- Page 1 INSTALLATION AND OPERATION MANUAL LONG RANGE (LR-II) REPEATER HEAT-TIMER CORP. 059707–00 REV. B...
- Page 2 (4) Consulting an experienced radio/TV technician for assistance. The antenna supplied by Heat-Timer Corporation must be used (gain <= 6dB). It is recommended not to operate the device (transceiver) with persons closer than 20cm to the antenna.
-
Page 3: Table Of Contents
(NOT SUPPLIED) LONG RANGE SENSOR NETWORK INITIAL LR-II REPEATER CONFIGURATION PROGRAMMING THE SYSTEM ID LOCATING THE LR-II REPEATER LOCATING THE LR-II REPEATER IN A BUILDING MOUNTING THE LR-II REPEATER MOUNTING THE LR-II REPEATER TRANSFORMER CONNECTING THE WIRING POWER INPUT WIRING... -
Page 4: Controls, Indicators, And Connections
CONTROLS, INDICATORS, AND CONNECTIONS FIGURE 1 LR-II REPEATER, INDICATORS, AND CONNECTIONS ITEM DESCRIPTION ITEM DESCRIPTION Status Indicators Internal use only • Red LED blinks when transmitting data RS485/Battery Pack Connection • Green LED blinks when receiving data Received Signal Strength Indicator (RSSI) LEDs If both LEDs are blinking, no System ID has •... -
Page 5: Specifications
SPECIFICATIONS LR-II REPEATER Dimensions (W x H x D) 6” x 3 1/8” x 1 ¾” (152.4mm x 79.5mm x 44.5mm) Mounting Locations Wall or Ceiling Mount Temperature Range 32°F to 150°F (0°C to 66°C) Power Input 8Vac Transformer (Supplied) -
Page 6: Installation Instructions
The following materials/tools are required for installation, but are not supplied: • General tool kit (screwdrivers, wire strippers, power drill, etc.) • 18 AWG cable (Heat-Timer P/N 703001–01 or equivalent #18/2 cable)—used for the 8Vac Wireless Repeater input power connection. RECOMMENDED MATERIALS (NOT SUPPLIED) The following device is recommended for installation, but are not supplied: •... -
Page 7: Long Range Sensor Network
For the LR-II Repeaters to function in a wireless sensor system, each LR-II Repeater must communicate with a nearby Long Range Repeater LR-II or with the MSI Hub. Each wireless sensor network should have an unique System ID that enables all wireless sensor network components (MSI Hub, Space Sensors, Repeaters and Wireless Temperature Modules) with that System ID to communicate with each other. -
Page 8: Initial Lr-Ii Repeater Configuration
INITIAL LR-II REPEATER CONFIGURATION For the LR-II Repeater to function in the Wireless Sensor network, each Long Range (LR) Repeater must communicate with another nearby LR Repeater or MSI Hub. Each Wireless Sensor network should have a unique System ID that... - Page 9 INSTALLATION INSTRUCTIONS Observe the RED and GREEN status LEDs (3). When the LEDs stop blinking, the LR-II Repeater has communicated to the MSI Hub and is ready to install. NOTE When properly communicating with the MSI Hub, the RED LED should blink when transmitting data and the GREEN LED should blink when receiving data.
-
Page 10: Programming The System Id
Continue holding the Transmit button until the RED and GREEN LEDs start blinking together. Once this occurs, the System ID has been cleared and the LR-II Repeater is ready to be programmed with a new System ID. HEAT-TIMER CORP. 059707–00 REV. B... - Page 11 INSTALLATION INSTRUCTIONS NOTE To continue the process of Programming a System ID on the LR-II Repeater ensure the MSI Hub has been powered-on and has already been programmed with the System ID. Observe the MSI Hub status LEDs (5). If the status LEDs are not blinking, or are blinking only once every 15 seconds, a System ID has been programmed.
- Page 12 Repeater was not properly clear of the previous System ID and did not communicate with the MSI Hub. Ensure the System ID was properly cleared from the LR-II Repeater as outlined in the above Steps 2 through 7. If the problem persist, contact Heat Timer tech support for assistance.
