- Page 1 User Manual Undermount Rangehood 52cm & 90cm Model Code: TR913B52, TR913B90 Please read this manual carefully before using, and keep it for future reference.
-
Page 2: Table Of Contents
P a g e CONTENTS PACKAGE ..............................3 IMPORTANT - CHECK FOR ANY DAMAGE OR MARKS ..............3 HANDLING ............................3 UNPACKING ............................3 BEFORE USING YOUR NEW APPLIANCE ..................4 SAFETY WARNINGS ............................ 5 IMPORTANT INFORMATION ......................5 WARNING ............................5 USAGE CONDITIONS AND RESTRICTIONS .................. -
Page 3: Package
P a g e Congratulations on purchasing your new appliance! We recommend that you read this Instruction and Installation Manual in order to fully understand how to install and operate it correctly. For installation, please read the installation section. Read all the safety instructions carefully before use and keep this User Manual for future reference. -
Page 4: Before Using Your New Appliance
P a g e All materials used for packaging are environmentally friendly and are fully recyclable. CAUTION: During unpacking, the packaging materials (polythene bags, polystyrene pieces, etc.) should be kept out of reach of children. 1.4 BEFORE USING YOUR NEW APPLIANCE ... -
Page 5: Safety Warnings
P a g e 2 SAFETY WARNINGS 2.1 IMPORTANT INFORMATION Your safety is important to us. Please read this manual thoroughly before you start using the appliance. The safety precautions instructions reduce the risk of fire, electric shock and injury when correctly complied to. - Page 6 P a g e Your new rangehood is guaranteed against electrical or mechanical defects, subject to certain exclusions that are noted in the Warranty Terms and Conditions. The foregoing does not affect your statutory rights. Always cover lit gas burners with pots or pans when cooker hood is in use. ...
-
Page 7: Usage Conditions And Restrictions
P a g e Cut with sharp tin snips or a fine-tooth hack saw blade, taking care not to distort or dent the exhaust cover. Where using expandable ducting, it’s important to have the ducting fully taught to maximise efficiency of the airflow. 2.3 USAGE CONDITIONS AND RESTRICTIONS ... -
Page 8: Product Overview
P a g e 3 PRODUCT OVERVIEW 3.1 LAYOUT TR913B52 TR913B90 3.2 RANGEHOOD COMPONENTS The Rangehood is supplied with: 1 × Rangehood 1 × Set of the Installation kit (brackets and fasteners) 1 x Carbon filter 1 × User Manual 3.3 OPTIONAL ACCESSORIES... -
Page 9: Installation
P a g e 4 INSTALLATION 4.1 INSTALLATION WARNINGS Before starting the installation, please refer to the Safety Information section. Always switch the power off prior to beginning the installation. Ensure to handle appliance carefully as stainless steel can be easily damaged during installation. -
Page 10: Positioning The Rangehood
P a g e | 10 • Jigsaw • Ladder 4.3 POSITIONING THE RANGEHOOD IMPORTANT: The height of the rangehood underside must be a minimum of 600mm to a maximum 800mm from the top of your cooktop surface (for gas cooktops this is the top of the gas burner). - Page 11 P a g e | 11 only a reference and the most suitable way of ventilation shall be decided by professional installer. DUCTED INSTALLATION Before beginning the installation of your rangehood, consider your ducting method. This rangehood has been supplied with expandable plastic ducting, however for maximum performance we recommend installing with rigid or semi rigid ducting.
-
Page 12: Cabinet Installation
P a g e | 12 RECIRCULATING INSTALLATION We recommend ducting your rangehood wherever possible, for the maximum performance, however this rangehood can be operated in recirculating mode. You will need to purchase the relevant Carbon Filter accessory which is available for purchase from our Customer Service Team. - Page 13 P a g e | 13 NOTE: • These steps should be operated by 2 persons. • The clips cannot be too near by the cutting edge. Or it may cause a fall risk. WARNING: Failure to install the screws or fixing device in accordance with these instructions may result in electrical hazards.
-
Page 14: Using Rangehood
P a g e | 14 5 USING RANGEHOOD 5.1 CONTROL Your Undermount Rangehood features electronic switch controls (Figure A). Figure A On/Off button It’s used for turning on/off the fan. Speed plus button For increasing the speed of the fan Speed decrease button For decreasing the speed of the fan. -
Page 15: Care And Maintenance
P a g e | 15 6 CARE AND MAINTENANCE Proper cleaning and maintenance of this rangehood will ensure long fault free operation. CAUTION: Before maintenance or cleaning is carried out, the rangehood should be disconnected from the main power supply. Ensure that the cooker hood is switched off at the wall socket and the plug removed. -
Page 16: Stainless Steel Surfaces
P a g e | 16 6.2 STAINLESS STEEL SURFACES Clean stainless-steel surfaces using non-abrasive cleaning products that are specifically designed to be used on stainless steel. To ensure best results, use an even pressure and follow the grain of the stainless steel. Use of a soft cloth reduces the risk of scratching. If the cloth is wet, ensure that a dry soft cloth is also used to wipe down the surface afterwards to reduce the risk of any surface rust appearing. -
Page 17: Troubleshooting
P a g e | 17 7 TROUBLESHOOTING Before calling the customer services, please check that the appliance is correctly connected. Any of the following cases are not covered by the warranty: Damage caused by improper use, storage or maintenance ... - Page 18 P a g e | 18 Check that your rangehood has Ducting is loose, kinked, too been ducted correctly and in long or too many bends. accordance with the installation instructions. IMPORTANT: If your appliance appears to be operating incorrectly, then you should disconnect it from your electrical supply and then contact Customer Service.
-
Page 19: Technical Specifications
P a g e | 19 8 TECHNICAL SPECIFICATIONS TR913B52 SPECIFICATIONS Model TR913B52 Dimensions 520mm × 295mm × 308mm (W × D × H) Cut-out 485mm × 265mm Dimensions (W × D) Extraction 750 cbm/h Control Touch Control Panel with Remote Control... -
Page 20: Disposal
P a g e | 20 9 DISPOSAL This appliance requires special waste disposal. For further information regarding the treatment, recovery and recycling of this product please contact your local council household waste disposal service or the store of purchase. The packaging materials are recyclable. -
Page 21: Customer Care
P a g e | 21 10 CUSTOMER CARE Please be advised that without the proof of purchase, your warranty may not be valid, keep the receipt. For your convenience, please record: STORE DETAILS STORE NAME ADDRESS TELEPHONE PURCHASE DATE PRODUCT DETAILS MODEL NO.
