- Page 1 DEU-2700 D 2000-Series User Manual DEU-2700 D Digital-Emergency-Unit ® Page 1 ©2023 by AUDEMO-SYSTEMS , Schatzbogen 62, 81829 München...
-
Page 2: Table Of Contents
DEU-2700 D 2000-Series Index 1. General .......................... 3 Symbols and Important Notes .................. 3 2. Safety Instructions ....................... 4 Please Note: ......................5 3. Technical Features ......................6 4. Operational Controls ....................... 7 Front Panel: ......................7 Rear Panel: ......................8 5. -
Page 3: General
DEU-2700 D 2000-Series 1. General This operation manual includes important notes on safe operation of the unit. Please read all instructions and safety regulations. Keep these instructions for future reference. Take care that the operation manual is available to all users. Our products are subject to continuous development. -
Page 4: Safety Instructions
Do not open or modify the unit. Opening of the security protected united for servicing, repair and so on is only allowed ® by the service department of AUDEMO SYSTEMS . Interventions to the unit and breaking the seals will invalidate the warranty agreement! -
Page 5: Please Note
DEU-2700 D 2000-Series Please Note: DANGER! Caution! Risk of electric shock of dangerous volt- Risk of Fire caused by False Polarity age within the units enclosure Wrong installation of batteries could destroy them! Within the units enclosure there are uninsulated Take care of correct polarity while changing or parts with height electric tension. -
Page 6: Technical Features
DEU-2700 D 2000-Series 3. Technical Features ® The PADES 2000 Digital Emergency Unit DEU-2700 D enables a standard-compliant (ac- cording to EN 54-4), permanent emergency power supply of 24 V DC consumers in the event of a power failure. The 19 inch device (2U) is equipped with a battery extension module and two digital charging modules. -
Page 7: Operational Controls
DEU-2700 D 2000-Series 4. Operational Controls Front Panel: BAT (FAIL) The LED BATT “FAIL” is illuminated yellow if there is any failure (Battery Fault). BAT (LOW) The LED BATT “LOW” is illuminated yellow if the battery is low. (Charging/Battery). CTRL (OK) The LED CTRL OK is illuminated green if the Controller ist OK. -
Page 8: Rear Panel
DEU-2700 D 2000-Series Rear Panel: Mains Plug Input Power connection to 230 V AC mains. Note the information of the schematic diagram. Connection for Battery-Set To connect up to 2 x DEU-2771 A battery-set 24V/100Ah. Connection Emergency Power for the Amplifier To connect up to 6 amplifiers of the DAA-series. -
Page 9: Connections And Additional Possibilities
DEU-2700 D 2000-Series 5. Connections and additional Possibilities The Digital-Emergency-unit is equipped individually on consumers request at the factory. Please note all information of the schematic diagram. Connection of the batteries Take care of correct polarity while changing or servicing the batteries! DANGER! Avoid short circuits! Use isolated tools only! The screwing of the cable-connections must be fixed with 0.12 –... -
Page 10: Options
DEU-2700 D 2000-Series 6. Options Order number Description Max. extension per unit DEU-2700 D Digital-Emergency-Unit DEU-2750 A Battery-Temperature-Sensor DEU-2789 A HF-Shielding-Module DMS-2098 A Special-Legend for System DPU-2686 A System-Mains-Connecting-Cable All options could only be assembled ex works. All components of the electroacoustic system could only be delivered referring to a project. -
Page 11: Specifications
DEU-2700 D 2000-Series 7. Specifications Digital-Emergency-Unit (DEU-2700 D) Moduleinbauplätze Energieversorgung 220-240 V AC, 50 Hz Leistungsaufnahme max. 350 W Nennspannung 24 V DC Ladestrom 15 A Summen-Eingangsstrom je Battery- 100 A max. Akkukapazität des Lademoduls max. 200 Ah (2x100Ah) Ladeschlussspannung 27.3 V typisch bei 20°C Schaltausgänge Abmessungen (B ×... -
Page 12: Environment Protection
DEU-2700 D 2000-Series 8. Environment Protection Note: In any case of replacement, the substituted unit is taken back from the manufac- turer. Dispose of Batteries The batteries should not been thrown away or been burned under no cir- cumstances! They must be disposed according to local rules about special waste.
