Zhengzhou Winsen Electronics Technology Co.,Ltd
www.winsen-sensor.com
Electrochemical Gas
Detection Module
User's Manual V2.0
（Model：ZE03）
Valid from: 2015-12-16
Zhengzhou Winsen Electronics Technology Co., Ltd
Tel: 86-371-67169097/67169670 Fax: 86-371-60932988
Email:
sales@winsensor.com
Leading gas sensing solutions supplier in China!
Advertisement
Table of Contents
Related Manuals for Winsen ZE03
Summary of Contents for Winsen ZE03
- Page 1 Zhengzhou Winsen Electronics Technology Co.,Ltd www.winsen-sensor.com Electrochemical Gas Detection Module User’s Manual V2.0 （Model：ZE03） Valid from: 2015-12-16 Zhengzhou Winsen Electronics Technology Co., Ltd Tel: 86-371-67169097/67169670 Fax: 86-371-60932988 Email: sales@winsensor.com Leading gas sensing solutions supplier in China!
- Page 2 Statement This manual copyright belongs to Zhengzhou Winsen Electronics Technology Co., LTD. Without the written permission, any part of this manual shall not be copied, translated, stored in database or retrieval system, also can’t spread through electronic, copying, record ways.
- Page 3 Electrochemical Detection Module ZE03 ZE03 is a general-purpose and high-performance electrochemical module. It uses three electrodes, electrochemical gas sensor and high-performance micro-processor. By installing different gas sensor, the module could detect relevant gas. It is with built-in temperature sensor to make temperature compensation, which makes it could detect the gas concentration accurately.
- Page 4 Zhengzhou Winsen Electronics Technology Co.,Ltd www.winsen-sensor.com Detection range and signal output stable2. Detection gas Detection 0-25%vol 0-100ppm 0-100ppm 0-20ppm 0-20ppm 0-10ppm 0-20ppm range 1000ppm Decimal point null 1 byte null null 1 byte 1 byte 1 byte 1 byte of serial port Voltage output 0.6-3V...
- Page 5 Zhengzhou Winsen Electronics Technology Co.,Ltd www.winsen-sensor.com 3.Commands 0X78—to change the communicate type (communication type: 0x03 is active upload type, 0x04 is passive upload type) 0x78 Change communication type Start Byte Address Demand Communication Type Checksum Upload 0XFF 0X01 0x78 0x03 0x84 EXP.
- Page 6 Please do not use the modules in strong air convection environment. Please do not expose the modules in high concentration organic gas for a long time. Zhengzhou Winsen Electronics Technology Co., Ltd Add: No.299, Jinsuo Road, National Hi-Tech Zone, Zhengzhou 450001 China...
