Bluetooth Car FM Transmitter and
Charger FMT-63BT
EN - ENGLISH
USER MANUAL
Thank you for purchasing our Bluetooth car charger!
In order to have a best performance experience,
please read the manual carefully before use!
I. Product introduction
This product is a car-specific car Bluetooth
player, built-in advanced Bluetooth and
WMA.MP3, FLAC. decoder chip, can play music
files inside U disk, wirelessly transmitted to car
audio, no need to modify your car can easily
make your music enjoy while driving. More
important is the purity and clarity of the special
sound of DSP technology. We hope to bring you
unlimited enjoyment of the music.
II. Schematic Appearance
Description:
1. USB1: QC3.0 fast charge output
2. PD fast charge
3. LED display
4. On / off key; press and hold for two seconds
to turn off / press any key to turn on
5. Short press: Previous/Long press to enter
mode switching (BT/USB/TF)
6. MIC
7. Play / pause / answer / call back / long press
to wake-up SIRI / Left and right rotation to adjust
the volume / addition and subtraction of left and
right rotation frequency in FM mode
8. Colorful light frame
9. U disk playback / 5V1A output
10. Short press the colorful light button to switch
/long press the colorful light button to turn on
breathing mode
11. Short press: next song / long press to enter
FM mode
12. TF card slot
13. Positive and negative Cigarette
III. Features
1. Bluetooth V5.0
2. Dual display digital tube display
3. Support QC3.0 quick charge
4. Support PD quick charge
5. Support voice assistant function
6. Support one-key soft shutdown; support any key to
boot
7. Support colorful light
8. Battery voltage detection
9. Automatic power off memory function
10. Support U disk music player
11. Support TF card music player
12. Support WMA, MP3, WAV, FLAC music format
files
13. Supports A2DP, AVRCP, HFP, HSP
14. Bluetooth hands-free calling
15. Bluetooth frequency: 2.4 – 2.483 GHz
16. Bluetooth channel emission power: 2dbm
VI. Operation instructions
4.1.1. The device will auto power on after plugging it
into the car cigar lighter socket, the LED will flash and
display HI->BT->FM Frequency.
4.1.2 Tune up the FM frequency same with the car
radio, then the voice will come out from the original
car speaker
4.1.3 Adjust the FM frequency:
Long press
to enter state,the LED display
flashes, turn left/right to adjust the transmission
frequency from 87.5 ~ 108MHZ, and exit the
frequency point selection without operation for three
seconds.
4.2 Bluetooth Pairing
When pairing the product with the mobile phone at
the first time, it may need pin code to finish the
paring, for more details, please refer to the relevant
manual
1. Please turn on Bluetooth on your mobile phone and
search for the device "FMT-63BT" from phone menu
list. 2.Choose the device "FMT-63BT"
