Summary of Contents for POLYGON COLLOSUS n8e

  • Page 1 POLYGONBIKES.COM BICYCLE OWNER’S MANUAL...

  • Page 2: Introduction

    Congratulations for buying Polygon Bikes! A bicycle is a great tool for transportation and recreation. Hopefully, you can find enjoyment and have a great deal of use in every ride. This manual contains important information which includes safety, performance, and maintenance.

  • Page 3: Table Of Contents

    CONTENT INTRODUCTION HOW TO HANDLE AN ASSIST BICYCLE TABLE OF CONTENT MAKING WALKING AND PUSHING THE BICYCLE EASY EXPLODED VIEW ELECTRICAL PARTS FRAME KITS WIRING DIAGRAM ASSEMBLY TROUBLESHOOTING CABLE ROUTING HOW TO CLEAN THE BIKE REGULAR INSPECTIONS HOW TO MAINTAIN THE BIKE’S CHAIN...

  • Page 4: Exploded View

    BICYCLE PARTS EXPLODED VIEW OPTIONAL FOR SHIMANO E7000 FOR SHIMANO EP801 And EP600 FOR SHIMANO EP8 03 / Bicycle Parts - Exploded View Manual Guide...

  • Page 5: Frame Kits

    COLLOSUS N8E - FRAME KITS ARTICLE TORQUE QTY / PART # ITEM ITEM DETAILS SOLD CODE (N.m) FRAME 733699 SHOCK LINK IS19PFK14 PER PIECE 733700 SECOND LINK IS19PFK13 PER PIECE 733701 FIRST LINK IS19PFK12 PER PIECE 735299 REAR PIVOT BOLT IS17PFK32 M12X1.25, L26, T12, HEX5...
  • Page 6 COLLOSUS N8E - FRAME KITS ARTICLE TORQUE QTY / PART # ITEM ITEM DETAILS SOLD CODE (N.m) FRAME WASHER ID8, OD12.5 BOLT INS-IS19PFK03 M8X1.25, L37, T22.2, HEX6 10 - 12.5 733717 DRIVE UNIT/MOTOR BOLT SET AS A SET BOLT INS-IS19PFK02 M8X1.25, L28, T13.2, HEX6 10 - 12.5...
  • Page 7 COLLOSUS N8E - FRAME KITS ARTICLE TORQUE QTY / PART # ITEM ITEM DETAILS SOLD CODE (N.m) FRAME BOLT M5X0.8, L12, HEX3 DRIVE UNIT BOTTOM COVER 736846 FOR DU-EP801 & DU-EP600 IS19PFK32 PLASTIC AS A SET BOLT M3X0.5, L6, HEX2 BOLT M4X0.7, L12, HEX2.5...
  • Page 8 BICYCLE PARTS DRIVE UNIT COVER & DOWNTUBE AREA ASEEMBLY FOR SHIMANO EP801 And EP600 07 / Bicycle Parts - Assembly Manual Guide...
  • Page 9 BICYCLE PARTS FIRST LINK AND SECOND LINK ASEEMBLY 08 / Bicycle Parts - Assembly Manual Guide...

  • Page 10: Assembly

    BICYCLE PARTS REAR PIVOT HARDWARE ASSEMBLY OPTIONAL 09 / Bicycle Parts - Assembly Manual Guide...
  • Page 11 BICYCLE PARTS SHOCK LINK HARDWARE ASSEMBLY 10 / Bicycle Parts - Assembly Manual Guide...
  • Page 12 BICYCLE PARTS SHOCK HARDWARE ASSEMBLY / Bicycle Parts - Assembly Manual Guide...

  • Page 13: Cable Routing

    CABLE ROUTING REAR BRAKE RIGHT CABLE ROUTING REAR BRAKE LEFT LEGEND RD Cable Charging port Charging port Rear Brake Hose Dropper Post Cable Cycle Computer Cable Speed Sensor Cable 12 / Cable Routing Manual Guide...

