TFS650 & TFS1000

FREE-STANDING SOLID FUEL BURNER

Installation Instructions

and User Guide

630592_1

Table of Contents

Need help?

Do you have a question about the TFS Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Escea TFS Series

Page 1 TFS650 & TFS1000 FREE-STANDING SOLID FUEL BURNER Installation Instructions and User Guide 630592_1...
Page 2 WARRANT Y REPAIR AND ANNUAL SERVICING Please contact Escea if you require warranty work. Warranty repair work must be carried out by a recognised Escea woodfire installer. It is recommended that recognised Escea Wood Fire Installers are also used to carry out annual servicing requirements (particularly during the warranty period).
Page 3: Table Of Contents
CONTENTS A Safety Information B Product Details C Installation Process D Woodfire Operation E Maintenance & Servicing F Troubleshooting G General Warranty Terms & Conditions H Service History & Data Plate...
Page 4: A Safety Information
WITH aS/nZS 2918:2001 anD SPECIFICaTIon oF CoMPonEnTS MaY RESulT THE aPPRoPRIaTE REQuIREMEnTS oF anY In HaZaRDouS ConDITIonS. WHERE SuCH RElEVanT loCal/naTIonal BuIlDInG aCTIon IS ConSIDERED, THE DISTRIBuToR: CoDES. ESCEa lTD SHoulD BE ConSulTED aT THE FIRST InSTanCE. 630592_1 TFS650-TFS1000 InSTallaTIon Manual...
Page 5 CauTIon: CRaCKED anD BRoKEn CauTIon: THE uSE oF SoME TYPES oF CoMPonEnTS. E.G. GlaSS PanElS, MaY PRESERVaTIVE-TREaTED WooD aS FuEl Can REnDER THIS InSTallaTIon unSaFE. BE HaZaRDouS. CauTIon: THIS aPPlIanCE SHoulD noT BE ͳ Your appliance requires periodic maintenance oPERaTED WITH CRaCKED GlaSS. and cleaning.
Page 6: B Product Details
The TFS series is a free-standing wood fire. B2 Product Dimensions The TFS series consists of the TFS650 and TFS1000 fireplace. Plinths are available for purchase to go along with the free-standing woodfire. GRC plinths (Glassfibre-Reinforced Concrete) are available for both TFS650 and TFS1000 products.
Page 7 TFS1000 Fire Dimensions: 200mm 150mm COMBUSTION FLUE PIPE AIR INLET PIPE ISOMETRIC VIEW TOP VIEW 988mm 566mm 940mm FRONT VIEW SIDE VIEW Sheetmetal Base 650W Dimensions: 656mm TOP VIEW 648mm FRONT VIEW...
Page 8 Plinth 650W Dimensions: 650mm TOP VIEW FRONT VIEW Plinth 1000W Dimensions: 994mm TOP VIEW 884mm FRONT VIEW 630592_1 TFS650-TFS1000 InSTallaTIon Manual...
Page 9 Plinth 1500W Dimensions: 1500mm TOP VIEW 1350mm FRONT VIEW B2 Specifications Table TFS650: Fuel Type Hardwood Average Particulate Emission (g/kg) 0.97 Overall Average Efficiency 68.63 Maximum Average Heat Output (kW) 6.75 TFS1000: Fuel Type Hardwood Average Particulate Emission (g/kg) 1.00 Overall Average Efficiency 61.88 Maximum Average Heat Output...
Page 10: C Installation Process
SHoulD BE uSED (aHHa - auSTRalIan MoVEMEnT oF CoolInG aIR. HoME HEaTInG aSSoCIaTIon). FaIluRE To FolloW THESE REQuIREMEnTS WIll VoID all WaRRanTY TERMS. ESCEa aCCEPTS no lIaBIlITY FoR IMPRoPER InSTallaTIon oR ConSEQuEnTIal DaMaGES. THIS aPPlIanCE anD ITS CoMPonEnTS aRE DESIGnED To BE InSTallED anD oPERaTED aS a SYSTEM.
Page 11 If there is combustible flooring directly in front of the appliance, the appliance must be installed on one of Escea’s plinths/ bases, or another heat resistant structure of minimum height H (as detailed below). Additionally, a floor protector of any suitable heat resistant material (eg.
Page 12 Parallel Position Corner Position 630592_1 TFS650-TFS1000 InSTallaTIon Manual...
Page 13 250mm dia galvanised liner. However the material must be no thicker than 20mm. At all other points, a minimum clearance of 25mm between the 250mm liner and any combustible material must be maintained. Note: the Escea ceiling plate must be installed to comply.
Page 14 C3 Appliance Installation Place the floor protector on the floor. Ensure that the floor protector is properly centred to the location of the flue exit hole on the ceiling. Place the plinth or base on the floor protector once the location of floor protector is set. *Note: Safety clearance requirements for the woodfire must be taken into account when setting the floor protector location.
Page 15 If installing onto one of the Escea Plinths, drill holes for mounting the fire, as per the schematics below. If installing onto the Escea base, this will not be necessary as the base already has mounting holes in the sheetmetal.
