- Page 1 MPA4350 MPA4350 DANTE DA1.4 DANTE DA1.4 MPA4700 MPA4700 DANTE DA2.8 DANTE DA2.8 MPA41500 MPA41500 DANTE DA6 DANTE MPA16700 DANTE DA11.2 DANTE...
- Page 2 User manual - MPA / DA series DOP_1815_A...
-
Page 3: Important Safety Instructions
Important Safety Instructions User manual - MPA / DA series Important Safety Instructions The mains plug, the appliance coupler or the mains CAUTION: to reduce the risk of electric shock, do not switch is used as the disconnect device. Either device remove cover (or back). - Page 4 Important Safety Instructions User manual - MPA / DA series Cleaning, Maintenance and Servicing your local waste administration, waste collection company or dealer. Unplug the apparatus from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
-
Page 5: Table Of Contents
Table of Contents User manual - MPA / DA series Table of Contents Important Safety Instructions Table of Contents Introduction Product Highlights MPA / DA series Before You Get Started Front Panel Rear Panel Processing & Signal Flow Processing Details Output Operation 70/100V Presets Operation Interfaces... -
Page 6: Table Of Contents
User manual - MPA / DA series IntelliCloud Web Interface Sidebar Menu | Network Devices GROUPS Edit Groups Assign Groups Gain Delay Settings Menu Device Name Global Preset Library Output Mode (70/100V, Bridge) Network Settings Hotspot Cloud Connect Login Credentials Streaming Services Spotify Apple AirPlay... -
Page 7: Introduction
Introduction User manual - MPA / DA series Dear Customer, Thank you for choosing the MPA / DA series for your sound reinforcement needs. The innovative MPA / DA series is a professional amplifier solution equipped with integrated DSP features and secure remote control capabilities via the cloud. With APEX IntelliCloud, you can conveniently manage your amplifiers remotely from your office environment. -
Page 8: Product Highlights
Product Highlights User manual - MPA / DA series Product Highlights • Class D, DC coupled amplifiers • All models can directly drive low impedance or 70/100V loudspeakers • Intuitive IntelliCloud web interface • Remote management from anywhere in the world •... -
Page 9: Mpa / Da Series
MPA / DA Series User manual - MPA / DA series MPA / DA Series MPA4350 MPA4350 / DA1.4 4 x 350W DANTE / 4 x 350W with 4x4 Dante™ DA1.4 DANTE MPA4700 MPA4700 / DA2.8 4 x 700W DANTE / 4 x 700W with 4x4 Dante™... -
Page 10: Before You Get Started
19-inch rack it can nevertheless be used the packaging. If any items are missing or damaged, free standing. If the unit is installed in a flight-case or contact Arbane Groupe at service@arbane-groupe. in an equipment rack, fix the unit with all four screws com. -
Page 11: Front Panel
Front Panel User manual - MPA / DA series Front Panel Front Panel The front panel features a modern and intuitive design, with a daylight-viewable color OLED display a single rotary encoder for front-panel operation, a physical power switch and ventilation vents. All in- corporated within a compact 1U 19”... -
Page 12: Rear Panel
Rear Panel User manual - MPA / DA series Rear Panel Rear Panel MPA4350 DANTE - 4 channel MPA16700 DANTE - 16 channel IEC connectors accept worldwide operation Balanced analog line inputs are available from 100-240Vac. MPA / DA series must be on terminal block connectors with clearly marked hot (+), cold (-) and ground terminals. - Page 13 Rear Panel User manual - MPA / DA series Terminal block connector for REMOTE applications, EN-54 ready. Standby If you connect the two STBY pins, the amplifier will go into standby. The pins must be connected potential free. You may not apply voltage to them. RELAY Relay If the amplifier is turned off or if a fault is detected, the...
-
Page 14: Processing & Signal Flow
Processing & Signal Flow User manual - MPA / DA series Processing & Signal Flow Processing & Signal Flow The MPA / DA series offers DSP processing in three stages. Speaker specific processing can be provid- ed by a manufacturer and loaded onto a channel using a SPEAKER PRESET. Additionally, users can apply two layers of processing: first, through the USER controls, affecting individual channels, and second, through six GROUP controls, which can affect multiple channels simultaneously. - Page 15 Processing & Signal Flow User manual - MPA / DA series SPEAKER PRESET Processing Features SPEAKER PRESET Processing Features SPEAKER PRESETS are channel-based features that can be loaded onto individual channels using preset files. The user doesn’t have direct access to these controls but can choose to load or clear the speaker preset from a channel.
