- Page 1 User Manual NBT Carplay MMI BOX...
-
Page 2: Specifications
Specifications Panel description For power cable connection, CAN data transmission CAN Power Antenna Wifi antenna connector USB Camera USB data transmission, and for reverse/front camera conenction LVDS OUT Connect with cable labelled ‘LVDS-GPBMW1901-NBT’ LVDS IN Connect with OEM LVDS from the screen Toggle switch Refer DIP code setting to set for different screen size 360 IN... - Page 3 Accessories AV/USB cable LVDS cable LVDS- WIFI antenna AV-USB-GP68 NBT-C19 CAN power cable CAN-NBT-C19 MIC adapter cable (Note:This cable isn’t for bmw i3/i8, longer for i3/i8) MIC-22C-DZ...
- Page 4 Compatible car model NBT car system interface Series Car model Production year Toggle switch F20,F21 2012-2016 2014-2016 F30/F31/F34 2013-2015 NBT MINI F32/F33/F36 2014-2016 F10/F11/F07 2013-2015 F12/F13 2013-2016 F01/F02 2013-2016 2013-2016 NBT i3/ i8 6.5 inch: 2014-2016 11000000 2014-2016 2015-2016 8.8/10.25 inch: 2014-2016 MINI 11100000...
-
Page 5: Connection Diagram
Connection Diagram... -
Page 6: Automatic Transmission
Reverse camera wirng connection and settings Automatic transmission camera' 1. Connect the reverse camera to CVBS OUT labeled 'Reverse 2. Connect the cable labeled '12V reverse camera(yellow)' to c amera power 3. Setting → Reverse → Reverse camera → Aftermarket... - Page 7 Munal transmission 1. Connect the reverse camera to CVBS OUT labeled 'Reverse camera' 2. Setting → Reverse → Reverse camera → Aftermarket...
- Page 8 Wireless carplay connection 1. Turn on WIFI (Fig.1) 2. Turn on Bluetooth (Fig.2), and connect Carplays bluetooth (Fig 3/4) . 3. After the bluetooth connection is completed he following prompts will pop up, click 'Allow Use carplay ‘ (Fig.5/ 6)
- Page 9 Wireless Android auto connection 1. Turn on WIFI (Fig.1) 2. Turn on Bluetooth (Fig.2) 3. Enter the Wireless Dev APP (Fig.3 ) 4. Search the bluetooth of phone (Fig.4 /5/ 6) 5. Choose any one of the options on the car end to pair (Fig.7) 6.
- Page 10 Wired Android auto connection . Download Android auto APP on Android phone(Fig.1). 2. Click 'WireAuto, icon(Fig.2), the prompt 'Please connect your Android device' will pop up(Fig.3). 3 Plug your phone to USB port. then it will enter Android auto automatically(Fig.4). ①...
- Page 11 Wireless Airplay connection 1. Click 'Airplay' icon first (Fig.1), the pairing information with the phone will be displayed (Fig.2) 2.Search wifi signal of Airplay and conenct 3. Turn on Airplay (Fig3/4) Note: If you have connected Carplay before, please disconnect Carplay wifi first. Wired Autolink connection 1.
- Page 12 Original buttons Operation Button Function Remarks CarPlay System switching Long press the button for MENU 3 seconds AppleCar Play Function Go Back Press the button short time Google Android Auto Back You can use this Function when you get Restart Press the button for 5 seconds in trouble AppleCar Play Function...
-
Page 13: Setting Instruction
Setting instruction:... - Page 16 1. Q: What need to be paid attention to during installation? A: 1) Make sure that the carplay box is compatible with the installed model, and check whether the label of box matches with the car model. 2) Power off during installation 3) After the installation is complete, it is best to lock the car for a few minutes to turn it on, wait until the running test is normal, then restore the car.
- Page 17 4. Q:My car has OEM microphone, but it can’t work, what can I do? A: Please use the following cable to connect to OEM microphone. 1)Connect A to C 2)Unplug blue connectors and place mic tap cable in between the connector with microphone on it and the main wiring harness coming from the roof.(B/D need to be connected) OEM MIC Q:I don’t have OEM microphone, how to connect external microphone?
- Page 18 6.Q: Solutions to not being able to connect with carplay ？ A: can try to use the solutions below separately or together 1) Click on carplay bluetooth or wifi on the mobile phone 2) At the same time, clear the Bluetooth devices on the mobile phone and the car, and then pair and connect 3) Go to WirelessDev to reset the Bluetooth, and then pair and (Fig.1) ②...
- Page 19 7. Q:When I call someone, he can hear himself, how to do? ① A:1) Adjust the volume of the original car to normal use 2) Turn the volume in ’audio‘ setting to 13(Fig.1) 3) Turn the ’Microphone Volume‘ to 12 4) 'Microphone OP' tune from 0 until no echo is heard 5) Adjust 'AEC quality' to 2 6) If the caller hears the echo interval for a long time, fine-tune the 'Microphone delay...
