- Page 1 Model HP20-3000E Galvanometer Scanner Instruction Manual SINO-GALVO (JIANGSU) TECHNOLOGY CO., LTD.
- Page 2 Depends on the leading technical advantage in laser industry, with the management idea of People-oriented, Innovation by science and technology, taking customer’s demand as center, Sino-Galvo Technology is looking forward to your visit and cooperation, and committed to contributing for Chinese nationality brand in laser industry.
-
Page 3: Table Of Contents
HP20-3000E Galvanometer Scanner Contents Document Version State ..................- 3 - Chapter 1 Summary of HP20-3000E Scanning System..........- 4 - Chapter 2 Safety Notice ..................- 5 - Chapter 3 HP20-3000E Technical Parameters ............- 6 - Chapter 4 The Galvanometer Structure and Wiring ..........- 7 - 4.1 Scanner Housing .................. -
Page 4: Document Version State
HP20-3000E Galvanometer Scanner Document Version State Version Date Responsible Person Remarks V1.0 2022.06 Ruiguang Jiang V2.0 2022.09 Ruiguang Jiang - 3 -... -
Page 5: Chapter 1 Summary Of Hp20-3000E Scanning System
PDM control mode, and military-grade process and technology. HP20-3000E high power galvanometer scanners have the good running stability，strong anti-interference ability and it can be applied to continuous fiber lasers within 3000W. According to the divergence angle parameters of the laser, the corresponding QBH beam expanding collimator components and quartz field lens can be configured. -
Page 6: Chapter 2 Safety Notice
HP20-3000E Galvanometer Scanner Chapter 2 Safety Notice 1. Please ensure that the QBH collimating mirror and field mirror are completely sealed and in a completely clean state. Dust and other contaminants may cause damage to the lens. 2. Before starting the galvanometer, ensure that the water connection is correct. Water cooling connection adopts water pipe with outer diameter φ6mm and inner diameter φ... -
Page 7: Chapter 3 Hp20-3000E Technical Parameters
HP20-3000E Galvanometer Scanner Chapter 3 HP20-3000E Technical Parameters Precision and Error 850μs Step Response Time(1% of full scale) 1584μs Step Response Time(10% of full scale) ≤448μs Tracking Error Time 99.9% Linearity ＜5mRad Gain Error ＜5mRad Zero Offset ＜0.5mRad Long-term Drift Over 8 Hours ＜40PPM/℃... -
Page 8: Chapter 4 The Galvanometer Structure And Wiring
HP20-3000E Galvanometer Scanner Chapter 4 The Galvanometer Structure and Wiring 4.1 Scanner Housing 4.2 Housing Dimension Drawing - 7 -... -
Page 9: Power Supply Wiring Diagram
HP20-3000E Galvanometer Scanner 4.3 Power Supply Wiring Diagram 4.4 The External Digital Wiring for DB25 Connection - 8 -... -
Page 10: Chapter 5 Self-Checking And Faq
HP20-3000E Galvanometer Scanner Chapter 5 Self-checking and FAQ Before starting up the whole system, please check carefully to confirm whether there is any problems, such as: plug virtual connection or without connection, two mirrors touched with each other, drive board signal input errors, etc. Only after finishing all checking, then you can turn on the power supply. - Page 11 HP20-3000E Galvanometer Scanner If you have any questions, please contact our Technical Services Department: Service consulting hot-line: 400-055-8805 SINO-GALVO (JIANGSU) TECHNOLOGY CO., LTD. Add: Bld. 33, Area D, No. 99, Jing 15th Road, Dingmao New Zone, Zhenjiang, Jiangsu Province, China. 212000 Tel: +86-511-88881750/88881705 E-mail: info@sino-galvo.com...
