Summary of Contents for Winsen ZP07-MP503
- Page 1 Air-Quality Detection Module Air-Quality Detection Module （Model：ZP07-MP503） User’s Manual Version:1.4 Valid from 2023.3.24 Zhengzhou Winsen Electronics Technology Co., Ltd Web: https://www.winsentech.com Email: sales@winsentech.com...
- Page 2 Air-Quality Detection Module Statement This manual’s copyright belongs to Zhengzhou Winsen Electronics Technology Co., LTD. Without the written permission, any part of this manual shall not be copied, translated, stored in database or retrieval system, also can’t spread through electronic, copying, record ways.
- Page 3 Air-Quality Detection Module ZP07 Air-Quality Detection Module Product Description ZP07 air quality module adopts advanced chip thick film semiconductor gas sensor, which has high sensitivity to formaldehyde, benzene, carbon monoxide, ammonia, hydrogen, alcohol, cigarette smoke, essence and other gases. After aging, debugging, calibration...
- Page 4 Air-Quality Detection Module Sensitivity Characteristics Picture 2: Contrast of the sensitivity in different gases Application of schematic diagram Picture 3: Module application diagram Pin defin ition Table2 Output Signal Table3. Pollution Name Function A output B output Air concentration class Input power - Clean air Slight pollution...
- Page 5 Air-Quality Detection Module Cautions Please do not put the module in organic solvent (include silica gel and other cementing compound), painting, medicament, oils and fuels, high concentration gas etc. Please do not impact or vibrate the module seriously. ...
