Cirris 3300 Series
User Manual
for 3300 & 3350 Testers

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3300 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Cirris 3300 Series

  • Page 1 Cirris 3300 Series User Manual for 3300 & 3350 Testers...
  • Page 2: Table Of Contents

    9.2 Dielectric Withstand Test..... . 17 9.3 Insulation Resistance Test ..... 17 Cirris 3300 Series User Manual...
  • Page 3: Help/Support

    1. Help/Support Cirris 3300 Series testers will help ensure the quality of your cables. The tester will safely check electrical connections in your device for accuracy in minimal time. For assistance with your Cirris test system, you may: ● Visit www.cirris.com/learning-center to read articles on Cirris software and other testing subjects.
  • Page 4: Safety

    Intended Use Your 3300 Series tester is intended to be used indoors at a temperature of 50 to 104 degrees Fahrenheit (10 to 40 degrees Celsius). Best performance can be obtained at a relative humidity of less than 70%. Insulation Resistance measurements will degrade at over 70% relative humidity.
  • Page 5: Medical Warning

    A child or individual wearing a cardiac pacemaker, an insulin pump, or any electronic controlled medical device should NOT perform high voltage testing. Manual Handling Before lifting or carrying the tester, Cirris recommends removing all wires and cables from the front connectors. Be sure the power cord is unplugged when moving the tester. User Precautions Cirris provides safety switches and other tools to keep operators safe during high voltage testing.
  • Page 6: Hardware Overview

    3. Hardware Overview You should have received: ● Cirris 3300 Low Voltage or 3350 High Voltage Cable Tester ● Power cord ● PC (USB B) cable ● Probe ● USB flash drive containing software/documentation Note: If you ordered a training cable, the cable will be included along with a training guide.
  • Page 7 1. Digital I/O Port 2. Printer Port 3. PC Port (USB B) 4. USB Port (USB A) 5. Probe Port 6. Power Cord Port 7. Power Light Indicator 8. Power Switch Hardware Overview...
  • Page 8: Fixturing

    ● The other senses voltage (referred to as “sense”) For the purpose of four-wire testing using the 3300 Series, test points are considered either Type 1 (T1) or Type 2 (T2) points. Each four-wire pair from the tester must have one of each point. The tester uses T1 points as either force or sense; it uses T2 points as the compliment.
  • Page 9 On a 3300 Series tester, you can tell which type each test point is by probing the point while setting up a Learn. 1. From the Main Menu, press Create New. 2. From the Learn menu, press Learn/Test Settings, then press Components.
  • Page 10: Tester Setup/Main Menu

    ● Version Information: Displays software and hardware version. ● Manage Files: Press to copy or delete test files. ● System Settings: Press to perform a variety of tasks relating to the setup and maintenance of the tester software. Cirris 3300 Series User Manual...
  • Page 11: Test Program Basics

    6. Test Program Basics Create a New Test Program A test program must be created before testing a cable. This is done by attaching a known-good sample cable to the tester, adjusting the test settings, and performing a Learn. The tester will create a list of test instructions based on the specified settings and the Learn.
  • Page 12: Components

    3. In the Save As screen, enter a new name for the test program by selecting the text box next to File. A keyboard will appear on the screen to enter a name for the test program. Press OK to finish and return to the main menu. Cirris 3300 Series User Manual...
  • Page 13: Edit A Test Program

    Edit a Test Program Load an existing test program and select Edit. The options allowed for revision are the same as those explained in the following sections. Components cannot be revised at this point. If you need to revise components, you will need to create a new test program. Note: It is possible to create a test program using a text editor on a computer.
  • Page 14: Start Conditions

    With digital I/O, the tester can start a test based on input from an external switch, such as a foot pedal. The tester can also output information to devices such as LEDs. The digital I/O port is located on the back of the tester. The pinout is as follows: Cirris 3300 Series User Manual...
  • Page 15: Inputs

    Function Function Function Input Switch LV Start Input Switch HV Start Output for Good test Output for Bad test Power + 5 VDC, 100 mA max To use the External Switch input, you must set the tester’s Start Condition to Press Button. Inputs 7.1.1 The 3350 tester has two inputs.
  • Page 16: Low Voltage

    ● The following graphic shows how component LV settings define errors for intended connections if there are com- ponents in the test. This value has no impact on whether an intended connection passes or fails, but does influence whether a failing connection is labeled as High Resistance or Open. Cirris 3300 Series User Manual...
  • Page 17: Intermittents Test

    ● As shown in the graphic below, the Component Resistance value has no impact on the shorts test. Intermittents Test An intermittents test repeatedly performs a low voltage test to give the operator time to catch problems that might be intermittent. The operator can move the cable around to catch intermittent failures such as loose connections.
  • Page 18: High Voltage (Hipot) - 3350 Only

    WARNING! High-Speed Mode with highly capacitive devices can slow testing. Highly capacitive nets may cause over- current failures, meaning the nets will need to be tested individually. This could cause the test to slow down significantly. Cirris 3300 Series User Manual...
  • Page 19: Dielectric Withstand Test

    Dielectric Withstand Test In a Dielectric Withstand test (DW test), a voltage much higher than the normal operating voltage is applied between points on the device-under-test. This ensures the wire insulation can withstand a higher amount of voltage (such as a surge) without failing.
  • Page 20: Run Test

    3. Depending on the chosen start condition, attach a cable or press Start. (The blue bar at the top of the window will prompt which action to take or the current step the test is on.) Cirris 3300 Series User Manual...
  • Page 21: Low Voltage Test

