CAME ECN3F242 Original Instructions

Original instructions
General




1 Safety Instructions
• The assembly, commissioning, modifications and extensions may only
be completed by an experienced electrician!
• Before commencing work, remove the power supply from the device/
installations!
• During the operation of electrical components
– e. g. in the case of a short circuit hot and ionised gases can be
– emitted
– protection covers must not to be removed!
• Pay attention to all local relevant electrical safety regulations!
• Disregard of the safety regulations can cause death, severe injuries or
extensive damage!
• Keep these operating instructions in a safe place for later use!
2 Common Applications
Safety switching device for sensors with 8,2 kOhm


 LED
 LCD display
 "Mode" button

 "Data" button
 Terminals
 Label (with terminal
description)
Before commencing the installation or assembly complete the following
safety precautions:
• Check the voltage data on the label of the switching device.
• Ensure that the device/installations can not be switched on!
• Determine that the power supply is disconnected!
• Separate or cover neighbouring components which are connected to
the power supply!
• Cover the device during assembly!
Foreign particles (e.g. borings from drilling) can damage the device.
• Protect the device with a housing against contamination or aggressive
environments!
Limited protection against accidental contact!
806SS-0060
ECN3F242
