of other modules within the chassis;...
- Page 3 Remove the (8) screws securing the Mini DSLAM chassis and carefully lift off the chassis cover. Set the screws aside. b. Select a port on the Mini DSLAM for UIM-DS3 installation; either port (1 or 2) may be used. Although not required for operational purposes, if redundancy is desired, two UIMs may be installed in the Mini DSLAM, one in each port.
- Page 4 NOTE A DS3 Uplink Interface Module (UIM-DS3) must be connected via DS3 line to a DS3 network extender provider unit (DNE4500-P or DNE4500-P-6-AC/DC). A UIM-DS3 connected to a DS3 network extender subscriber unit (DNE4500-S) will not function.
- Page 5 environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