-
Page 16: Processing Details
End users have the option to select a loudspeaker type from a preset library, eliminating the need to configure parameters manually. These speaker presets are developed by Arbane Groupe and can be uploaded and stored in the amplifier’s speaker preset folders via the WebUI. If necessary, users can further customize processing using the USER controls. -
Page 17: Operation Interfaces
Operation Interfaces User manual - MPA / DA series Operation Interfaces Operation Interfaces A MPA / DA series device can be controlled through either of the following interfaces: IntelliCloud Web Interface The web interface serves as the primary method of operating the amplifier and can be accessed in the following ways: »... -
Page 18: Front Panel Operation
Front Panel Operation User manual - MPA / DA series Front Panel Operation Front Panel Operation While the MPA / DA series is primarily designed for use with its intuitive IntelliCloud web interface, the front panel provides a secondary method of controlling the amplifier’s most important features without the need for network connectivity. -
Page 19: Homepage
Front Panel Operation User manual - MPA / DA series Homepage The homepage displays the most important statuses of the amplifier, including the output level and mute status of all channels, along with the status of the network features. display the current status of the network, cloudconnect and STATUS ICONS hotspot respectively. -
Page 20: Settings
Front Panel Operation User manual - MPA / DA series Settings Menu The settings menu provides access to the audio processing features, global and speaker presets, and network features. Turning the encoder will highlight the selected submenu. To enter the submenu, press the rotary encoder. Select and press the return icon to navigate back one level in the menu and return to the hompage. -
Page 21: Mixer Matrix
Front Panel Operation User manual - MPA / DA series Settings / Audio / Mixer Matrix Each of the MPA / DA series channels has its own mixer matrix, allowing you to create a custom mix of input signals for every channel. You can access the mixing matrix through the front panel by navigating to Settings >... -
Page 22: Delay
Front Panel Operation User manual - MPA / DA series Settings / Audio / Delay Each output channel of the MPA / DA series can have a delay of up to 250 ms inserted by the user. Note: the total delay of 250 ms per channel is shared between the user delay and group delay. You can access the user delay function through the front panel by navigating to Settings >... -
Page 23: X-Over
Front Panel Operation User manual - MPA / DA series Settings / Audio / X-Over The MPA / DA series provides a crossover with both a high-pass filter (HPF) and low-pass filter (LPF) for every channel. You can access this function through the front panel by navigating to Settings > Audio > X-Over. -
Page 24: Limiter
Front Panel Operation User manual - MPA / DA series Settings / Audio / Limiter Each of the MPA / DA series channels can potentially have four active limiters, two of which are the user RMS and Peak limiters. They are accessible from the front panel via Settings > Audio > Lim. The user can choose to manually set the limiters or have the MPA / DA series calculate a safe setting for the specific speaker connected to the channel. -
Page 25: Presets
Front Panel Operation User manual - MPA / DA series Settings / Presets Menu The MPA / DA series amplifier features two types of preset libraries: Global and Speaker Presets. For further details, please refer to pages 16, 52 (global) and 59 (speaker) in this manual. Access the Global and Speaker Presets from the front panel via Settings >... -
Page 26: Hotspot
Front Panel Operation User manual - MPA / DA series Settings / Hotspot Each MPA / DA series amplifier features a Hotspot, enabling users to control the amplifier using any mobile device (smartphone, tablet, or laptop) without needing access to the local network to which the amplifier is connected through its port. -
Page 27: Network
Front Panel Operation User manual - MPA / DA series Settings / Network The Network menu gives access to the IP setting of the MPA / DA series which can be set from the front panel by navigating to Settings > Network. Connect via a router Connect the MPA / DA series device’s connector together with a PC to a router. -
Page 28: Notes On Networking
Notes On Networking User manual - MPA / DA series Notes on Networking Providing that the network is properly configured, IntelliCloud is capable of automatically detecting and controlling any MPA / DA series device connected to the network. Please refer to the IntelliCloud documentation for more details on controlling the MPA / DA series remotely. - Page 29 Notes On Networking User manual - MPA / DA series Going wireless Using wireless networks may be challenging, but the key to success is to use good quality rugged wireless access points and to configure them correctly. Configuring an access or router point is not that difficult. There is no requirement to install any software as the computer’s web browser is sufficient (all access points have a built-in web-server).
