- Page 1 NIMBUS 2 BURNER GAS BBQ INSTRUCTION MANUAL IMPORTANT: Please read these instructions before using the product and retain for future use. HHGL Limited, MK9 1BA V1_2023 HHGL (ROI) Limited, D02 X576...
-
Page 2: General Information
GENERAL INFORMATION Safety and Care Advice IMPORTANT: Please read these instructions fully before starting assembly and using the appliance. WARNING: Whilst every effort has been made in the manufacture of your barbecue to remove any sharp edges, care should be taken in handling to avoid any accidental injury. • Use outdoors only. -
Page 3: Gas & Regulator
GAS & REGULATOR This barbecue can use either propane or butane or propane/butane mixed LPG (liquid petroleum gas) bottled gas. Propane bottles will supply gas all year round, even on cold winter days. Butane bottles will supply sufficient gas in summer, but it may affect the performance of the barbecue and restrict the heat output available from the burners, particularly once the gas temperature starts to fall below +10°C. -
Page 4: Installation
INSTALLATION Selecting a Location This barbecue is for outdoor use only and should be placed in a well-ventilated area, and on a safe and even surface. Never place your barbecue below ground level. Take care to ensure that the barbecue is used on an incombustible floor. - Page 5 • After the rightmost burner is lit, push in and turn the leftmost control knob anti-clockwise until the burner is lit. • Failure to follow this lighting sequence could result in a hazardous situation occurring. • After ignition, the burner should be burned at the high position for 3-5 minutes in order to preheat the barbecue. This process should be done before every cooking session.
-
Page 6: Care And Maintenance
Flare-up Control *Very Important Notice* Flare-ups occur when meat is barbecued and its fat and juices fall upon the hot flame tamer. Smoke of course helps give food its barbecued flavour, but it is best to avoid excessive flare-up to prevent food becoming burned. To control flare-ups, it is ABSOLUTELY ESSENTIAL to trim away excess fat from meat and poultry before grilling;... - Page 7 Even when your barbecue is covered for its protection, it must be inspected on a regular basis, as damp or condensation can form, which may result in damage to the barbecue. It may be necessary to dry the barbecue and the inside of the cover.
- Page 8 A stainless steel cleaner may be used on stainless steel parts if required. Whenever a barbecue is being assembled for the first time, or its burners are being cleaned, make sure each gas valve tip goes into the burner venturi tube completely during the assemble or re-assemble process. burner venturi tube valve...
-
Page 9: Component Parts
Please check you have all the components and fittings listed. If you find any missing or damaged parts, please contact our customer services team on 0333 003 7084 between 09:00 & 18:00, or use the contact form on our website www.homebase.co.uk Part No. Description Illustration... - Page 10 Part No. Description Illustration Quantity Cart - Left side panel assembly Cart - Right side panel assembly Bottom shelf assembly Lower - Front panel Upper - Front panel Foot Wheel...
- Page 11 Please check you have all the components and fittings listed. If you find any missing or damaged parts, please contact our customer services team on 0333 003 7084 between 09:00 & 18:00, or use the contact form on our website www.homebase.co.uk Part No. Description Illustration...
- Page 12 ASSEMBLY INSTRUCTIONS Remove all packaging Step 1 Put the Cart - Left side panel assembly on the Bottom shelf assembly using 12mm bolts Step 2 Put the Cart - Right side panel assembly on the Bottom shelf assembly using 12mm bolts...
- Page 13 Step 3 Put the Lower - Front panel and Upper - Front panel between Cart - Left side panel assembly and Cart - Right side panel assembly using 12mm bolts and nut...
- Page 14 Step 4 Apply the wheels to the front leg and the rear leg of the left cart assembly using the axle Then fix the axle by the axle nuts Step 5 Apply the footer to the leg of Cart - Right side panel assembly and secure the feet with 35mm bolts...
- Page 15 Step 6 Put the Back brace between Cart - Left side panel assembly and Cart - Right side panel assembly using 12mm bolts Step 7 Set the Grill assembly on the assembled grill cart. Secure the Grill assembly with Cart - Left side panel assembly and Cart - Right side panel assembly using 35mm bolts...
- Page 16 Step 8 Apply 8 of the 12mm bolts to left and right side of Grill assembly Have half of the bolt threads go into the bolt holes. Do not tighten the bolts at this stage. Step 9 Align the 12mm bolts properly with the Side burner assembly .
- Page 17 Step 10 Align the 12mm bolts properly with Side table assembly . Hang the Side table assembly to the Grill assembly . Secure the bolts tightly by screwdriver after the alignment is done. Step 11 Align and secure Side burner assembly and Side table assembly using 12mm bolts...
- Page 18 Step 12 Loosen the two pre-assembled screws between the side burner and the Side burner assembly M4 x 8 Bolt Loosen the two pre-assembled screws from the side burner valve bracket on the HVR of the Grill assembly Fix the valve on the side burner control panel using those two screws loosened at procedure B. Valve M4*6 Bolt...
- Page 19 Align the side burner venturi against the valve. Make sure the valve tip goes into the burner venturi completely with good alignment. Then tighten those two screws loosened at procedure A on the side burner after the alignment. Install the side burner electrode wire to the side burner electrode and igniter.
- Page 20 Step 13 Put the Side burner knob on the Side burner assembly Step 14 Put the Side burner grate on the Side burner assembly and align with the holes.
- Page 21 Step 15 Put the Heat tent , Cooking grill and Warming rack on the Grill assembly Step 16 Put the grease cup at the bottom of the Grill assembly...
- Page 22 Step 17 Assembly is complete. ALL JOINTS AND CONNECTIONS MUST NOW BE LEAK TESTED BEFORE USING THE BARBECUE. Leak test annually, and whenever the gas bottle is removed or replaced. Please refer to Leak Testing in pg.4. Always place the gas bottle at the side of the appliance. The gas bottle should be sited as far away from the appliance as possible without straining the hose.
-
Page 23: Technical Specification
TECHNICAL SPECIFICATION Model Number: KS16032 Gas Category: I3+(28-30/37) Type of Gas: (pressure) Propane (37 mbar) Butane (28 - 30 mbar) Pin Number: 0359BU1015/2575DM29973 Injector Size (Main Burner): 0.86mm Injector Size (Side Burner): 0.94mm Total Heat Input: 9.36 kW 2 Burner Heat Input: 5.86 kW Side Burner Heat Input: 3.5 kW... -
Page 24: Troubleshooting
TROUBLESHOOTING Problem Possible Cause Solution Burner will not light LP gas cylinder is empty Replace with full cylinder using the ignition Faulty regulator Have regulator checked or replaced system Obstructions in burner Clean burner Obstructions in gas jets or gas hose Clean jets and gas hose Electrode wire is loose or disconnected Reconnect wire...
