- Page 1 Cassini Turntable Cassini Turntable Instruction Manual Plato Giradiscos CASSINI Manual de instrucciones 卡西尼唱片机使用说明书 カッシーニ・ターンテーブル」です取扱説明書 Platine tourne-disque CASSINI Manuel d'instructions CASSINI Plattenspieler Bedienungsanleitung AR-PH68 www.ARKROCKET.com...
-
Page 2: Safety Instructions
Safety Instructions Top View Back View Setting Up Your Turntable 3.1 Installing The Platter And Turntable Mat 3.2 Install Dust Cover 3.3 Attaching And Adjusting The Counterweight Using Your Turntable 4.1.Before playing a record 4.2. Turntable Operation 4.3 Bluetooth Operation 4.4 Bluetooth Trasmitter Operation 4.5 AUX-IN Operation Needle Replacement... - Page 3 Read and understand this entire manual before using this product. Keep these instruc- tions for future reference. Do not use this product near water. This product should be operated only by the type of power source indicated on the marking label or in this instruction manual. Do not defeat the safety purpose of the polarized plug.
-
Page 4: Product Overview
Product overview 2.1 Top view 2.2 Back View K L M ITEM DESCRIPTION Turntable Platter Aluminum Alloy Turntable Counter Weight Turn To Adjust The Needle Pressure Turn To Select The Record Type (33 or45) Speed Of Your RPM Selector Switch Turntable Tone Arm Lifter Push Forward And Pull Back To Raise And Lower Tone Arm... - Page 5 ITEM DESCRIPTION Tone Arm Hole The Stylus That Produces Sound From The Record Function Control Turn The Control To Select BT/Line In/Phone/BT Transmitter Turn The Control To Power ON/OFF Unit And Control Dial Power/Volume Control To Adjust The Volume Phone Mode: RED Light Solid Bluetooth Mode:Blue Light Quickly Flash Indicator Light Bluetooth Pairring:Blue Light Solid...
- Page 6 Silica gel feet Turntable Metal Dust cover platter Belt Counterwight 5. Carefully remover the tape. Too much force will damage the cover and stylus. 5. Carefully remover the tape. Too much force will damage the cover and stylus. 5. Carefully remover the tape. Too much force will damage the cover and stylus. Tape EN-5...
- Page 7 Installing the platter and turntable mat platter and turntable mat Note: The belt is pre-installed on the bo om of the metal pla er. installed on the bo om of the metal pla er. Turn the platter over and check the belt position Make sure that the drive belt is looped in the middle of the circle.The drive belt located too high or too low in this circle may cause the drive belt to fall off...
- Page 8 2. Still holding the belt, flip the platter over, then insert the platter onto the spindle in the center of your turntable. 3. Align the round hole in the platter with the pulley and use your finger to hook the belt onto the pulley.
- Page 9 Cartridge Tracking Force Adjustment The supplied Counterweight is suitable for cartrides weighing between 3.0-6.0g Tracking Force Dial Center Line 1. Gently push and turn the counterweight onto the rear of the tonearm(with the dial facing toward the front of the turntable) 2.Hold the counterweight with the black number ring on the counterweight you, and then slightly push the counterweight into the end of tone arm.
-
Page 10: Turntable Operation
Playing a Record CAREFUL! 4.1.Before playing a record 4.1.1 Pull the protector straight forward to remove it. NOTE: Applying a downward force may cause the stylus to come off the body. Only low volume is output if the stylus has come off, or is about to Protector come off, so refer to “Replacing the stylus”to reattach the stylus correctlu. -
Page 11: Aux-In Operation
4.3.3. Once your media device is successfully paired with the turntable, the turntable will play a short confirmation sound 4.3.4. Play and stream music from your media device to the turntable. The indicator light will become solid. Note:Bluetooth version:5.0 4.4 Bluetooth Trasmitter Operation 4.4.1. - Page 12 5.Needle Replacement Removing Needle 1. Gently pull down the front edge of the needle. 2. Pull needle forward. 3. Pull out and remove. Installing Needle 1. Position the needle with its tip facing down. 2. Line up the back of the needle with the cartridge. 3.
- Page 13 PH68-DWT JL5.1 4 INCH 2 X 20W lid closed H119 X W 448 X D351MM lid open H180 X W 448 X D351MM 9.05kg AR-N60 Stylus Model EN-12...
