HORTI-BLADE
TUNABLE
INSTALLATION INSTRUCTIONS
PLEASE ENSURE YOU HAVE READ THE FOLLOWING INSTRUCTIONS THOROUGHLY AND CAN UNDERTAKE THE
REQUIRED ACTIONS BEFORE COMMENCING INSTALLATION.
IF YOU HAVE ANY QUERIES, PLEASE CONSULT VERTICALLY URBAN TECHNICAL SUPPORT DEPARTMENT BEFORE
PROCEEDING.
THIS PRODUCT SHOULD BE INSTALLED BY A CERTIFIED ELECTRICIAN AND FOLLOW
LOCAL REGULATIONS.
017369
Page 1 of 16
Advertisement
Table of Contents
Related Manuals for VERTICALLY URBAN HORTI-BLADE TUNABLE
Summary of Contents for VERTICALLY URBAN HORTI-BLADE TUNABLE
- Page 1 PLEASE ENSURE YOU HAVE READ THE FOLLOWING INSTRUCTIONS THOROUGHLY AND CAN UNDERTAKE THE REQUIRED ACTIONS BEFORE COMMENCING INSTALLATION. IF YOU HAVE ANY QUERIES, PLEASE CONSULT VERTICALLY URBAN TECHNICAL SUPPORT DEPARTMENT BEFORE PROCEEDING. THIS PRODUCT SHOULD BE INSTALLED BY A CERTIFIED ELECTRICIAN AND FOLLOW LOCAL REGULATIONS.
-
Page 2: Table Of Contents
REVISION TABLE COMMENTS APPROVED BY REVISION DATE AUTHOR 15/12/2022 DOCUMENT CREATED M. ASH M. BRUMPTON SPECTRA DRIVE CONNECTIONS UPDATED M. BRUMPTON 02/02/2023 M. ASH CONNECTION NOTE ADDED M. BRUMPTON 08/02/2023 M. ASH VERTICAL MOUNTING BRACKET ADDED L. GIBSON 05/09/2023 M. BRUMPTON L.GIBSON 08/10/2023 M. -
Page 3: Components List
COMPONENTS LIST HORTI-BLADE SPRING CLIPS TERMINATOR VERTICAL CLIP/SUPPORT RJ45 TERMINATOR STARTER CABLE VU-SPECTRA-DRIVE-6- VU-SPECTRA-DRIVE-6- MODBUS (015138) DMX (012252) Page 3 of 16 Page 3 of 16... -
Page 4: Specifications
020326 1764 020327 2340 CONTACT VERTICALLY URBAN IF MIXING VARIOUS LENGTHS OF FITTINGS WARNING: Do NOT hot-plug, use dimmers, or switches on the DC side. Doing so will invalidate the warranty. Always ensure that the power source is completely disconnected before handling any plugs or making any connections to avoid the risk of electrical shock or damage to the equipment. - Page 5 SPRING CLIPS *USE APPROPRIATE M4 SCREW Page 5 of 16 Page 5 of 16...
- Page 6 2340mm 1764mm 1188mm 612mm Page 6 of 16 Page 6 of 16...
- Page 7 CLIPS – VERTICAL INSTALLATION 2340mm 1764mm 1188mm 612mm Page 7 of 16 Page 7 of 16...
-
Page 8: Recommended Connection Methods
RECOMMENDED CONNECTION METHODS Do NOT reverse polarity WARNING! Do NOT exceed max. VU Spectra Drive chain length (31) RISK OF ELECTRICAL SHOCK. Only use specified PSU (as shown on Page 4) DISCONNECT POWER BEFORE Maximum cable length from Spectra Drive to luminaire is 20m SERVICING OR INSTALLATION STARTER CABLE TO SPECTRA DRIVE (DIRECT) NOT IP RATED... -
Page 9: Spectra Drive To Psu
Always ensure the connection has an appropriate IP rating for install location (Refer to page 7 for more information on extending cables) Vertically Urban recommends starter cables are linked to extension cables with gel boxes or junction boxes with suitable glands for both cables. -
Page 10: Dmx Setup
DMX SETUP ADDRESSING SHOULD BE DONE INDIVIDUALLY AND NOT WHEN MULTIPLE SPECTRA DRIVES ARE CONNECTED TOGETHER VU SPECTRA DRIVE DMX TESTING TOOL DMX OUT TO RJ45 WARNING! CABLE DO NOT LOOK AT LIGHT PRESS TO OPEN MENU PRESS TO NAVIGATE MENU PRESS TO SELECT... -
Page 11: Dmx Channel Example
PRESS TO SELECT NOTE: Horti-Blade™ Tunable utilises four channels which Spectra Drive DMX Channels correspond to four following DMX addresses assigned to that SD 1 001 – 004 Spectra Drive (SD). The DMX start address of each SD should SD 2 005 –... -
Page 12: Modbus Setup
MODBUS SETUP SPECTRA DRIVE CONFIGURATION EXPLANATION SLAVE ID: 1 SLAVE ID: 2 SLAVE ID: 3 NO. HOLDING REG: 4 NO. HOLDING REG: 4 NO. HOLDING REG: 4 Start Register – First holding register Baud Rate – Baud rate of the Master Slave ID –... -
Page 13: Ios Setup Instructions
iOS SETUP INSTRUCTIONS It may be necessary to disable Wi-Fi Assist to connect to MODBUS (Settings > Cellular OR Settings > Mobile Data > Wi-Fi Assist) 1. Connect to PowerDrive_******** 2. Click next to the Wi-Fi name, 3. Open Safari and paste IP address 4. -
Page 14: Android Setup Instructions
ANDROID SETUP INSTRUCTIONS 1. Connect to PowerDrive_******** 2. Click next to the Wi-Fi name, 3. Open Browser and paste IP address 4. Once fields are correct, press the using password 12345678 scroll to the bottom of this page, and ‘Press’ button in the ‘Save’ field once. into search bar. -
Page 15: Linking Spectra Drives (Rj45 Connections)
LINKING SPECTRA DRIVES (RJ45 CONNECTORS) WIRING EXAMPLE (NOT IP RATED) TO LUMINAIRE RJ45 TERMINATOR TO AC MAINS INPUT RJ45 DATA OUT → DATA IN *REFER TO PSU MANUFACTURER INSTRUCTIONS FOR SPACING GUIDANCE TO LUMINAIRE TO AC MAINS INPUT RJ45 DATA OUT → DATA IN TO LUMINAIRE TO AC MAINS INPUT RJ45 DATA OUT →... -
Page 16: Cautions
CAUTIONS Do NOT coil any power wires. Please take note of luminaire and PSU ingress protection rating when deciding location Always allow sufficient slack not to overstretch the cable. Do NOT bend the cable beyond its specified bend radius. Make sure all connections made are tight with no loose strands and with an appropriate IP rating. Do NOT hot-plug –...
