CR-MF3
CR-MF3
SATEL
CR-MF3
MIFARE proximity card reader
Full manual is available on
to our website and download the manual.
The CR-MF3 reader can operate as:
 proximity card reader in the INTEGRA alarm system,
 proximity card reader in the ACCO access control system,
 proximity card reader in systems of other manufacturers,
 standalone door control module.
Before you mount the reader, program the settings required for the selected operating mode
in the CR SOFT program. The exception is a reader that is to operate in the ACCO NET
system and is to be connected to the ACCO-KP2 controller using the RS-485 bus (OSDP
protocol). The OSDP protocol is supported by the ACCO-KP2 controllers with firmware
version 1.01 (or newer). In that case, you can program the required settings in the
ACCO Soft program (version 1.9 or newer).

Installation

The device should be installed by qualified personnel.
Prior to installation, please read the full manual.
Disconnect power before making any electrical connections.
1. Open the reader enclosure.
2. Connect the reader to the computer. Use the USB / RS-485 converter (e.g. ACCO-USB
by SATEL). Follow the instructions in the converter manual.
Do not connect more than 24 access control devices with the MIFARE card reader
(CR-MF5 and CR-MF3) to the converter. The CR SOFT program may not be able to
support more devices correctly.
3. Program the reader in the CR SOFT program.
3.1. Create a new project or open an existing project.
3.2. Establish connection between the program and the device.
3.3. Program the settings and upload them to the reader.
4. Disconnect the reader from the computer.
5. Run the cables to where you want to install the reader. To connect the RS-485 bus,
we recommend using a UTP cable (unshielded twisted pair). To make other connections,
use unshielded straight-through cables.
SATEL
CR-MF3
MIFARE proximity card reader
Full manual is available on
to our website and download the manual.
The CR-MF3 reader can operate as:
 proximity card reader in the INTEGRA alarm system,
 proximity card reader in the ACCO access control system,
 proximity card reader in systems of other manufacturers,
 standalone door control module.
Before you mount the reader, program the settings required for the selected operating mode
in the CR SOFT program. The exception is a reader that is to operate in the ACCO NET
system and is to be connected to the ACCO-KP2 controller using the RS-485 bus (OSDP
protocol). The OSDP protocol is supported by the ACCO-KP2 controllers with firmware
version 1.01 (or newer). In that case, you can program the required settings in the
ACCO Soft program (version 1.9 or newer).
Installation
The device should be installed by qualified personnel.
Prior to installation, please read the full manual.
Disconnect power before making any electrical connections.
1. Open the reader enclosure.
2. Connect the reader to the computer. Use the USB / RS-485 converter (e.g. ACCO-USB
by SATEL). Follow the instructions in the converter manual.
Do not connect more than 24 access control devices with the MIFARE card reader
(CR-MF5 and CR-MF3) to the converter. The CR SOFT program may not be able to
support more devices correctly.
3. Program the reader in the CR SOFT program.
3.1. Create a new project or open an existing project.
3.2. Establish connection between the program and the device.
3.3. Program the settings and upload them to the reader.
4. Disconnect the reader from the computer.
5. Run the cables to where you want to install the reader. To connect the RS-485 bus,
we recommend using a UTP cable (unshielded twisted pair). To make other connections,
use unshielded straight-through cables.
Quick installation guide
www.satel.pl
. Scan the QR code to go
Quick installation guide
www.satel.pl
. Scan the QR code to go