-
Page 30: Intellicloud Web Interface
IntelliCloud WebUI User manual - MPA / DA series IntelliCloud Web Interface IntelliCloud Web Interface The primary mode of operating a MPA / DA series amplifier is through the user-friendly IntelliCloud interface. This fully web-based software is hosted by the MPA / DA series amplifier itslef and can be accessed by any device with a browser. -
Page 31: Accessing The Web Ui
IntelliCloud WebUI User manual - MPA / DA series Accessing the Web UI To access the IntelliCloud interface, you need to establish a connection between your device and the amplifier’s server. This can be accomplished using one of the methods outlined below. For more information, please refer to the Web UI / Settings / Network section of this manual. -
Page 32: Login
IntelliCloud WebUI User manual - MPA / DA series Login When connection has been established, the interface will prompt you for the login and password. By default, both are set to: admin You can change these credidentials via the web interface > Settings > Network •... -
Page 33: User Homepage
IntelliCloud WebUI User manual - MPA / DA series Homepage | USER Processing After logging in, the Homepage will be displayed. This is where you have an overview of all the channels and can access the various submenus. USER The image below displays the homepage for the 4 channel models. The top section allows you to navigate submenus, mute and select channels. -
Page 34: Delay
IntelliCloud WebUI User manual - MPA / DA series menu contains all channel-based processing options available to the user. The Mixer, USER PEQ, X-Over, Limiter, and Speaker menus pertain to individual channels; ensure you have the correct channel selected. The Gain and Delay menus display controls for all channels simultaneously. Gain Limiter Preset loaded on... -
Page 35: Mixer Matrix
IntelliCloud WebUI User manual - MPA / DA series USER / Mixer Matrix The Mixer matrix enables users to route and blend input signals for each individual channel. Within its side menu, you can rename channels and access the internal signal generator. Select the channel you want to control Select the Mixer submenu All faders can be operated in five different ways:... -
Page 36: Gain
IntelliCloud WebUI User manual - MPA / DA series USER / Gain The Gain submenu show the master input faders for every channels. This is where you will control the volume for each amplifier output. Note: the gain values can be offset if the channel is assinged to a with gain settings other then unity (0.0 dB). - Page 37 IntelliCloud WebUI User manual - MPA / DA series USER / Delay The Delay submenu enables users to set a delay time for each channel, ranging from 0 to 250 ms, with increments of 0.1 ms. The limit of 250 ms is shared between the delay.
- Page 38 IntelliCloud WebUI User manual - MPA / DA series USER / PEQ The MPA / DA series offers 12 bands of EQ per channel, with a wide variation of filter types to USER choose from. Select the channel you want to control Select the PEQ submenu Drag EQ nodes The ALL tab provides an overview of all 12 band settings...
- Page 39 IntelliCloud WebUI User manual - MPA / DA series Tap a filter band for detailed control, which can be particularly useful when using tablets or phones. The tab will turn green when its filter is activated, and the selected tab will be outlined in blue. Use the three value boxes to enter the data by sliding the fader, clicking the - and + buttons for small increments or entering the data in the input filed.
- Page 40 IntelliCloud WebUI User manual - MPA / DA series Both the PEQ and the X-Over charts offer features to enhance usability and provide feedback. The active nodes on the chart can be moved by dragging them with your finger or mouse. Lock horizontal movement of the notes in order to avoid changing the frequency.
- Page 41 IntelliCloud WebUI User manual - MPA / DA series USER / X-Over The MPA / DA series amplifier provides both a high-pass and a low-pass filters in its user interface. These filters offer a choice of 19 different classic X-over filter types, including Bessel, Butterworth, and Linkwitz Riley, with slopes ranging from 6 to 48 dB/octave.
-
Page 42: Limiter
IntelliCloud WebUI User manual - MPA / DA series USER / Limiter To protect the connected loudspeakers from damage, each MPA / DA series channel is equipped with a dual-stage Limiter that includes an RMS stage which responds to the signal’s average power, and a Peak stage designed to react to fast signal spikes and transients. - Page 43 IntelliCloud WebUI User manual - MPA / DA series Clicking the calculator icon opens a window where you can calculate appropriate starting values for your limiter. This calculation is based on the impedance and the maximum output wattage of your speaker and the high-pass filter settings from the crossover menu.