-
Page 13: Locating The Lr-Ii Repeater
Do not locate the LR-II Repeater in which the signal may be restricted such as a closet. Begin locating the LR-II Repeater on every 7 floors of the building as a general rule of thumb. Some building construction may allow this to be expand to every 9 floors, while some building construction may restrict the location to every 3 to 5 floors. -
Page 14: Locating The Lr-Ii Repeater In A Building
4 LEDs = Great 5 LEDs = Best Ensure there is at minimum 3 Signal Strength Indicators LED's flashing. If not relocate the LR-II Repeater and repeat the above steps. After a location is found that provides an acceptable signal strength, disconnect the 9V MSI Installation Battery Pack from the LR-II Repeater. -
Page 15: Mounting The Lr-Ii Repeater
PROGRAMMING THE SYSTEM ID on page 10 have been completed before continuing. The LR-II Repeater cover should already have been removed. Once an appropriate location to mount the LR-II Repeater has been determine, the LR-II Repeater base ready to be mounted. The LR-II Repeater base is secure in place using the provided screws through the two mounting holes the base. -
Page 16: Mounting The Lr-Ii Repeater Transformer
DO NOT mount the device in a location where it will be exposed to extreme heat, cold, humidity, or moisture. WARNING The 120Vac power wiring for the LR-II Repeater transformer can not be exposed. The transformer and wiring may need to be mounted in a 1900 electrical box. -
Page 17: Connecting The Wiring
DO NOT re-connect electrical power until ALL wiring to the LR-II Repeater is completed. Failure to do so may result in severe personal injury or death. DO NOT share the LR-II Repeater AC power transformer with other devices. This may cause problems with the wireless operation or permanent damage to the equipment. -
Page 18: Attaching Lr-Ii Repeater Indoor Antenna
ATTACHING LR-II REPEATER INDOOR ANTENNA The LR-II Repeater is supplied with a rubberized external antenna that is intended only for indoor use. The antenna can be rotated around a swivel-point to change its direction in order to achieve the best possible signal strength. -
Page 19: Installing The Lr-Ii Repeater Outdoor Antenna (Optional)
Attach one end of the antenna cable to the antenna adapter, and then connect the other end of the cable to the external antenna connector on the LR-II Repeater. Note that an optional surge suppressor can be attached to the end of the cable before connecting to the LR-II Repeater Antenna Socket. -
Page 20: Performing The Icms Configuration
Select SETUP SENSORS/ALARMS from the drop down menu on the left side of the screen. Select the Building/Control name from the drop down menu under CHOOSE BUILDING/CONTROL. Then select CONTINUE in the lower right corner of the screen. HEAT-TIMER CORP. 059707–00 REV. B... - Page 21 Under WIRELESS SENSORS, select ADD TO LIST. Enter the Sensor ID, which is found on the Sensor ID card provided with the LR-II Repeater. The Sensor ID can also be found on the label at the base of the LR Repeater.
-
Page 22: Troubleshooting
SYMPTOM POSSIBLE CAUSE RECOMMENDED ACTION(S) Status LEDs are No power to the LR-II Repeater. Verify the LR-II Repeater is receiving power from not lighting. the AC transformer and all power cables are in good condition and are connected. Refer to: •... -
Page 23: Wireless System Information
17 Sensor ID # 18 Sensor ID # 19 Sensor ID # 20 Sensor ID # 21 Sensor ID # 22 Sensor ID # 23 Sensor ID # 24 Sensor ID # 25 Sensor ID # 059707–00 REV. B HEAT-TIMER CORP. -
Page 24: Notes
NOTES HEAT-TIMER CORP. 059707–00 REV. B... - Page 25 NOTES 059707–00 REV. B HEAT-TIMER CORP.
- Page 26 NOTES HEAT-TIMER CORP. 059707–00 REV. B...
-
Page 27: Warranty
WARRANTIES AND LIMITATIONS OF LIABILITY AND DAMAGE: Heat-Timer Corporation warrants that it will replace, or at its option, repair any Heat-Timer Corporation manufactured product or part thereof which is found to be defective in material workmanship within one year from the date of installation only if the warranty registration has been properly filled out and returned within 30 days of the date of installation. - Page 28 20 NEW DUTCH LANE, FAIRFIELD, NJ 07004 PHONE: 973-575-4004 FAX: 973-575-4052 HEAT-TIMER.COM HEAT-TIMER CORP. 059707–00 REV. B...
