WAL CANOPY RANGEHOOD

INSTALLATION AND

USER'S MANUAL

M odel: T R 20160 & T R 20190

Table of Contents

Need help?

Do you have a question about the TR 20160 and is the answer not in the manual?

Questions and answers

Summary of Contents for Trinity TR 20160

Page 1 WAL CANOPY RANGEHOOD INSTALLATION AND USER’S MANUAL M odel: T R 20160 & T R 20190...
Page 2: Table Of Contents
Contents Introduction Safety precautions Installation Installing the charcoal filer Operation Care and maintenance Troubleshooting Environmental protection...
Page 3: Introduction
Introduction Thank you for choosing this extractor hood. To ensure that you get the best results from your new extractor, we strongly suggest that you read this instruction manual thoroughly before use. If treated with care, your extractorshould give you years of trouble-free use To register ownership, please ensure you complete and returnthe guarantee card supplied with the appliance.
Page 4 damaged. A damagesupply cord must be replaced by qualified service personnel only. Please contact the service department. If the room where the hood is to be used contains a fuel burning appliance such as a central heating boiler then its flue must be of the sealed orbalanced flue type.
Page 5: Installation
Installation Prepare for the installation: a. If you have an outlet to the outside, your cooker hood can be below picture by means of an extraction duct connected as per the with an interior diameter of 150mm. b. Before installation, turn the unit off and unplug it from the outlet. c.
Page 6 Installation – ducted Attention! Observe the warning concerning the operation of the appliance when air is discharged from the room. Drill 3 x 8mm holes to accommodate the bracket. Screw and tighten the bracket onto the wall with the screws and screw plugs provided. Screw Holes on Screw...
Page 7 Fix the one-way-valve to the air outlet of the cooker hood. Then, attach the exhaust pipe to the one-way-valve as shown below. Exhaust pipe Cooker hood Chimney installation. Place the upper chimney into the lower chimney . Use 2 pcs ST4x8mm screws to attach lower and upper chimney together.
Page 8 Drill 2 holes to accommodate the plate II. Screw and tighten the plate II onto the wall with two screws and wall.plugs provided Slide up the upper chimney and fix the upper chimney with plate II with 2 screws ST4x8mm Fix the lower chimney with the hood with 2 screws ST4x8mm...
Page 9: Installing The Charcoal Filer
Installation – recirculation mode If you do not have an outlet to the outside, the exhaust pipe is not required (as shown in the section “Installation - ducted”). Installing the charcoal filter An activated charcoal filter can be used to trap odours. In order to install the charcoal filter, the grease filter should be detached first.
Page 10: Operation
Operation Low speed button Is suitable for simmering and cooking which does not produce much odour. Medium speed button The airflow speed is ideal for extracting with regular cooking. High speed button When a high amount of smoke or odour is produced, press the high speed button for the most effective extraction.
Page 11: Care And Maintenance
Care and maintenance IMPORTANT: Before cleaning or maintenance please switch off the electricity supply and remove the plug from the wall. Regular cleaning Use a soft cloth moistened with lukewarm mildly soapy water or household cleaning detergent. Never metal pads, chemicals, abrasive material, abrasive cleaning creams or stiff brushes to clean the appliance.
Page 12: Troubleshooting
Replacing the bulb 1. Switch the unit off and unplug the appliance. 2. Remove the lamp cover by unscrewing the 2 screws. 3.Unscrew the bulbs. 4.Replace with the same type and rated bulb/lamp. Troubleshooting Fault Cause Solution The lights on, Switch off the unit and The fan blade is jammed.
Page 13: Environmental Protection
Environmental protection Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice. This appliance is marked according to the European directive 2012/19/EC on Waste Electrical and Electronic Equipment (WEEE). By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this...

This manual is also suitable for:

Tr 20190
