- Page 1 TVIBH Operation Manual BACKPACK CONCRETE VIBRATOR FIND THE HOW TO GUIDE ON YEAR Honda Engine...
-
Page 2: Table Of Contents
- Service Safety 2. Technical Data 3. Checks Before Starting 4. Machine’s Safety Rules 5. Vibrator Operation 6. Dimensions of Poker Wear 7. Maintenance 8. Troubleshooting 9. Spare Parts 10. Operation Recommendations 11. Parts Manual 12. Tomahawk Catalog and Coupon... - Page 3 Register Your Equipment Thank you for purchasing TOMAHAWK equipment! Your product is covered by the TOMAHAWK Warranty policy, but in order to activate your warranty, we need you to register your product. In addition to activating your equipment warranty, product registration will grant you access to important product updates, streamlined customer service and more.
-
Page 4: Safety Information
Tomahawk Power. The information contained in this manual is based on equipment’s production at the time of publication. Tomahawk Power reserves the right to change any portion of this information without notice. -
Page 5: Laws Pertaining To Spark Arresters
1.2.2 NEVER touch the engine or muffler while the engine is on or immediately after it has been turned off. These areas get hot and may cause burns. 1.2.3 NEVER use accessories or attachments that are not recommended by Tomahawk Power. Damage to equipment and injury to the user may result. -
Page 6: Safety While Using Combustion Engines
1.2.9 ALWAYS operate machine with all safety devices and guards in place and in working order. DO NOT modify or remove safety devices. DO NOT operate machine if any safety devices or guards are missing or inoperative. 1.2.10 ALWAYS read, understand, and follow procedures in Operator's Manual before attempting to operate equipment. -
Page 7: Technical Data
2. TECHNICAL DATA 2.1 Design and Features Ideal for construction, formwork, patching, and other repair jobs, the Tomahawk TVIBH Backpack Concrete Vibrator is the perfect for removing air bubbles at 12,000 VPM to help properly settle concrete faster. Tomahawk vibrators are designed with superior padding with adjustable straps and cushion to distribute weight evenly to reduce operator fatigue. - Page 8 2.4 Machine Data ENGINE DATE Engine Brand Honda Engine Model GX35 Engine Type Air-cooled 4-stroke OHV Displacement 35.8 cm3 Net Power Output* 1.3 hp (1.0 kW) @ 7,000 rpm Net Torque 1.2 lb-ft (1.6 Nm) @ 5,500 rpm Starting System Recoil Oil Capacity 3.4 US oz (100cc)
-
Page 9: Machine's Safety Rules
4. MACHINE’S SAFETY RULES 4.1 For your own safety, the safety of others, and the safety of this equipment, read the following instructions carefully: 4.1.1 For the proper use of this device, please assure that the operator has been correctly informed of the content of this manual before using it. -
Page 10: Vibrator Operation
5. VIBRATOR OPERATION 5.1 Before Starting 5.1.1 Before working, make sure that all the security devices are operating under normal conditions. 5.1.2 Read the engine manufacturer manual thoroughly. 5.1.3 DO NOT work in rooms with scarce ventilation. 5.1.4 Make sure there is NO flammable good near to the escape. 5.1.5 Check the petrol level in the reservoir (use always unleaded gas in 4 stroke engines). -
Page 11: Dimensions Of Poker Wear
5.7 Inspection 5.7.1 Before starting the job, ensure that all handling and safety devices are working correctly. 5.7.2 Regularly inspect the condition of the transmission to ensure it is in good condition. When the hose is broken, repair it or replace it to avoid damaging the shaft or the poker. 5.7.3 Replace parts that are worn down. -
Page 12: Maintenance
7. MAINTENANCE 7.1 Maintenance Table Maintain the equipment in accordance with the following recommended procedures. Refer to the engine manufacturer’s instruction manual for additional information about engine maintenance. The following chart is based on a normal operation schedule. WEEKLY MONTHLY QUARTERLY MONTHLY (EVERY 50 HOURS) - Page 13 7.2 Additional Maintenance Information 7.2.1 Safety fittings must be checked after every maintenance check. 7.2.2 Always use the original parts for every maintenance check. 7.2.3 DO NOT fill the fuel tank near any potential source of danger. (EX: while smoking) 7.2.4 Lock the petrol admission key while filling the fuel tank.
