PEERLESS In2ition 76952 Installation Instructions Manual

®
In2ition Installation Instructions
Parts Included
Shower Head
Hand Shower Flexible Hose
Hose Washer
(3)
* WARNING: Plumbing
Codes require that shower
heads and hand showers
provide a small but
continuous flow of water
(trickle) when in" PAUSE"
mode. Because of this
continuous flow, in
certain circumstances
pressure variations in the
water line and /or changes
in the position of the
shower temperature
control handle while in
" PAUSE" mode could
result in dramatic changes
to the temperature of the
water when the shower
head or hand shower is
returned to the" ON"
position.
ALWAYS point the shower
head away from yourself
when returning to the
" ON" position and feel
the water with your hand
before resuming your
shower to ensure the
water flow is not too hot
or too cold. DO NOT
allow children or others
who might not understand
this warning to use the
" PAUSE" function.
Backflow Protection
Your product is not equipped with backflow prevention. In order to make your product backflow compliant, if required by local plumbing code,
a vacuum breaker will need to be added.
10/30/2023
1. Install the Shower Head
2. Install Hand Shower
a. Place the hose washers into the hose nuts on each end
of the hose.
b. Connect one end of the Flexible Hose to the Shower
Head. Connect the other end of the Flexible Hose to
the Hand Shower. All connections should be able to be
made by hand tightening.
c. To change the Hand Shower spray selection, turn the
lever (located on the front of the Hand Shower) left or
right to the desired setting.
Control
Knob
5. Removing the Hand Shower from the Shower Head
a.
76952
X00076952
a. Make sure to turn off water supply before installing the Shower Head.
b. Remove existing Shower Head from Shower Arm.
c. Check to ensure washer is installed in the Shower Head prior to installation on
Shower Arm.
d. Hand tighten the Ball Connector of the Shower Head to the Shower Arm.
Notice: Removal of or tampering with the flow restrictor may result in showerhead
failure and will void the warranty.
3. Insert Hand Shower into Shower Head
a.
b.
4. Changing Modes on the Shower Head
Turn knob on side of Shower Head to change between:
• Shower Head only
• Shower Head and Hand Shower
• Hand Shower only
a. Push the lower part
b.
of the Hand Shower
upwards, away from
the Shower Head,
releasing it from the
Shower Head base
a. Slide Hand Shower
into the base of the
Shower Head.
b. Gently push the
Hand Shower
down into the
Shower Head.
• If the Shower
Head moves when
removing the
Hand Shower,
hand tighten the
connection
between the
Shower Head and
the Shower Arm.
b. Pull the Hand
Shower away from
the slot in the
Shower Head.
76952 Rev. G