Page 16 Place the appliance on top of the plinth and secure it to the plinth. Use the supplied 4x M8x50 Hex bolts and 4x M8 x 32 washers to bolt through the plinth to the appliance. *Note: Before placing the fire on the plinth, pre-drill 3x 3.3mm dia flue fixing holes on both the fireplace Ø150mm and Ø200mm spigots.
Page 17 PLACE 200mm SPACER HERE MINIMUM 1600mm Place the Escea ceiling plate over the spigots on the fire (folds pointing upwards). The ceiling plate is supplied with the Escea Freestanding Flue Kit. Position the long Ø150mm flue pipe (with the crimped end pointing downwards) into the inner spigot.
Page 18 Secure the ceiling plate on to the ceiling. Use the 4x supplied machine pozi screws and 4x 12mm ceramic spacer. Cut one of the Ø250mm galvanised liners from a length of 1219mm length to match the required liner length. Then connect the 2 pieces of the Ø250mm liners together to create a long liner pipe.
Page 19 Install the back vermiculite panel by tilting the panel and placing the bottom edge of the back panel above the ember air plenum. Carefully push the top of the back panel towards the back wall of the firebox. *Note: Please hold the back panel in place while placing the side panels in place to prevent it from tipping over.
Page 20 Install the left and right side vermiculite panels next by placing the panels on the sides above the firebox base. Carefully push the top of the side panels towards the side walls of the firebox. *Note: Please refer to the diagram below for the correct orientation of the side vermiculite panels during installation to the firebox.
Page 21 Install the bottom vermiculite panel by placing it above the firebox base. Tilt the base panel roughly 30° to fit the panel through the firebox opening. The door will be re-assembled to the product after installing the bottom vermiculite panel. Re-engage the door hinge to the hinge pins to re-attach the door to the product.
Page 22 C4 Flue Installation Any flue system used on this fire must comply and be installed to fully meet the requirements of AS/NZS 2918:2018 Domestic solid fuel burning appliances – Installation. Flue Pipes: The flue system is comprised of the following 150mm diameter stainless steel flue for the exhaust air ͳ...
Page 23 General Installation Procedure: *Note: The total length of the connected flue pipes must be within the requirements of AS/NZS 2918:2018 Domestic solid fuel burning appliances - Installation. Do not cut any of the flue pipes above the flue cone. For minimum flue dimensions, refer to Flue Size - Minimum Requirements section.
Page 24 Escea Classic Flue Kit: Escea’s woodfire flue system is unique as it draws combustion air from the same pressure zone as the exhaust gases, eliminating downdrafts and ensuring an efficient burn. *Note: The total length of the connected flue pipes must be within the requirements of AS/NZS 2918:2018 Domestic solid fuel burning appliances - Installation.
Page 26 Installation Procedure - Classic Flue Kit: Install partially completed flue system according to the general installation procedures. Place the 150mm cone spacer above the flue system and tighten the nut to hold it in place. Connect the 915mm long, 150mm diameter flue pipe to the existing long flue pipe.
Page 27 Optional Accessory - Escea Designer Flue Shroud: A minimalist shroud can be purchased as an optional accessory to the Escea flue kit, providing a sleek design solution. *Note: The total length of the connected flue pipes must be within the requirements of AS/NZS 2918:2018 Domestic solid fuel burning appliances - Installation.
Page 28 630592_1 TFS650-TFS1000 InSTallaTIon Manual...
Page 29 Installation Procedure - Escea Designer Flue Kit Install the Escea Classic Flue Kit as per the above instructions. Cut the bottom shroud from the non-crimped end to be above by 100mm from the roof line. Be aware of the roof pitch when cutting the bottom shroud. If required, a cutting template for the flue can be provided showing common roof pitches.
Page 30 Place the bottom shroud around the flue system, on the Ø250 spiders. Position the bottom shroud below the top end of the Ø250mm flue liner by 160mm, as mentioned in Step 2. Drill through the legs of the Ø250 spiders and secure the bottom shroud to these spider legs using 4x SS rivets.
