NZ TFS650 & TFS1000

FREE-STANDING SOLID FUEL BURNER

Installation Instructions

and User Guide (NZ)

630738_0

Need help?

Do you have a question about the NZ TFS650 and is the answer not in the manual?

Questions and answers

Summary of Contents for Escea NZ TFS650

Page 1 NZ TFS650 & TFS1000 FREE-STANDING SOLID FUEL BURNER Installation Instructions and User Guide (NZ) 630738_0...
Page 2 WARRANT Y REPAIR AND ANNUAL SERVICING Please contact Escea if you require warranty work. Warranty repair work must be carried out by a recognised Escea woodfire installer. It is recommended that recognised Escea Wood Fire Installers are also used to carry out annual servicing requirements (particularly during the warranty period).
Page 3 CONTENTS A Safety Information B Product Details C Installation Process D Woodfire Operation E Maintenance & Servicing F Troubleshooting G General Warranty Terms & Conditions H Service History & Data Plate...
Page 4 In HaZaRDouS ConDITIonS. WHERE SuCH WaRnInG: THIS aPPlIanCE anD aCTIon IS ConSIDERED, THE DISTRIBuToR: FluE SYSTEM MuST BE InSTallED In ESCEa lTD SHoulD BE ConSulTED aT THE aCCoRDanCE WITH aS/nZS 2918:2001 anD FIRST InSTanCE. THE aPPRoPRIaTE REQuIREMEnTS oF anY RElEVanT loCal/naTIonal BuIlDInG CoDES.
Page 5 CauTIon: CRaCKED anD BRoKEn CauTIon: THE uSE oF SoME TYPES oF CoMPonEnTS. E.G. GlaSS PanElS, MaY PRESERVaTIVE-TREaTED WooD aS FuEl Can REnDER THIS InSTallaTIon unSaFE. BE HaZaRDouS. CauTIon: THIS aPPlIanCE SHoulD noT BE ͳ Your appliance requires periodic maintenance oPERaTED WITH CRaCKED GlaSS. and cleaning.
Page 6 TFS650 and the TFS1000. These are designed to be paired with the corresponding fireplace. Dimensions for each fireplace and plinth options are available in the following pages. For more detail, view architectural drawings at www.escea.com TFS650 Fire Dimensions: 650mm...
Page 7 TFS1000 Fire Dimensions: 200mm 150mm COMBUSTION FLUE PIPE AIR INLET PIPE ISOMETRIC VIEW TOP VIEW 988mm 566mm 940mm FRONT VIEW SIDE VIEW Sheetmetal Base 650W Dimensions: 656mm TOP VIEW 648mm FRONT VIEW...
Page 8 Sheetmetal Base 1000W Dimensions: TOP VIEW 994mm FRONT VIEW Plinth 650W Dimensions: 650mm TOP VIEW FRONT VIEW 630738 TFS650-TFS1000 InSTallaTIon Manual nZ...
Page 9 Plinth 1000W Dimensions: 994mm TOP VIEW 884mm FRONT VIEW Plinth 1500W Dimensions: 1500mm TOP VIEW 1350mm FRONT VIEW...
Page 10 B3 Specifications Table TFS650: Fuel Type Softwood Average Particulate Emission (g/kg) 0.89 Overall Average Efficiency 68.3 Maximum Average Heat Output (kW) 8.03 Clean air authorisation number TFS1000: Fuel Type Softwood (Rural only) Average Particulate Emission (g/kg) Overall Average Efficiency Maximum Average Heat Output (kW) 8.77 Clean air authorisation number...
Page 11 SHoulD BE uSED (nEW ZEalanD HoME MoVEMEnT oF CoolInG aIR. HEaTInG aSSoCIaTIon). FaIluRE To FolloW THESE REQuIREMEnTS WIll VoID all WaRRanTY TERMS. ESCEa aCCEPTS no lIaBIlITY FoR IMPRoPER InSTallaTIon oR ConSEQuEnTIal DaMaGES. THIS aPPlIanCE anD ITS CoMPonEnTS aRE DESIGnED To BE InSTallED anD oPERaTED aS a SYSTEM.
Page 12 The floor protector must be continuous and extend fully beneath the fireplace. If there is combustible flooring directly in front of the appliance, the appliance must be installed on one of Escea’s plinths/ bases, or another heat resistant structure of minimum height I (as detailed below).
Page 13 Parallel Position Corner Position 13 13...
Page 14 Height Clearances Flue Clearances A minimum clearance of 25mm between the 250mm liner and any combustible material must be maintained. Note: the Escea ceiling plate must be installed to comply. 25mm minimum 250mm DIA GALVANISED LINER 250mm GALVANISED LINER 25mm...
Page 15 *Note: Safety clearance requirements for the woodfire must be taken into account when setting the floor protector location. Escea requires the plinth/base and floor protector be secured to the floor. Into timber floors secure with 4x M6 bolts or coach screws (minimum), through the pre-drilled holes on the plinth and floor protector (circled below).
