- Page 1 Ecostore Vertical refrigerators Type reference V.M..Quick guide 595R73602- 2024.02 *Original instructions...
-
Page 2: Table Of Contents
1. make sure to have the application for QR code reading on your device and an internet connection available; 2. scan the QR code; 3. register your product; 4. consult the documents needed; The complete Installation and user manuals are also available on Electrolux Professional SpA website: www.electroluxprofessional.com... -
Page 3: Awarning And Safety Information
WARNING AND SAFETY INFORMATION General information To ensure safe use of the appliance and a proper understanding of the manual it is necessary to be familiar with the terms and typographical conventions used in the documentation. The following symbols are used in the manual to indicate and identify the various types of hazards: WARNING Danger for the health and safety of operators. - Page 4 Ventilation type None= standard (upper ventilation) / M= Marine (frontal ventilation) Refrigerant type None = built-in cooling unit R134a or R404a R= remote cooling unit HC= built-in cooling unit R290 Personal protection equipment Summary table of the Personal Protection Equipment (PPE) to be used during the various stages of the appliance's service life. Stage Protective Safety footwear...
- Page 5 – Positioning – Electrical connection – Appliance cleaning, repair and extraordinary maintenance – Appliance disposal – Work on electrical equipment – Dismantling operations of appliances which use R290 or R-744 (with a refrigeration system under high pressure) – Dismantling operations of appliances which use flammable insulation blowing gases; Protection devices installed on the appliance Guards The appliance has:...
- Page 6 To preserve these conditions, the areas around the appliance must always be: • kept free of obstacles (e.g. ladders, tools, containers, boxes, etc.); • clean and dry; • well lit. For the Customer's complete information, the residual risks remaining on the appliance are indicated below: such actions are deemed improper and therefore strictly forbidden.
- Page 7 A.12 Installation and assembly • The installer must evaluate the minimum volume of the installation’s environment necessary to reduce the risks related to danger caused by the flammability and toxicity of the refrigerant present in the appliance. • The operations described must be carried out in compliance with the current safety regulations and provisions in force in the country of use.
- Page 8 A.15 Electrical connection for appliances with plug • To connect to the power supply, insert the power cable plug in the corresponding mains socket, first making sure: – the socket has an efficient earth contact and the mains voltage and frequency match that given on the dataplate. In case of any doubts regarding the efficiency of the earth connection have the system checked by specialised personnel.
- Page 9 WARNING: • Do not use mechanical devices or other means to speed up the defrost process, unless recommended by the manufacturer. • Do not damage the refrigerant circuit. • Do not use electrical appliances inside the appliance compartments for storing frozen food, unless such equipment is recommended by the manufacturer.
-
Page 10: Bgeneral Information
This appliance is designed for the refrigeration and preserva- This manual is intended solely for consultation by the operator tion of foods. and can only be given to third parties with the permission of Electrolux Professional SpA company. Any other use is deemed improper. NOTE! Responsibility... -
Page 11: Doperating
CAUTION 2. remove the cables from their packing; • Install the appliance in a ventilated place, away from heat sources such as radiators or air conditioning systems, to allow correct cooling of the refriger- ating unit components. • Never cover the condenser, even tem- porarily, as this can compromise its proper operation and therefore that of 3. -
Page 12: Etroubleshooting
INTERNAL LIGHT BUTTON (if present) PROGRAM BUTTON It allows to switch on/off the inside light. Pressed briefly It allows to save value; Pressed for 3 seconds it allows to unlock keypad CONTINUOUS CYCLE BUTTON and enter programming mode. It allows to activate/deactivate the Continuous cycle ON-OFF BUTTON / DOWN ARROW for decreasing the values. - Page 14 Electrolux Professional SPA Viale Treviso 15 33170 Pordenone www.electroluxprofessional.com...
