modway EEI-6135 Assembly Instructions Manual page 2

Read through all of
the instructions
before starting
Approx. 60 minutes
assembly time
2 people recommended
for assembly
Furniture components:
1 Le Panel
2 Right Panel
3 Back Bottom Panel
4 Back Top Panel
5 Front Side Base Panel
6 Back Side Base Panel
Side Base Panel
7
Provided hardware:
A Cam Bolt M6 x 35mm
B Wood Dowel M8 x 30mm
C Cam Lock M15
D Allen Bolt M6 x 25mm
E Allen Bolt M6 x 30mm
Allen Key
F
G
Quadro Drawer Channel
H Leveler M6 x 20mm
I Screw M4.5 x 16mm
Missing parts or hardware? Need assistance?
Contact us before returning your item. We're here to help!
609.256.9000 • cs@modway.com
Care instructions are
listed in the last step
of this manual
Make sure you have all
parts and components
before discarding any
packing materials
Base Top Panel
x1 8
Front Panel
x1 9
x1 10
Drawer Front Panel
x1
11 Drawer
x1
x1
x2
What you need:
x17
x30
Phillips
x17
x6
x5
x1
x2
x4
x6
Only use hand tools to assemble this item. Do not use power tools.
Do not tighten bolts or screws completely until all hardware is lined up
and inserted into the holes.
Do not over-tighten screws and bolts to avoid stripping the hardware
or cracking the item.
For vanity and plumbing installation, we suggest hiring a professional
contractor and plumber.
you're assembling the product.
Keep all components and packaging out of reach of children or animals
x1
x1
x1
1
x1
Phillips Head Screwdriver
4
9
11
3
10
8
6
7
7
5
You may also need:
+ Power Drill
+ Level
+ Silicone Adhesive or Caulk
+ Drywall Anchors and Screws
+ Other Wall-Mounting Hardware
PAGE 2 OF 10