Page 16 If installing onto one of the Escea Plinths, drill holes for mounting the fire, as per the schematics below. If installing onto the Escea base, this will not be necessary as the base already has mounting holes in the sheetmetal.
Page 17 Place the appliance on top of the plinth and secure it to the plinth. Use the supplied 4x M8x50 Hex bolts and 4x M8 x 32 washers to bolt through the plinth to the appliance. *Note: Before placing the fire on the plinth, pre-drill 3x 3.3mm dia flue fixing holes on both the fireplace Ø150mm and Ø200mm spigots.
Page 18 PLACE 200mm SPACER HERE MINIMUM 1600mm Place the Escea ceiling plate over the spigots on the fire (folds pointing upwards). The ceiling plate is supplied with the Escea Freestanding Flue Kit. Position the long Ø150mm flue pipe (with the crimped end pointing downwards) into the inner spigot.
Page 19 Secure the ceiling plate on to the ceiling. Use the 4x supplied machine pozi screws and 4x 12mm ceramic spacer. Cut one of the Ø250mm galvanised liners from a length of 1219mm length to match the required liner length. Then connect the 2 pieces of the Ø250mm liners together to create a long liner pipe.
Page 20 Install the back vermiculite panel by tilting the panel and placing the bottom edge of the back panel above the ember air plenum. Carefully push the top of the back panel towards the back wall of the firebox. *Note: Please hold the back panel in place while placing the side panels in place to prevent it from tipping over.
Page 21 Install the left and right side vermiculite panels next by placing the panels on the sides above the firebox base. Carefully push the top of the side panels towards the side walls of the firebox. *Note: Please refer to the diagram below for the correct orientation of the side vermiculite panels during installation to the firebox.
Page 22 Install the bottom vermiculite panel by placing it above the firebox base. Tilt the base panel roughly 30° to fit the panel through the firebox opening. The door will be re-assembled to the product after installing the bottom vermiculite panel. Re-engage the door hinge to the hinge pins to re-attach the door to the product.
Page 23 C4 Flue Installation Any flue system used on this fire must comply and be installed to fully meet the requirements of AS/NZS 2918:2001 Domestic solid fuel burning appliances – Installation. Flue Pipes: The flue system is comprised of the following 150mm diameter stainless steel flue for the exhaust air ͳ...
Page 24 Flue Clearances A minimum clearance of 25mm between the 250mm liner and any combustible material must be maintained. Note: the Escea ceiling plate must be installed to comply. Minimum 250mm clearance from bottom of cone to any chimney material or adjacent...
Page 25 3x stainless steel rivets to secure the spiders to the flue. Place the Escea ceiling plate over the fireplace spigots, folds pointing upwards. Position the long Ø150mm flue pipe (with the crimped end pointing downwards) into the appliance’s inner spigot.
Page 26 Escea Classic Flue Kit: Escea’s woodfire flue system is unique as it draws combustion air from the same pressure zone as the exhaust gases, eliminating downdrafts and ensuring an efficient burn. *Note: The total length of the connected flue pipes must be within the requirements of AS/NZS 2918:2001 Domestic solid fuel burning appliances - Installation.
Page 27 Gaps between Flue Pipes - 25mm Gaps between Flue Pipes - DETAIL A 25mm DETAIL B DETAIL A DETAIL A DETAIL A 27 27...
Page 28 Installation Procedure - Classic Flue Kit: Install partially completed flue system according to the general installation procedures. Place the 150mm cone spacer above the flue system and tighten the nut to hold it in place. Connect the 915mm long, 150mm diameter flue pipe to the existing long flue pipe.
Page 29 Optional Accessory - Escea Designer Flue Shroud: A minimalist shroud can be purchased as an optional accessory to the Escea flue kit, providing a sleek design solution. *Note: The total length of the connected flue pipes must be within the requirements of AS/NZS 2918:2001 Domestic solid fuel burning appliances - Installation.
Page 30 Gaps between Flue Pipes - 25mm DETAIL B Gaps between Flue Pipes - 25mm DETAIL A DETAIL B SCALE 2 : 17 630738 TFS650-TFS1000 InSTallaTIon Manual nZ...