- Page 14 7.3.8 Assemble all of the parts correctly once maintenance checks are completed. 7.3.9 Every 12 months (or more frequently depending on use), have the unit inspected by a dealer authorized by Tomahawk Power. 7.4 Storage 7.4.1 When the motor will not be used for a long period of time, store in a clean, dirt-free, protected area.
-
Page 15: Troubleshooting
8. Troubleshooting LOCATING MALFUNCTIONS WITH THE ENGINE PROBLEM CAUSE/SOLUTIONS Check the gas level. Check the gas admission key is open. The motor does not work Check the de choke position. Check the engine oil level. LOCATING MALFUNCTIONS OF FLEXIBLE SHAFT AND POKERS PROBLEM CAUSE/SOLUTIONS Head is overlubricated. -
Page 16: Spare Parts
9.2.5 Customer Support will notify you if your warranty is valid. 9.2.6 Warranty will be void if any equipment has been handled by personnel outside of Tomahawk Power, or an unauthorized dealer. 9.2.7 Tomahawk Power reserves the right to modify any part of this manual without prior notice.*... -
Page 17: Operation Recommendations
10. OPERATION RECOMMENDATIONS 10.1 Choose the type of vibrator adequate to the dimensions of the structure, the distance among the reinforcement, and the slump cone. It is recommendable to have an additional concrete vibrator, based on the scope of your project. 10.2 Before beginning the job, check that the concrete vibrator is in good use and it works correctly. -
Page 18: Parts Manual
11. TIPS AND SUGGESTIONS FOR VIBRATION CONCRETE Proper concrete vibration techniques WILL: • Produce concrete with the maximum strength and qualities designed in the mixture. • Bond rebar to maximize concrete strength. • Slow down the penetration of rust-causing liquids by increasing density. •... - Page 19 PROPER TECHNIQUE INCORRECT TECHNIQUE Trapped air moves upward in the mixture from 1 to 3 inches per second. (1 inches in near 0 slump; 3 inches in 4 to 5 inch slump). IMPORTANT RADIUS OF VIBRATOR ACTION..AREA OF INFLUENCE INSERTION POINT OF VIBRATOR FORM NO VIBRATIONS...
- Page 20 11. TIPS AND SUGGESTIONS FOR VIBRATION CONCRETE CONTINUED Consolidation eliminates the pockets of aggregate and air bubbles. This maximizes strength and eliminates surface voids, bringing sufficient fine material to the surface and against forms to produce the desired finish. Concrete vibrators consolidate concrete by sending out shock waves, which allows aggre- gate to float freely while pushing lighter trapped air up and out of the mixture.
- Page 21 TVIBH BACKPACK CONCRETE VIBRATOR...
-
Page 29: Tomahawk Catalog And Coupon
Lose the manual pump and gain the power to spray 15,000 ft² in 10 minutes or less while maintaining constant, adjustable pressure from 50-435 PSI with your ideal concrete sealant, cure, top cast, form release, and more! Item #: TCS6.5 6.5 GAL MOTORIZED CONCRETE SPRAYER www.tomahawk-power.com... - Page 30 36” & 46” Concrete Power Trowel 36” & 46” Concrete Power Trowel 8” Gas Powered Concrete Scarifier 8” Gas Powered Concrete Scarifier Part#: TVIBH + TVW10-P Part#: TVIBH + TVW10-P Part#: TPT36H/K & TPT46H/K Part#: TPT36H/K & TPT46H/K Part#: TSCAR8H Part#: TSCAR8H 1.6 HP Honda GX35 engine...
- Page 31 1 Year Product Warranty 3 Year Engine Warranty & 1 Year Product Warranty 1 Year Product Warranty * All coupons in this manual are valid only for orders placed on www.tomahawk-power.com, unless otherwise noted. Coupon codes ASSEMBLED IN THE ASSEMBLED IN THE may only be used once per customer and may not be combined with any other offer.
- Page 32 With same day shipping and faster delivery times, count on Tomahawk to keep you powered throughout the day! With long lasting parts and engines, Tomahawk equipment will be the star of your fleet for years to come. Visit www.tomahawk-power.com to get started today!
