- Page 1 USER MANUAL AML Gutter Frame Walker MP61040070 sales@alliedmedical.co.nz | www.alliedmedical.co.nz | 0800 31 61 81...
-
Page 2: Parts Of The Product
Parts of the product: Lever Steel net Braking cable Rear wheel Plastic tray Screw Steel basket Handle tube Front wheel Arm support Seat Handgrip Warranty: 1 year for main frame only, not including any consuming parts( wheels, brakes, and so on…) - Page 3 Intended purposes Walking Aid: including Walkers and Rollators, an all- or partially-wheeled mobility aid in the form of a waist-high framework with handgrips and four or three legs designed to provide a stable support to a person with a disability, a geriatric or an infirm person when standing or ambulating;...
-
Page 4: Limitation Of Liability
Limitation of liability: Maxhealth Corporation accepts no liability for damage arising from: Non-compliance with the User Manual Incorrect use Natural wear and tear Incorrect assembly or set-up by the purchaser or a third party Technical modifications The usage of unapproved 3rd party accessories instead of a tested and approved accessories Unauthorized modifications and/or use of unsuitable spare parts A written authorization of Maxx Corporation must be obtained before installing... - Page 5 Use the basket only to transport objects and do not overload it! Max. load: 5.0 kg Use on escalators and the like is expressly prohibited! The push handles must always be adjusted parallel to the direction of movement – risk of tipping! Do not hang any bags on the handle –...
- Page 6 Height adjustment of handles Insert the tube of the adjustable handgrip into the frame at least to the “MAX” marking. Adjusting the forearm supports Loosen the locking lever beneath the armrest by turning it anticlockwise. The brake handle can now be pushed until the ideal setting is achieved.
- Page 7 Adjusting the brakes If braking is poor or too hard, the brake can be adjusted either at the brake housing above or using the adjusting screw on the Bowden cable below) to achieve the desired braking effect. The brake is correctly adjusted when the brake lever as well as the brake wires is free of play and the wheels can be rotated without grinding noises when the brake is released.
-
Page 8: Specification Sheet
Sitting Place the rollator on an even and solid surface. Then apply the brakes. The rollator must be stable and may not slip. Only sit upright; do not lean backwards Seated position permitted only as shown and against the direction of movement. Folding To fold up the rollator, open the folding guard, pull the seat and rollator upwards!