    Low Voltage Test 10.1.1 4. The tester will perform a low voltage test, checking for opens and shorts. For simple cables, this test can take less than a second. Don’t be alarmed if the test passes without ever seeing the Low Voltage testing screen. 5.
  • Page 22: Using The Probe

    Using the Probe 10.1.6 In the test window, probe any point on the attached connector to show information pertaining to the probed point. Release the probe to hide the window. Cirris 3300 Series User Manual...
  • Page 23: Printing

    Printing Options 11.1 Printing options are located within the System Settings menu. Press Configure Reports to setup printing. The 3300 Series testers prints labels and test results using any Zebra Programming Language (ZPL) capable printer. In the Configure Reports menu, you can control the following printing functions: Auto Print on Pass: ●...
  • Page 24 3. Press either Pass Report Template or Fail Report Template. Navigate to where you saved the label file. Select it and press Load. Note: When you select a report, this same report will be used for all test programs until you change the report selection. Cirris 3300 Series User Manual...
  • Page 25: Manage Files

    12. Manage Files All test programs, report templates, and other files can be accessed through the Manage Files menu. From this screen, test programs can be organized into different folders, copied, and deleted. Scrolling: For longer lists, touch the up or down arrows to scroll through the list of folders and test programs.
  • Page 26: Test Program Backup Via Usb Drive

    WARNING! Do not format your drive. Formatting your drive will permanently erase all test programs and test settings. If this happens, you must contact Cirris to make your tester operational again. Test Program Backup via USB Drive 12.2 To back up test programs: 1.
  • Page 27: System Settings

    Update Firmware 13.3 After an update is released, you will be given instructions to visit cirris.com to download the necessary firmware. 1. Download the update from cirris.com onto a USB drive. 2. Insert the USB drive into the tester and select Update Firmware from the System Settings menu.
  • Page 28: Import/Export System

    WARNING! Importing files will delete current files from the tester to which the files are being copied. Make sure to have all test programs and other data saved in a separate location before using Import System. Cirris 3300 Series User Manual...
  • Page 29: Factory Defaults

    14. Factory Defaults The following table lists the settings for the 3300 Series testers and their corresponding factory defaults. Start Conditions Low Voltage Start Start Button High Voltage Start Auto Start HV Auto Start Delay 1.0 S LV Settings Connection Resistance 10.0 ohm...
  • Page 30 Intermittents Settings Setting Delay Components Settings Configure Reports Auto Print on Pass Auto Print on Fail Pass Report Template DefaultPass.prn Fail Report Template DefaultFail.prn Lot ID System Settings Mains Frequency 60 Hz Volume Date MM_DD_YY Time Cirris 3300 Series User Manual...
  • Page 31: Troubleshooting

    15. Troubleshooting Visit www.cirris.com/learning-center for articles on troubleshooting. If you need additional help, contact Cirris Technical Support at techsupport@cirris.com or 1-800-441-9910. ■ A high percentage of tests fail Too many tests failing could be caused by several possibilities. ● Error in the Learned device: If a bad cable (meaning a cable with mistakes or defects) is used as the primary cable to create the test program, then all good cables will fail because they are tested using bad test instructions.
  • Page 32: Appendix A - High Voltage Guidelines (3350 Only)

    IR Settings may be based on any of the following factors: ● Contamination: Consider lowering the IR threshold if your DUT has issues such as fingerprints and mold release. ● Humidity: A humid environment can aggravate the effects of contamination between contacts and affect insulation. Cirris 3300 Series User Manual...
  • Page 33 ■ Duration ● The default setting for this parameter of 0.010 seconds (10 milliseconds) should be adequate to test most cables. A longer duration will increase the total high voltage test time. ● A shorter Duration with a shorter soak time or not having soak time is more likely to fail due to humidity related problems since absorbed moisture may not have time to be “dried out”...
  • Page 34: Appendix B - Interpreting Test Results

    ● This error could also be caused when the tester was charging the net or point given in the error message and the ca- pacitance in the DUT was too high. A limit is in place to ensure safety while testing, so testing is immediately halted when the limit is reached. Cirris 3300 Series User Manual...
  • Page 35 Dielectric Failure Error: ● An arc occurred during the high voltage test of the net or point given in the error message. This error will occur any- time the current exceeds the ‘DW Max Current’ test setting. ● This error most often occurs in pairs – that is two different nets will fail. This generally means that the arc is occurring between these two nets.
  • Page 36: Frequently Asked Questions

    ■ General Maintenance Do not remove the tester cover. Removing the tester cover will void your warranty. The 3300 Series tester contains no inter- nal user serviceable parts. Cleaning or routine maintenance of internal parts should be done at Cirris.
  • Page 37: Repair

    Repair 18.3 Should your tester require repair, contact your Cirris representative for a free estimate. Depending on the extent of the dam- age, you may have to send your tester to Cirris headquarters. Frequently Asked Questions...
  • Page 38: Specifications

    Approximately 3.6 kg (8 lbs) ● Voltage: 50 to 1000 VDC ± 5% ± 5 V ● Resistance: 5 MΩ to 1000 MΩ ± 10% All Cirris products are manufactured in Salt Lake City, Dielectric Withstand Test Utah, United States of America.
  • Page 39 Cirris 3300 Series User Manual Version 2017.1.0 © 2017 Cirris Systems Corporation 401 North 5600 West Salt Lake City, Utah 84116 U.S.A. www.cirris.com...