Page 31 Installation Procedure - Escea Designer Flue Kit Install the Escea Classic Flue Kit as per the above instructions. Cut the bottom shroud from the non-crimped end to be above by 100mm from the roof line. Be aware of the roof pitch when cutting the bottom shroud. If required, a cutting template for the flue can be provided showing common roof pitches.
Page 32 Place the bottom shroud around the flue system, on the Ø250 spiders. Position the bottom shroud below the top end of the Ø250mm flue liner by 160mm, as mentioned in Step 2. Drill through the legs of the Ø250 spiders and secure the bottom shroud to these spider legs using 4x SS rivets.
Page 33 Assemble the cone pipe assembly to the 150mm diameter flue pipe. Assemble the cowl to the 150mm diameter flue pipe. Drill through and rivet through the cone pipe, cowl and flue pipe using a minimum of 3x SS rivets. *Note: Ensure a good mechanical seal between the cowl and cone. This is necessary to keep rain out of the flue system.
Page 34 Flue Restraints: The flue above the roof must be restrained as per AS/NZS 2918:2001 Section 4.10 - Fixing Flue Flashing: The rubber flashing, flashing plate and other flashing material used must comply with the relevant building code/ local building regulations. Silicone flashing is the recommended flashing material for both the Classic flue kit and with the Designer Shroud accessory.
Page 35 OPERATION GUIDE WARNING WARNING DO NOT MODIFY THIS APPLIANCE. DO NOT OPERATE YOUR APPLIANCE WITH THE DOOR OPEN OR AJAR. BURN WELL SEASONED WOOD ONLY (LESS THAN 20% MOISTURE). ONLY OPEN THE DOOR WHEN FUELLING/RE-FUELLING YOUR ALWAYS OPERATE THIS APPLIANCE APPLIANCE.
Page 36 D1 First Fires The first fire(s) in your appliance may be difficult to get going and keep going with a lesser amount of heat being generated. This is a result of the moisture being driven out of the vermiculite panels. Allow several hours of hot fires before your appliance will perform optimally.
Page 37 Top – Down Lighting Method (Alternative) Step 4: Lighting a fire can sometimes be difficult. The Light each of the firelighter pieces and close the following method of lighting a fire is one that is door. Wait for when the flames are well established widely practiced in other parts of the world.
Page 38 Can’t get heat out of the appliance? Another problem may be wet or green wood. The typical symptom is sizzling wood and moisture One of two things may have happened. The being driven from the wood. appliance itself has not reached optimum temperature or the flue damper is positioned all the way to the left.
Page 39 D4 Smoke Information A properly installed appliance should not smoke. If Is the smoke flow impeded by too long a ͳ yours does, check the following: horizontal pipe or too many bends? Has the flue had time to get hot? Is it a weak draft perhaps caused by a leaky ͳ...
Page 40 CAUSES: Using incorrect fuel, or small fuel pieces IN CASE OF A CHIMNEY FIRE: ͳ which would normally be used as kindling. Have a well understood plan for evacuation ͳ Leaving the door ajar too long and creating and a place outside for everyone to meet. ͳ...
Page 41 D8 Summary - Do’s and Dont’s DON’T Build a hot fire. Take ash out immediately. Let it accumulate ͳ ͳ to a depth of at least one inch. A good ash Use only dry wood. ͳ layer provides for a longer lasting and better burning fire.
Page 42 An up to date list of authorised sufficient fuel to get the appliance thoroughly dealers can be found at www.escea.com hot, using green or wet wood, or closing the draft DO NOT USE SUBSTITUTE MATERIALS.
Page 43 The appliance is sprayed with Senotherm high temperature paint. If any visual parts become scratched during assembly or servicing, touch up Senotherm paint cans can be purchased from your local Escea dealer. Please ensure that ONLY Senotherm is used during touch ups.
Page 44 E5 Latch Bracket Adjustment Remove stud cover from the latch bracket. Unhook the stud cover from the latch bracket by pulling the stud cover up. Pull the stud cover from the latch bracket to remove it. VIEWED FROM RIGHT SIDE OF THE PRODUCT WITH STUD COVER NO STUD COVER STEP 1: LIFT UP STUD COVER...
