Pyle PPHP1569UT User Manual page 3

Function Description
1. LCD screen
2. MP3 control
MODE: USB/SD/BT/FM convertor
: Previous Song
Press and hold for fast rewind
: Next Song
Press and hold for fast forward
: Repeat one / Repeat all / Random
: Play / Pause/SCAN
SCAN: Press and hold to auto search under FM radio
FOL: When playing USB/SD songs,
Press and hold to enter folder mode
3. SD card input
4. USB input
5. Master Volume control
6. Treble control for high frequencies
7. Bass control for low frequencies
8. MIC input level control
9. Line input level control
10. 6.35 mm microphone input
11. (R+L) Iine outputs
12. 3.5 mm line input
13. (R+ L) line inputs
14. Clip LED indicator
15. Power LED indicator
16. Speaker out 8 Ohm
17. Fused IEC mains inlet
18. 110V/220V switch
19. Main power switch
20. IR: Remote control receiver
21. LED Light switch