Page 31 Assemble the cone pipe assembly to the 150mm diameter flue pipe. Assemble the cowl to the 150mm diameter flue pipe. Drill through and rivet through the cone pipe, cowl and flue pipe using a minimum of 3x SS rivets. *Note: Ensure a good mechanical seal between the cowl and cone. This is necessary to keep rain out of the flue system.
Page 32 Flue Restraints: The flue above the roof must be restrained as per AS/NZS 2918:2018 Section 4.10 - Fixing Flue Flashing: The rubber flashing, flashing plate and other flashing material used must comply with the relevant building code/ local building regulations. Silicone flashing is the recommended flashing material for both the Classic flue kit and with the Designer Shroud accessory.
Page 33 Ensure that an isolation switch is hard-wired to the wall. Escea will supply a replacement supply cord if the supply cord is damaged. An Escea service agent or a similarly qualified person will conduct maintenance of the supply cord to...
Page 34: D Woodfire Operation
OPERATION GUIDE WARNING WARNING DO NOT MODIFY THIS APPLIANCE. DO NOT OPERATE YOUR APPLIANCE WITH THE DOOR OPEN OR AJAR. BURN WELL SEASONED WOOD ONLY (LESS THAN 25% MOISTURE). ONLY OPEN THE DOOR WHEN FUELING/ RE-FUELING YOUR APPLIANCE. ALWAYS OPERATE THIS APPLIANCE WITH THE DOOR CLOSED AND LATCHED WEAR SUITABLE GLOVES TO OPERATE EXCEPT DURING START UP AND RE-...
Page 35 D1 First Fires The first fire(s) in your appliance may be difficult to get going and keep going with a lesser amount of heat being generated. This is a result of the moisture being driven out of the vermiculite panels. Allow several hours of hot fires before your appliance will perform optimally.
Page 36 Top – Down Lighting Method (Alternative) Step 4: Lighting a fire can sometimes be difficult. The Light each of the firelighter pieces and close the following method of lighting a fire is one that is door. Wait for when the flames are well established widely practiced in other parts of the world.
Page 37 Can’t get heat out of the appliance? Another problem may be wet or green wood. The typical symptom is sizzling wood and moisture One of two things may have happened. The being driven from the wood. appliance itself has not reached optimum temperature or the flue damper is positioned all the way to the left.
Page 38 D4 Smoke Information A properly installed appliance should not smoke. If Is the smoke flow impeded by too long a ͳ yours does, check the following: horizontal pipe or too many bends? Has the flue had time to get hot? Is it a weak draft perhaps caused by a leaky ͳ...
Page 39 CAUSES: Using incorrect fuel, or small fuel pieces IN CASE OF A CHIMNEY FIRE: ͳ which would normally be used as kindling. Have a well understood plan for evacuation ͳ Leaving the door ajar too long and creating and a place outside for everyone to meet. ͳ...
Page 40 D8 Summary - Do’s and Dont’s DON’T Build a hot fire. Take ash out immediately. Let it accumulate ͳ ͳ to a depth of at least one inch. A good ash Use only dry wood. ͳ layer provides for a longer lasting and better burning fire.
Page 41: E Maintenance & Servicing
An up to date list of authorised sufficient fuel to get the appliance thoroughly dealers can be found at www.escea.com hot, using green or wet wood, or closing the draft DO NOT USE SUBSTITUTE MATERIALS.
Page 42 The appliance is sprayed with Senotherm high temperature paint. If any visual parts become scratched during assembly or servicing, touch up Senotherm paint cans can be purchased from your local Escea dealer. Please ensure that ONLY Senotherm is used during touch ups.
Page 43 E5 Door Hinge Adjustment To ensure continued and proper sealing, adjustments to the door and the latch bracket will be required as the seal becomes worn-out over time. Removal of the door will be required when adjusting the door. Open the door and lift it up to disengage from the door hinge. Pull the door away from the product.
Page 44 Undo 4x M6 nuts and 4x M6 washers (circled below) to free the hinge blocks on the left side of the product. Move hinge blocks inwards, towards the products, to ensure a tight seal once the door is re-attached. Re-assemble the M6 nuts and M6 washers after moving the hinge blocks.