Page 45 Loosen 3x M8 bolts (circled below) using a 13mm spanner to free the latch bracket on the right side of the product. Move the latch bracket inwards, towards the product, to ensure a tight seal once the door is re-attached. Tighten the bottom bolt in the new latch position but leave the others loose.
Page 46 E6 Door Angle Adjustment Loosen the 4x M6 nuts and 4x M6 washers (circled below) to free the hinge adjustment plate behind the door. NUTS AND WASHERS HERE Viewed from the back of the door, swing the top of the hinge adjustment plate to the left to adjust the angle of the door.
Page 47 E7 Vermiculite Removal and Replacement Vermiculite panels will have to be removed to gain access to the flue for cleaning and any electrical component maintenance. In the event of vermiculite panels getting damaged over time, the existing panels will also have to be removed and replaced with new panels. Note: please handle the replacement vermiculite panels carefully.
Page 48 Use the previous steps as guide for re-installing vermiculite panels. Tilt panel as required to fit the replacement panels into the firebox. New vermiculite panels are available from your authorised dealer or distributor. An up to date list of authorised dealers can be found at www.escea.com 630738 TFS650-TFS1000 InSTallaTIon Manual nZ...
Page 49 E8 Air Bar Removal & Replacement The air bar will have to be removed to gain access to the flue for cleaning and maintenance. In the event of the air bar getting damaged over time, the air bar removal will be needed for replacement.
Page 50 Use the previous steps as guide for re-installing the air bar . Tilt part as required to fit the replacement air bar into the firebox. New air bar is available from your authorised dealer or distributor. An up to date list of authorised dealers can be found at www.escea.com 630738 TFS650-TFS1000 InSTallaTIon Manual nZ...
Page 51 New ash lips are available from your authorised dealer or distributor. An up to date list of authorised dealers can be found at www.escea.com. 51 51...
Page 52 E10 Back Panel Removal & Replacement Undo 6x M8 bolts to remove the back panel from the product (circled below). 630738 TFS650-TFS1000 InSTallaTIon Manual nZ...
Page 53 Is the door closed? Leave door closed while kindling takes off. • Use top down lighting method • Is an Escea flue system installed? Required for the fireplace to work properly. Smokes when • Ensure the damper is set to high during refueling door is open.
Page 54 Problem Solution The fire leaks • Check door gasket for adequate seal (paper test). Adjust if necessary. through the door Dirty glass • Air control may be closed too far. Open air control more. • Burn hotter, smaller fires. Use well-seasoned wood. •...
Page 55 The warranty applies from the date of purchase from or through an authorised Escea fire dealer. Nature of Warranty Subject to the exclusions in section 2 & 3, Escea undertake to put right any defects in the Escea wood fire products supplied by Escea for the periods specified below: Parts...
Page 56 • This warranty does not cover paint blemishes or imperfections because of the uneven nature of high temperature paint. A spray can of touch up Escea paint is available and can be purchased from your Escea dealer. •...
Page 57 Where you make a claim under this warranty, an authorised repairer may need to attend your premises to inspect the Escea product. Escea may charge you a service call fee if a repairer will be required to travel more than 30 km from the nearest service centre to your location.
Page 58 Escea Distributor Filing a Claim Escea Limited Contact the dealer you purchased the fire from. 17 Carnforth Street Dunedin, 9018, New Zealand Ph 0800 17 3000 www.Escea.com THIS DOCUMENT CONTAINS TECHNICAL DATA SUBJECT TO CHANGE WITHOUT NOTICE. 630738 TFS650-TFS1000 InSTallaTIon Manual nZ...
Page 59 SERVICE HISTORY & DATA PL ATE Service History The appliance must be serviced at least annually and possibly more frequently – dependent on usage. Date Dealer Name Service Technician Service Performed Notes...