-
Page 44: Speaker Preset
IntelliCloud WebUI User manual - MPA / DA series USER / Speaker Preset Library The MPA / DA series provides a feature to load pre-made processing presets onto each channel, specifically designed to apply speaker-specific settings. These presets can be created using the speaker preset creator or can be supplied by speaker manufacturers. -
Page 45: Sidebar Menu | Network Devices
IntelliCloud WebUI User manual - MPA / DA series Sidebar Menu | Network Devices The sidebar menu grands access to the network devices and the GROUP processing. Click the Sidebar button to exand it The sidebar displays the currently connected device as the “Local device,” and it lists other MPA / DA series™️ amplifiers in the network as “Network devices.”... -
Page 46: Groups
IntelliCloud WebUI User manual - MPA / DA series Click to open the menu. GROUPS The amplifier’s custom name and IP adress. Click the info icon to display a popup window containing the amplifier details and its status. The model is also displayed in the CP Icon. Small versions of the output meters which turn red when a limiter is active, providing an overview of the output activity in the network. -
Page 47: Edit Groups
IntelliCloud WebUI User manual - MPA / DA series Edit Groups The first thing you want to do is give your groups a custom name. This is done in the Edit Group menu. With the sidebar expanded, click Click on Edit Groups to access the page where you can to open the menu. -
Page 48: Assign Groups
IntelliCloud WebUI User manual - MPA / DA series Assign Groups Next, you’ll want to assign the channels to one or multiple groups. You can easily do this using the routing matrix in the Group Assign menu. Click on Assign Groups to show the routing matrix. Click on the amplifier headers to show their channels in the matrix. -
Page 49: Gain
IntelliCloud WebUI User manual - MPA / DA series GROUP / Gain You are now ready to start using the processing. GROUP First in the chain is the Gain. Be sure to select the GROUP correct group at the bottom of the screen first. Click Gain to access the gain contols. -
Page 50: Peq
IntelliCloud WebUI User manual - MPA / DA series GROUP / PEQ PEQ enables you to apply an additional layer of EQ processing to all the channels assigned GROUP to the group. If a single channel is assigned to multiple groups, it will undergo processing from all the PEQs of those groups. -
Page 51: Settings Menu
IntelliCloud WebUI User manual - MPA / DA series Web UI / Settings Menu To access the MPA / DA series™️ settings menu, click on the gear icon located in the interface’s header. This will open a new page with various setting tabs. Click on the Gear icon in the interface’s header to open the settings menu. -
Page 52: Global Preset Library
IntelliCloud WebUI User manual - MPA / DA series Web UI / Settings / Global Presets Library Global Preset files contains all audio DSP settings of every channels of the amplifier, including: parameters. USER GROUP SPEAKER PRESET They do not contain any other settings found in the settings menu such as: Output operation and configuration (100V HPF, bridge mode), network settings and streaming account details. -
Page 53: Output Mode (70/100V, Bridge)
IntelliCloud WebUI User manual - MPA / DA series Web UI / Settings / Output Mode In the output window, you have the option to configure channel bridging for both A-B (1-2) and C-D (3-4) on the 4-channel MPA4350 and MPA4700 models. When the bridge mode is enabled, refer to the diagram below for the correct wiring configuration of the output terminals. -
Page 54: Network Settings
IntelliCloud WebUI User manual - MPA / DA series Web UI / Settings / Network In the network tab, you can access all network-related settings, including the device’s LAN, hotspot and cloud settings, and login credentials. The LAN section gives control over the amplifiers IP configuration. In DHCP mode, an IP address will be automatically displayed when a connection is established with the router. -
Page 55: Cloud Connect
IntelliCloud WebUI User manual - MPA / DA series Every MPA / DA series™️ amplifier is equipped with a Cloud feature. This feature enables users to remotely manage the amplifier via the internet. To enable this, the CONTROL port (on the rear side of the amplifier) must be connect- ed to a router with an internet connection. -
Page 56: Streaming Services
IntelliCloud WebUI User manual - MPA / DA series Web UI / Settings / Stream Services MPA / DA series™️ is the first amplifier in its class with an integrated audio source and streaming capability, allowing easy streaming of background music from devices running apps such as Spotify or AirPlay. -
Page 57: Apple Airplay
