Kingpin QFS Series Operation Manual

QUICK FLEX SCREEN
OPERATION GUIDE/BRUKSANVISNING/GEBRAUCHSANWEISUNG/GEBRUIKSAANWIJZING/KÄYTTÖOHJEET
MOUNTING BATCH / MONTERINGSSATS
Screen fabrics 1 pc
Strap, 26 pcs (2 pcs as spare part)
Adjustable foot for middle leg, 1 pc
Spacers, 6 pcs
1:5 ASSEMBLE THE HORIZONTAL TUBES
Screw together the two tube parts for the horizontal tubes (2 x 2 pcs)
2:5 ASSEMBLE THE VERTICAL TUBES
3:5 ASSEMBLE THE FRAME
FOR SERVICE/HUOLTO:
SWEDEN .............................. www.kingpinscreens.com
Horizontal tubes 2 sets x 2 pcs
Vertical tubes 3 sets x 2 pcs
Foot for vertical tubes 2 pcs
Screws for foot, 2 pcs
Screws for middle leg and horizontal
tubes, 6 pcs
Nut for middle leg, 2 pcs
End cap for vertical tubes, 3 pcs
Screw together the two tube parts for the vertical
tubes (3 x 2 pcs)
Attach the foots to two of the vertical tubes.
Attach the adjustable foot to the middle of the
vertical tubes.
Attach the end cap on top of each vertical tube.
Attach the spacers in between the horizontal
and the vertical tubes, in total four spacers.
Attach the four screws, thru the vertical tubes
into the horizontal tubes, on each side,
NORWAY ............................. www.avpartner.no
WWW.KINGPINSCREENS.COM
Operationguide/Bruksanvisning, QFS-series
Published/Utgiven 2024-02
