- Page 1 @seeedstudio...
- Page 2 ODYSSEY- X86J4105 User Manual...
- Page 3 Package Contents SATA ODYSSEY - X86J4105 User Manual x1 International Power SATA Cable x 1 Adapter x 1 • ODYSSEY - X86J4105 • User Manual • International Power Adapter Antenna x 2 RTC Battery x1 • SATA Cable • Antenna x2 •...
-
Page 4: Specifications
Specifications Intel® Celeron® J4105 Processor Frequency: 1.5 – 2.5GHz Microchip® ATSAMD21G18 Coprocessor 32-Bit Arm® Cortex® M0+ Intel® UHD Graphics 600 Graphics Frequency: 250 – 750MHz LPDDR4 8GB Memory 64GB eMMC V5.1 Storage Wi-Fi 802.11 a/b/g/n/ac @ 2.4/5 GHz HT160 Wireless Bluetooth®... - Page 5 USB 2.0 Type-A x2 USB 3.1 Type-A x1 USB 3.1 Type-C x1 HDMI2.0a: Up to 4096x2160 @ 60Hz 24bpp Video Interfaces DP1.2a: Up to 4096x2160 @ 60Hz 24bpp M.2(Key B, 2242/2280): SATA III, USB2.0, UIM M.2 (Key M, 2242/2280): PCIe 2.0 ×4 Expansion Slots Micro SD card Socket SIM Card Socket...
-
Page 6: Before You Start
Quick Start with ODYSSEY - X86J4105 Before you Start Make sure you have the following: An external monitor A keyboard and a mouse An HDMI Cable... - Page 7 Attaching External Storage If you have bought the 64GB EMMC storage version of the ODYSSEY - X86J4105, you can skip this step. However, if you need more storage for your needs, feel free to follow this step. There are four methods of adding storage to ODYSSEY - X86J4105 Through M.2 PCIE Connector M.2 PCIE SSD Through M.2 SATA connector...
-
Page 8: Connecting Antennas
Connecting Antennas Insert the two antennas into the two sockets on the ODYSSEY - X86J4105 Note: One antenna is for Wi-Fi and Bluetooth whereas the second antenna is for strong 5G connectivity Connecting to a display 1. There are two ways to connect your ODYSSEY - X86J4105 to an external display Method 1 Method 2 Type-C... - Page 9 Connecting to a keyboard and a mouse Connect your favorite keyboard and mouse to the ODYSSEY - X86J4105 through any of the USB connectors...
- Page 10 Powering up 1. There are two ways to power up your ODYSSEY - X86J4105. Method 1 Use the 12V/2A power adapter (provided) Method 2 Use a USB Type-C Cable (Supports DP) Type-C...
- Page 11 2. Press the power button and you will notice the blue power LED turn on 3. Wait a few seconds until it boots into the operating system. Welcome to ODYSSEY- X86J4105...
-
Page 12: Installing An Operating System
Installing an Operating System ODYSSEY - X86J4105 supports both Windows and Linux operating systems. If you have bought the non EMMC version, you could attach an external storage by following the previous steps and install your desired operating system by creating a bootable USB drive. - Page 13 Step 2 Press the power button and keep pressing F7 key on the keyboard until you see the Boot Manager screen. Step 3 Select the connected USB Drive as the boot drive and press enter Please select boot device: UEFI: Built-in EFI Shell Windows Boot Manager UEFI OS (USBStick 16GB) Enter Setup...
- Page 14 Adding 4G Cellular Connectivity Step 1 Insert a standard SIM Card to the bottom layer of the slot. Step 2 Insert a PCIE 4G module. Note: This module is a must have if you want to use the connected SIM card.
-
Page 15: Pinout Diagram
Pinout diagram Solder pads at the back GND 3.3V 28-Pin Arduino Pinout UART 4-Pin Power switch PWR GND LED+ LED- Digital Analog MOSI Serial MISO Power ODYSSEY- X86J4105 3.3V 40-Pin GPIO GPIO 386 (Raspberry Pi compa�ble) GPIO 387 GPIO 337 GPIO 493 GPIO 492 GPIO 338... - Page 16 Check BIOS settings and enable Wi-Fi and Bluetooth from BIOS. ODYSSEY - X86J4105 doesn’t power up Make sure you use the 12V/2A power adapter provided in the box and check the connection. If you have any further questions, please visit forum.seeedstudio.com or send an email to techsupport@seeed.cc...