IntelliCloud WebUI User manual - MPA / DA series AirPlay streaming can be enabled and customized. Ensure that your mobile device is connected to the same network as your MPA / DA series™️ device. Airplay name This is the name that will be displayed on your devices. Password Optionally, you can set a password to prevent unauthorized individuals from connecting to the MPA /... -
Page 58: Firmware Update
IntelliCloud WebUI User manual - MPA / DA series Web UI / Settings / Firmware Update Updating the firmware can conveniently be done through the web interface. Firmware updates will be available when new features are implemented. Please note that you need to restart the amplifier manually to complete the process. To update the firmware: 1. -
Page 59: Speaker Preset Creator
IntelliCloud WebUI User manual - MPA / DA series Speaker Preset Creator The web interface hosts its own Preset Creator software for designing speaker presets. To access this feature, simply add “/preset.html” after the IP address in the URL. For instance: http://192.168.0.10/preset.html Access to this preset creator page can be secured with an OEM code if necessary. -
Page 60: Speaker Preset Library
IntelliCloud WebUI User manual - MPA / DA series After designing a preset, it can be stored in the speaker preset library and optionally protected with an OEM code. Our presets are included with the amplifier upon shipping or made available on Active Audio and APG website. -
Page 61: Oem Configuration
IntelliCloud WebUI User manual - MPA / DA series OEM Configuration To secure the speaker creator and avoid incorrect presets from being loaded, an OEM code can be set in the OEM Config window. To reach this page, add “/oem.html” after the IP address in the URL. For example: http://192.168.0.10/oem.html To set up an OEM configuration: •... -
Page 62: Application Examples
Application Examples User manual - MPA / DA series Application Examples Application Examples In this bar example, the two rooms are each equipped with their own speaker system comprising of a bar zone with ceiling mount loudspeakers and a dancing area with a stereo set of full range loudspeakers. Each of the systems is able to play any of the selected analog sources. - Page 63 Application Examples User manual - MPA / DA series In this restaurant example, the four rooms are each equipped with their own speaker system comprising of a bar zone with full range loudspeakers, a Karaoke area with a small PA system, a restaurant with ceiling loudspeakers and the rest rooms, also equipped with ceiling loudspeakers.
-
Page 64: Specifications
Specifications User manual - MPA / DA series Specifications 4 Channel Models Specifications 4 Channel Models Operating conditions Temperature 0° to 50° C, 10 to 60 % non-condensing Storage temperature -20° to 70° C Safety / Compliance CE Certificate Amplification and power supply Amplification class Class D GlidePath technology Power supply model... - Page 65 Specifications User manual - MPA / DA series User processing functions per channel Gain: -80 to +15dB, 0,1dB steps Polarity: Normal / inverted Delay: 0 to 250 ms (Shared between User and Group settings) PEQ: 12 x PEQ. Each PEQ can be set to a choice of 16 filter types (1) HP/LP filters: Bessel , Butterworth and Linkwitz Riley with slopes from 6 to 48 dB/oct Limiter:...
- Page 66 Specifications User manual - MPA / DA series Amplifier model MPA4350 MPA4700 MPA41500 Total burst power (all channels driven) 1400 2800 6000 2 ohms (with correct limiter setup) 1500 4 ohms 1500 8 ohms 1500 16 ohms 1000 Hi-Z 70V 1500 Hi-Z 100V 1500...
- Page 67 Specifications User manual - MPA / DA series Specifications MPA16700 DANTE Specifications MPA16700 DANTE Operating conditions Temperature 0° to 50° C, 10 to 60 % non-condensing Storage temperature -20° to 70° C Safety / Compliance CE Certificate Amplification and power supply Amplification class Class D GlidePath technology Power supply model...
- Page 68 Specifications User manual - MPA / DA series User processing functions per channel Gain: -80 to +15dB, 0,1dB steps Polarity: Normal / inverted Delay: 0 to 250 ms (Shared between User and Group settings) PEQ: 12 x PEQ. Each PEQ can be set to a choice of 16 filter types (1) HP/LP filters: Bessel , Butterworth and Linkwitz Riley with slopes from 6 to 48 dB/oct Limiter:...
- Page 69 Specifications User manual - MPA / DA series Amplifier model MPA16700 DANTE Total burst power (all channels driven) 11200 2 ohms (with correct limiter setup) 4 ohms 8 ohms 16 ohms Hi-Z 70V Hi-Z 100V Max Output Power bridged mode 4 ohms 1200W 8 ohms...
-
Page 70: Warranty
User manual - MPA / DA series Arbane Groupe 8 Rue Johannes Gutenberg - 44340 Bouguenais- France Tél : 02.40.46.66.64 www.apg.audio DOP_1815_A...
