Pergola Tilt RTS Control Box Connection Quick Start Guide for Slim Motor
BEFORE YOU BEGIN: Power must be cut before wiring or making any wiring changes
DESCRIPTION & CONNECTIONS
Switch 1
ON
Drive with coder sensor
OFF
Drive without coder sensor
Switch 2
(only if switch 1 is set to ON)
ON
Activates synchronization S1 and S2
OFF
Deactivates synchronization S1 and S2
Switch 3
ON
5.5 A max. per output
OFF
3 A max. per output
Switch 4
ON
Activates the temperature sensor
OFF
Deactivates the temperature sensor
Switch 5
ON
Open 50% in the event of wind
OFF
Open 100% in the event of wind
Power Supply Input
A
-
24 Vdc power supply input (SELV)
B
+
Drive output 1
Yellow
C
-
24 Vdc - 3A/5.5A drive: Maximum
current according to switch 3
Green
D
+
Drive output 2
Yellow
E
-
24 Vdc - 3A/5.5A drive: Maximum
current according to switch 3
Green
F
+
Rain Sensor
O
Contact
Dry contact input
P
Common
Q
-
Power supply output:
R
24 Vdc/- 300 mA
+
DESCRIPTIONS OF CIRCUIT BOARD INDICATOR LIGHTS
The LED flashes every 4 seconds: Circuit board waiting.
The LED flashes rapidly: Command in progress.
The red LED light remains illuminated for 5 seconds: Current consumption threshold has
been exceeded or circuit board has heated up too much during an output command.
The red LED flashes: drive synchronisation fault.
The orange LED remains illuminated for several seconds: Backing-up the memory.
The orange LED flashes rapidly: Movement of a drive not permitted by a sensor action.
The orange LED remains illuminated: The rain threshold has been
exceeded.
The orange LED flashes rapidly: protection still in progress for 15
External
antenna
T
Output
R
Q
O P
Power
supply
Rain
sensor
-
+
-
+
OUTPUT Vdc
C
D
OUTPUT Vdc
-
-
+
S1
OUTPUT Vdc
-
+
-
+
S1
OUTPUT Vdc
Status
Fault
Rain
(1) (2)
S
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
A
B
E
F
POWER SUPPLY
POWER SUPPLY
+
-
+
-
S2 +
OUTPUT Vdc
-
+
-
S2 +
OUTPUT Vdc
The orange LED remains illuminated: the ice threshold has been
exceeded.
The orange LED flashes rapidly: protection still in progress for 15
External antenna
S
Signal
T
GND
Status
Fault
Wind
Rain
1
Temperature
PROG
button.
Switch 1
2
Switch 2
Switch 3
Switch 4
Switch 5
3
Power
supply
input
Drive
output S2
Drive
output S1
Wind
The orange LED remains illuminated: Wind
threshold has been exceeded.
The orange LED flashes rapidly: protection still
last being exceeded.
Temperature
(1) (2)
Conductor
Shielding braid
4
T
S
(1)