  • Page 14: Regular Inspections

    REGULAR INSPECTIONS BEFORE RIDING THE BICYCLE Before riding the bicycle, check the following items. If any problems are found, consult your place of purchase or a distributor. Does the drive train perform gear shifting smoothly? Is there any looseness or damage in the component parts? Are the components securely installed to Do any abnormal noises occur while riding? the frame/ handlebar/ stem, etc.?

  • Page 15: How To Handle An Assist Bicycle

    HOW TO HANDLE AN ASSIST BICYCLE QUICK GUIDE Charge the battery Turn the power ON Example of built-in type battery To turn OFF the power, *According to the assist bicycle, the location of the charging port repeat this procedure. may be different from the one shown in the figure. Wait a while before pressing the power button when turning the power ON again after the power...
  • Page 16 HOW TO HANDLE AN ASSIST BICYCLE QUICK GUIDE Select assist mode LED2 Assist mode display • When the power is turned OFF, the assist mode resets to [OFF]. [OFF] • The below shows the display for the [BASIC] assist profile. Light blue [ECO] For the [Fine tune] assist profile display, refer to the user's manuals...

  • Page 17: Making Walking And Pushing The Bicycle Easy

    HOW TO HANDLE MAKING WALKING AND PUSHING AN ASSIST BICYCLE THE BICYCLE EASY (WALK ASSIST) QUICK GUIDE QUICK GUIDE Get on the bicycle and start riding SHIMANO STEPS has a function where assist works even when you are walking and pushing the assist bicycle. Turn the pedals to start assist.
  • Page 18 MAKING WALKING AND PUSHING THE BICYCLE EASY (WALK ASSIST) QUICK GUIDE Carefully push the bicycle Exit walk assist mode while pressing Y again Press the button (X button) on The drive unit operates while Y the upper side of the assist is pressed to assist you in switch (left side of the handle).
  • Page 19 SWITCHING BETWEEN AUTOMATIC AND MANUAL GEAR SHIFTING QUICK GUIDE Depending on the assist bicycle used, you may be able to switch When there is one automatic When there are two automatic gear shifting setting gear shifting settings between automatic and manual gear shifting. •...

  • Page 20: Electrical Parts

    ELECTRICAL PARTS - COLLOSUS N8E Built-in type battery BT-EN806 630 Wh Battery mount BM-EN801-A Drive unit DU-EP801 Drive unit cover (left side and bottom side) DC-EP801-A Crank arm FC-M8150 160mm Chainring unit SM-CRE80-12-B 34T Speed sensor EW-SS301 Shifting unit RD-M8100-SGS...
  • Page 21 ELECTRICAL PARTS - COLLOSUS N8XE PART # Built-in type battery BT-EN806 630 Wh Battery mount BM-EN801-A Drive unit DU-EP801 Drive unit cover (left side and bottom side) DC-EP801-A Crank arm FC-M8150 160mm Chainring unit SM-CRE80-12-B 34T Speed sensor EW-SS301 Shifting unit RD-M8150-SGS Disc brake rotor RT-EM810 203mm...

  • Page 22: Wiring Diagram

    Collosus N8e WIRING Collosus N8Xe DIAGRAM Collosus N8Xe only 21 / Wiring Diagram Manual Guide...

  • Page 23: Troubleshooting

    ERROR/WARNING INDICATION WHEN A PROBLEM OCCURS TROUBLESHOOTING TROUBLESHOOTING For details on error/warning codes, check the latest versions below: The FAQ for SHIMANO STEPS can be accessed with the following: https://si.shimano.com/error https://bike.shimano.com/faq/STP0A NOTICE If the error persists, stop using the bicycle and swiftly contact your place of purchase or a distributor for assistance.

  • Page 24: How To Clean The Bike

    HOW TO CLEAN THE BIKE NOTE • Use the right bike wash to make sure your every bike component and frame is safe. • Avoid washing the bike using high-pressure water. • It is highly recommended to use specific lubricants for bicycle parts, not with engine vehicles or other oil since it might lead to...

  • Page 25: How To Maintain The Bike's Chain

    HOW TO MAINTAIN THE BIKE’S CHAIN Use a bike chain cleaner and Wipe with a clean and dry cloth, Lube the chain regularly. gently brush it. and let it dry for minutes. 24 / Bike Maintenance Manual Guide...
