Akai FMT-30 User Manual

FMT-30
FM Transmitter User Manual
Product Overview
Thanks for using Car MP3 Player!
Car MP3 Player read the MP3 audio file in the Built-in and flash USB
flash disk and transfers the audio signal to the car FM tuner through the
built-in FM transmitter. You enjoy the MP3 music through the Car FM
tuner. It also has LINE-IN feature which transfers the audio source from
the external audio device such as CD, MP3 player to the Car FM tuner.
Just insert the USB flash disk which stores MP3 files to the USB port or
connect to an external audio device, and adjust the Car FM tuner to the
channel which is indicated on the Car MP3 player, now you can enjoy
your favorite music.
Features
-MP3 player
Read MP3. WMA file from the external USB disk directly and broadcast
through the Car FM tuner.
Provide four keys to control the playback: PLAY/PAUSE/ PREV/V-,
NEXT/V+ and CH.-FM transmitter
Transmitter music from external audio player (CD, MP3 player etc.) to
the FM radio.
-Frequency Display and work state (play. Pause) indicator.
-Rotary joint design convenient for you to adjust the device` s position.
-206 preset channels from 87.5-108MHz.
-Car cigarette lighter power supply.
-Song memory function.
Device Diagram
1. LCD Display
2. Previous Track &Volume Decrease
(USB disk &SD card)
Press this button once to return to the previous file
Press and hold to decrease the volume
3. Press the button
To decrease the broadcast frequency
4. Press the button
To increase the broadcast frequency
5. Next Track &Volume Increase
(USB flash Memory &SD card)
Press this button once to advance to the next file
Press and hold to increase the volume
6. Play/Pause
(USB disk &SD card)
Press this button once to start playing an MP3 file
Press it again to pause
7. 12-24 Volt
8. Power
9. SD Memory Card Slot
10. USB Port
11. Audio input
Operations
Set up
1. Insert the device to car cigarette socket power supply (12v-24v DC
power). You will see the screen as shown channel in LCD display.
2. Tune your FM radio to one of pre-set FM frequencies used by the
player.
3. Press the button " "or " "to set the player's broadcast
frequency to match the frequency you have set on your radio
Pre-set Broadcast Frequency.
SD Memory Card & USB Flash Memory
1. Follow the instructions in the "Set Up" section of this manual
2. Insert the SD memory card into the SD card slot on the player.
3. Press the button to play/pause. Keep press
play mode (ALL/FOLDER/SINGLE/RANDOM).
4. Press the button once to go to the previous file. Press and
hold the button to decrease the volume.
5. Press the button once to go to the next file. Press and hold
the button to increase the volume
Then you can enjoy MP3 music with excellent quality through the FM
stereo audio set.
LINE-IN Function
The device supports LINE-IN feature that enables you to enjoy the
music from an external audio device such as CD, MP3 player.
The external audio source comes into the Car MP3 player through the
line-in jack and is transmitted to the Car FM tuner by the built-in FM
transmitter. You enjoy the music through the FM stereo audio system.
To enjoy the music on the external audio device through the FM radio:
1. Connect one end of the LINE-IN cable to the line-in jack of the Car
MP3 player. And connect the other end to the earphone jack of the
external audio device.
2. Turn on the external audio player and play the music.
Technical Specifications
Item
USB interface
FM frequency range
SNR
Output Frequency
Supported File
Audio Source
Bit Rate
Power Supply
Notice
-The device supports most USB disk except a few.
-Frequency of the Car FM tuner should be the same as that of the Car
MP3 player.
-You` d better not pull out the USB flash disk during play back. Pause
the playback first.
-The progress may be slow when the USB flash disk stores too many
audio files.
-In order to extend the device life, please do not keep it in use for too
Package Content
-Main Unit
-Line-in Cable
-Safety Tube
-Safety Tube installation Guide
DISPOSAL OF WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT
This symbol on the product or packaging means
that the product should not be treated as
key to switch
household waste. Do not throw garbage at the
end of its life, but take it to a collection center for
recycling. In this way you will help to protect the
environment and be able to prevent any negative
consequences that it would have on the
environment and human health.
To find your nearest collection center:
- Contact local authorities;
- Access the website: www.mmediu.ro;
Request additional information from the store where you purchased
the product.
Description
USB1.1 (USB2.0 Compatible)
87.5-108MHz
85dB
20HZ-20KHZ
Mp3
USB flash disk or audio player
32Kbps-320Kbps
12V-24V(DC)
