- Page 2 1.Installation Precautions Please follow the equipment installation steps process to Flow chart of installation steps: The definition of each interface must be clear during the Schematic diagram of battery interface: ensure the equipment can be successfully installed. installation process, otherwise the wrong connection will lead to installation failure or even damage to the equipment.
- Page 3 2.Check the packing list Please refer to the packing items shown below, please check the packing list carefully, if any items are missing, please contact your dealer directly. Power cable 3 Power cable 1 Power cable 2 Battery Black/1000mm Black/180mm Red/180mm CAN communication Power cable 4...
- Page 4 3.Tool preparation Step 1: Protective equipment products must be worn and maintained during the installation process. Safety gloves Safety glasses Safety shoes Step 2: Installation Tools: tools needed in the process of installing equipment, are more effective to improve installation efficiency. Phillips screwdriver Torque screwdriver Hammer...
- Page 5 4.Battery pack installation Before you start connecting cables, make sure that the inverter and battery are entirely switched off! Ensure no water source above or near the battery, including downspouts, sprinklers, or faucets. The area of the grounding cable shall be prepared at least 6mm , using a ground screw and terminal to connect the ground cable which can ground the battery.
- Page 6 5.Power and communication cable connection Use power cable 1 to connect the negative pole (P- terminal) of battery A to the negative pole (P- terminal) of battery B, and use power cable 2 to connect the positive Step 1: Power connections between two batteries pole (P+ terminal) of battery A to the positive pole (P+ terminal) of battery B.
- Page 7 6. Equipment debugging Step 1: Primary dial setting: DIP address is (1:ON, 2-4:OFF), the battery factory default settings are the master mode and don’t need to be changed. Step2: Subordinate DIP setting: Dip address is #1-#4 , #5 need to be dipped OFF. NOTE: The battery directly connected to the inverter is the primary and the rest are subordinates.
- Page 8 Step 4: Inverter Protocol Selection: The battery default factory CAN communication is Hanchu ESS protocol and RS485 communication is SRNE protocol. Protocol selection: 1) Check which protocols are supported by the inverter. 2) If the inverter supports the battery factory default protocol, select the corresponding protocol on the inverter directly.
