- Page 1 User Manual EVO Carplay MMI BOX Apple CarPlay Android Auto...
-
Page 2: Specifications
Specifications Panel description CAN Power For power cable connection, CAN data transmission Antenna Wifi antenna connecton USB data transmission, and for reverse/front camera conenction USB Camera LVDS OUT ‘Connect with cable labelled ‘LVDS-GPBMW1901-NBT LVDS IN Connect with OEM LVDS from the screen Toggle switch Refer DIP code setting to set for different screen size (Exterior 360 input(VGA signal input... - Page 3 Accessories LVDS cable WIFI antenna AV/USB cable CAN power cable (Note:This cable isn’t for bmw i3/i8, longer MIC adapter cable usb to AUX audio cable for i3/i8)
- Page 4 Compatible car model BMW-EVO Model configuration table-matching model system distinction diagram ID 5 MANUFACURE SERIES SYSTEM Toggle Switch MODEL YEAR SCREENSIZE Main car models 1series F20,F21 16-20 6.5/8.8 EVO(ID5\ID6) 2series 16-20 6.5/8.8 EVO(ID5\ID6) 3series F30/F31/F34 17-20 6.5/8.8/10.25 EVO(ID5\ID6) 4series F32/F33/F36 16-20 EVO(ID5\ID6) 5series F10/F11/F07 17-20...
-
Page 5: Connection Diagram
Connection Diagram:... - Page 6 Reverse camera wirng connection and settings Automatic transmission 1. Connect the reverse camera to CVBS OUT labeled 'Reverse camera' 2. Connect the cable labeled '12V reverse camera(yellow)' to c amera power 3. Setting → Reverse → Reverse camera → Aftermarket...
- Page 7 Munal transmission 1. Connect the reverse camera to CVBS OUT labeled 'Reverse camera' 2. Setting → Reverse → Reverse camera → Aftermarket...
- Page 8 Wireless carplay connection Turn on WIFI (Fig.1) Turn on Bluetooth (Fig.2), and connect Carplay's bluetooth (Fig.3/4) After the bluetooth connection is completed, the following prompts will pop up, click 'Allow-Use carplay' (Fig.5/6)
- Page 9 Wireless Android auto connection 1. Turn on WIFI (Fig.1) 2. Turn on Bluetooth (Fig.2) 3. Enter the Wireless Dev APP (Fig.3 ) 4. Search the bluetooth of phone (Fig. 4 / 5 /6) 5. Choose any one of the options on the car end to pair (Fig .7) 6.
- Page 10 Wired Android auto connection 2. Click 'WireAuto' icon(Fig.2), the prompt 'Please connect your Android device' will pop up(Fig.3). 3. Plug your phone to USB port. then it will enter Android auto automatically(Fig.4). ① ② ④ Plug the phone to USB port ③...
- Page 11 Wireless Airplay connection 1. Click 'Airplay' icon first (Fig.1), the pairing information with the phone will be displayed (Fig.2) 2.Search wifi signal of Airplay and conenct 3. Turn on Airplay (Fig3/4) Note: If you have connected Carplay before, please disconnect Carplay wifi first. Wired Autolink connection 1.
- Page 12 Original buttons Function Operation Button Remarks System Long press the button for CarPlay MENU switching seconds 3 Apple Car Play Function Press the button short time Go back Google Android Auto Back You can use this function when you get Press the button 5 seconds Restart in trouble...
-
Page 13: Setting Instruction
Setting instruction:... - Page 16 1.Q: What need to be paid attention to during installation? A: 1) Make sure that the carplay box is compatible with the installed model, and check whether the label of box matches with the car model. 2) Power off during installation. 3) After the installation is complete, it is best...
- Page 17 4.Q:My car has OEM microphone, but it can’t work, what can I do? A: Please use the following cable to connect to OEM microphone. 1)Connect A to C 2)Unplug blue connectors and place mic tap cable in between the connector with microphone on it and the main wiring harness coming from the roof.(B/D need to be connected) OEM MIC Q:I don’t have OEM microphone, how to connect external microphone?
- Page 18 6. Q: Solutions to not being able to connect with carplay？ A: can try to use the solutions below separately or together ) Click on carplay bluetooth or wifi on the mobile phone At the same time, clear the Bluetooth devices on the mobile phone and the car, and then pair and connect Go to WirelessDev to reset the Bluetooth, and then pair and (Fig.1) ②...
- Page 19 . Q:When I call someone, he can hear himself, how to do? A:1) Adjust the volume of the original car to normal use. Turn the volume in ’audio‘ setting to 13(Fig.1) ① 3) Turn the ’Microphone Volume‘ to 12 4) 'Microphone OP' tune from 0 until no echo is heard 5) Adjust...
