Yamaha RS-65S Assembling Instructions

YAMAHA
Electronic Drum Rack System
Thank you for purchasing the Yamaha Electronic Drum Rack System RS65S.
Before using, thoroughly read these assembly instructions, and use this product safely and correctly.
I RS65S Rack Stand Parts
* Before assembling the rack stand, make sure all of the parts shown below
are included.
Overall Assembly RS65S
(When the box is opened)
G Pad and Drum Trigger Grouping (option)
q DTXPRESS w TP65/65S
Drum Trigger Module Drum Pad
rKP65 t HH65
Kick Pad Hi-hat Control Pedal
PRECAUTIONS
Before using, please read this "Assembly Instruction" sheet,
and use this product in a safe and proper manner.
Especially for children, parents or an instructor should teach the
children the proper manner in which to use the device.
To prevent against accidents and injury
Please follow the cautions listed below
Caution (including danger, or warning). This mark indicates
cautions in which you should pay close attention to.
Acts indicated with this icon are prohibited and should not
be attempted.
●
This icon indicates acts that you are urged to follow.
* Specifications are subject to change without notice.
RS65S
N Small Screws M5 X8
(Module Holder Fixing Screws X4)
N Cable Band (x10)
N Assembly Instructions
(this sheet)
e PCY65/65S
Cymbal Pad
y Foot Pedal
* FP-700 etc.
If this symbol is ignored and the equipment is
used improperly, fatal injury to persons or se-
rious damage could occur.
WARNING
Always set the instrument on a flat and solid surface.
Placement on a sloping, unstable surface or on steps
may result in the instrument being unstable and over-
turning.
Make sure all bolts are tightened firmly. Loose bolts
may result in the rack overturning or parts dropping
causing injury.
When adjusting the height or angle, do not suddenly
loosen the bolt. The pad may drop, the rack or pipes
may slip, pinching or causing injury to hands or fingers.
Do not sit or step on the rack. The rack may overturn
or be damaged resulting in injury.
Please be careful when children are close to or touch-
ing the product. The product has many pipes and arms
so careless movement around the product may result
in injury.
When setting the pads and modules, please pay close
attention in regards to the handling and setting of
cables. Feet may become entangled in the cables re-
sulting in falls.
Assembly Instructions
I RS65S + Pad grouping : Set up example
e
PCY65S
q
w
w
TP65S
t
* Specifications are subject to change without notice.
CAUTION
e
w
r
y
If this symbol is ignored and the equipment is
used improperly, there is a danger of injury to
persons handling the equipment, and material
damage could occur.
Do not put your hands or feet under the foot pedal or
foot switch. They may be pinched resulting in injury.
Watch your fingers when adjusting clamps. They may
become pinched resulting in injury.
Be careful around pipe ends, inside the pipe and screw
ends. Metal shavings, etc. may injure your fingers.
Do not attach acoustic drums to the electronic drum
rack. Clamps may be damaged and drums may drop,
causing injury.
w
