- Page 1 Barneveld, Netherlands Phone: + 31 6 51920965 E-mail: info@comfychair.nl Website: www.comfychair.nl Wood PACKAGE CONTENT Folding Chair FCC 200 L1-7 MOUNTING HARDWARE Assembly 4x40 video Watch 8x70 4x20...
- Page 2 Barneveld, Netherlands Phone: + 31 6 51920965 E-mail: info@comfychair.nl Website: www.comfychair.nl Wood ASSEMBLY INSTRUCTIONS Folding Chair FCC 200 Before you start • Carefully unpack the package and check if all components are present. • Required for assembly: cordless drill, hammer and an wrench 13.
- Page 3 Barneveld, Netherlands Phone: + 31 6 51920965 E-mail: info@comfychair.nl Website: www.comfychair.nl Wood ASSEMBLY INSTRUCTIONS Folding Chair FCC 200 Step 3 | Low back support • Take two washers and two 8x70 mm screws. Slide a washer over each screw. • Take low back support D and place it in the center of side pieces A.
- Page 4 Barneveld, Netherlands Phone: + 31 6 51920965 E-mail: info@comfychair.nl Website: www.comfychair.nl Wood ASSEMBLY INSTRUCTIONS Folding Chair FCC 200 1,5 cm Step 6 | Armrest carrier • Fasten triangle G on chair leg E. The triangle extends 1.5 cm above E. The three marking points on G should face forward.
- Page 5 Barneveld, Netherlands Phone: + 31 6 51920965 E-mail: info@comfychair.nl Website: www.comfychair.nl Wood ASSEMBLY INSTRUCTIONS Folding Chair FCC 200 Step 9 | Armrest • Take the end of the armrest (H) and secure it to the ‘position stopper’. Use two 8x70 screws and slide a washer over each screw.
- Page 6 Barneveld, Netherlands Phone: + 31 6 51920965 E-mail: info@comfychair.nl Website: www.comfychair.nl Wood ASSEMBLY INSTRUCTIONS Folding Chair FCC 200 Step 12 | Slat M • Insert slat M in the notches at the back of the seat, with the curved side facing back and the countersunk screw holes facing up.
