Summary of Contents for MEMUP MEDIADISK DIAMOND
- Page 1 User Guide User Guide User Guide Mediadisk Mediadisk DIAMOND DIAMOND...
-
Page 2: Table Of Contents
USER GUIDE SAFETY AND OTHER INSTRUCTIONS REMARKS PRODUCT VIEW REMOTE CONTROL CONNECTION INTERFACE BROWSER FILE MANAGER SEARCH PROCESS SETUP MENU SPECIFICATIONS TROUBLESHOOTING... -
Page 3: Safety And Other Instructions
Mediadisk Diamond is a Home Media Center, with a built-in 3.5” HDD. It plays High Definition multimedia files (movies, audios and photos). SAFETY AND OTHER INSTRUCTIONS Please use MEDIADISK DIAMOND carefully and read following instructions. >>> Copyright >>> Water / Moisture... -
Page 4: Remarks
“movie” and then place the corresponding file into each folder. 2. Plug AC adapter 3. Press [Power] on remote control, the Mediadisk Diamond will switch on as the LED will turn on 4. Press [TV] on remote control to check output 5. -
Page 5: Remote Control
REMOTE CONTROL FUNCTION Stand by, power ON/OFF Audio mute key Enter settings on media Switch language track Change subtitle when playing movie Display information of the title Press to go to main menu Exit to menu or return to previous window Switch the output mode Safely remove external USB device Volume up/down... -
Page 6: Connection
CONNECTION Computer connection The MEDIADISK DIAMOND is also a personal multimedia files storage device and can be used with a computer. Connect the MEDIADISK DIAMOND to a computer with the USB cable, then, copy and transfer data. See above picture and connect the device to computer accordingly. - Page 7 HDMI is a output with best audio and video effect. Connect HDMI cable to the output of the MEDIADISK DIAMOND. Select HDMI mode on TV and the Mediadisk Diamond output with [TV system] of the remote control. Digital audio device connection Connect the coaxial connector with the audio device by coaxial cable.
- Page 8 USB host Once an USB device is connected, select folders in menu “Explorer” to display the content. 2 in 1 Card Reader Once a memory card is connected, select folders in menu “Card” to display the content. It only accepts SD HC and MMC cards.
-
Page 9: Interface
INTERFACE Main interface Video Browse all your video content. Photo Browse all your photo content. Audio Browse all your audio content. File Manager Copy from one device to another with intuitive interface. Setup Change your settings. - 7 -... -
Page 10: Browser
BROWSER Press or to select media. Choose from Video, Photo and Audio. Press “Return” to go to previous list. Once you selected your media, you can chose device by pressing on remote control and select “HDD”, “USB” and “Card”. Browsing Movies ... - Page 11 Display all files according to a preview All Movies List all films content included in Mediadisk Diamond BD/DVD List all virtual DVD / BD included in Mediadisk Diamond Go to folder Enter File Manager to find files Name Display by ascending sort...
- Page 12 Browsing Photo and press button to play the file you want in Photos menu. Only Photo files will be displayed under “Photo” Menu. Other media files such as Video or Audio files won’t be displayed in this menu. Options: You can set your photo content by pressing button on photo browser:...
- Page 13 Options during slideshow: During slideshow, you can access to different settings by pressing [option]. Slide timing Set to Off, 2 sec., 5 sec., 10 sec. or 30 sec. Slide transition You have 9 different transition effects Play order Set to Off, repeat all and shuffle loop Background music Open/close current music Define background music as required...
- Page 14 Display all files according to a thumbnail List Display all files according to a list Preview Display all files according to a preview All songs Display all music the Mediadisk Diamond include Album Access to music by album Artists Access to music by artist Genre...
-
Page 15: File Manager
FILE MANAGER (COPY/PASTE & DELETE) Access to the File Manager interface on main menu, it allows copying or deleting files between HDD, USB and card reader. Copying operation Choose File Manager icon and press the green button (operations) to begin handling your files. You’ll be able to copy, delete, move, rename and multiple selection. -
Page 16: Search Process
After copying some files, go to “Copy Destination” as below Then press and the copy interface will run. After processing, you’ll get a “success” or “failure” message. SEARCH PROCESS For whether Video, Photos and Music, you are able to easily search files in “option” mode Select letters or numbers included in your title, use shortcuts to move, delete, switch uppercase letters, symbols or phonetic notation. -
Page 17: Setup Menu
SETUP MENU Go to Setup menu on welcome screen. Press or to switch between setup mode. It concerns System, Audio, Video and MISC configuration. - 15 -... - Page 18 System Setup Menu language Set display language Text encoding Set font code language Time Manual or time zone settings R/RW auto-play External DVD driver auto play on/off Screen saver Timing setup before screen saver MiniKBD Language Choose language as default Scan storage Auto scan, scan off and resume scan Resume play...
- Page 19 To upgrade your system: 1/ Get the latest firmware on www.memup.com: download and unzip file (you will get an .img file) 2/ Copy the .img file to root directory of your USB key, plug your USB key and start system 3/ Enter System menu then enter the setup menu 4/ Go to USB upgrade.
-
Page 20: Specifications
SPECIFICATIONS CONTENT FORMAT SUPPORTED: Video: Codecs: H.264 (AVC HD), H.263, VC-1 (WMV HD), MPEG 1/2/4, Xvid, RV8, RV9 Formats: MKV, AVI, MP4, MPG, WMV, DAT, VOB, MOV, ISO, FLV, ASF, MJPEG, TP, TS, TRP, M2TS, SWF, RM/RMVB Subtitles support: SRT, SMI, SUB, ASS, SSA, IDX+SUB format ... -
Page 21: Troubleshooting
3. The MEDIADISK DIAMOND can’t read my video files ? MEDIADISK DIAMOND chipset can’t read some files due to new codecs, even some firmware couldn’t correct, reading files are mentioned on giftbox and in “specifications” part. Some will be added and available in www.memup.com...