Page 45 E6 Latch Bracket Adjustment Remove stud cover from the latch bracket. Unhook the stud cover from the latch bracket by pulling the stud cover up. Pull the stud cover from the latch bracket to remove it. VIEWED FROM RIGHT SIDE OF THE PRODUCT WITH STUD COVER NO STUD COVER STEP 1: LIFT UP STUD COVER...
Page 46 Undo 3x M6 nuts and 3x M6 washers (circled below) to free the latch bracket on the right side of the product. Move the latch bracket inwards, towards the product, to ensure a tight seal once the door is re-attached. Tighten the bottom nut in the new latch position but leave the others loose.
Page 47 E7 Door Angle Adjustment Loosen the 4x M6 nuts and 4x M6 washers (circled below) to free the hinge adjustment plate behind the door. Viewed from the back of the door, swing the top of the hinge adjustment plate to the left to adjust the angle of the door.
Page 48 E8 Vermiculite Removal and Replacement Vermiculite panels will have to be removed to gain access to the flue for cleaning and any electrical component maintenance. In the event of vermiculite panels getting damaged over time, the existing panels will also have to be removed and replaced with new panels. Note: please handle the replacement vermiculite panels carefully.
Page 49 Use the previous steps as guide for re-installing vermiculite panels. Tilt panel as required to fit the replacement panels into the firebox. New vermiculite panels are available from your authorised dealer or distributor. An up to date list of authorised dealers can be found at www.escea.com...
Page 50 E9 Air Bar Removal & Replacement The air bar will have to be removed to gain access to the flue for cleaning and maintenance. In the event of the air bar getting damaged over time, the air bar removal will be needed for replacement.
Page 51 Use the previous steps as guide for re-installing the air bar . Tilt part as required to fit the replacement air bar into the firebox. New air bar is available from your authorised dealer or distributor. An up to date list of authorised dealers can be found at www.escea.com 51 51...
Page 52 New ash lips are available from your authorised dealer or distributor. An up to date list of authorised dealers can be found at www.escea.com. 630592_1 TFS650-TFS1000 InSTallaTIon Manual...
Page 53 E11 Maintenance of Electrical Components In the event of electrical components such as the fan and thermal switch becoming faulty, it would be required to remove and replace the fan cassette from the product. The following steps highlight the procedures for the removal and replacement of the fan cassette.
Page 54 FAN CASSETTE PLINTH (VIEWED FROM THE BACK OF THE PRODUCT) Undo 1x M5 nylock nut to remove the label plate from the fan cassette (circled below). Put aside the label plate as it will have to be re-assembled to the new fan cassette. Replace the new fan cassette as required.
Page 55: F Troubleshooting
TROUBLESHOOTING unTIl aPPlIanCE HaS CoolED. WaRnInG Do noT uSE aBRaSIVE ClEanERS. aPPlIanCE MaY BE HoT, Do noT SERVICE Problem Solution Can’t get the fire • Not enough kindling / paper? Add more. started. • Not enough air? Ensure air control is fully open. Also ensure that the air opening is not obstructed.
Page 56: G General Warranty Terms & Conditions
Escea fire dealer. Nature of Warranty Subject to the exclusions in section 2 & 3, Escea undertake to put right any defects in the Escea wood fire products supplied by Escea for the periods specified below:...
Page 57 • This warranty does not cover paint blemishes or imperfections because of the uneven nature of high temperature paint. A spray can of touch up Escea paint is available and can be purchased from your Escea dealer. •...
Page 58 Where you make a claim under this warranty, an authorised repairer may need to attend your premises to inspect the Escea product. Escea may charge you a service call fee if a repairer will be required to travel more than 30 km from the nearest service centre to your location.
Page 59: H Service History & Data Plate
SERVICE HISTORY & DATA PL ATE H1 Service History The appliance must be serviced at least annually and possibly more frequently – dependent on usage. Date Dealer Name Service Technician Service Performed Notes...
Page 60 630592_1 TFS650-TFS1000 InSTallaTIon Manual...
