Summary of Contents for IronCraft FL 85
- Page 1 FLAIL MOWER USE AND MAINTENANCE GUIDE Read and understand the manual. This manual provides information and procedures to safely operate and maintain the Flail Mower. Scan QR code for a digital version of this manual September 2023...
-
Page 2: Table Of Contents
1.1 WELCOME 1.1 Welcome 1.2 Safe Operation Congratulations on your choice of an IronCraft Flail Mower. This equipment has been designed and 1.3 Specifications manufactured to meet the needs of discerning users. Many features incorporated into this mower are 1.4 Register This Product the result of suggestions made by customers like you. -
Page 3: Specifications
1.3 SPECIFICATIONS 1.4 REGISTER THIS PRODUCT PURCHASE DATE flail mower MODEL FL 85 FL 95 FL 105 FL 115 FL 125 FL135 FL145 FL165 DEALER NAME STRUCTURE WEIGHT 100kg 115kg 130kg 145kg 160kg 175kg 190kg 235kg WORKING WIDTH 829mm 929mm... -
Page 4: Safety Information
SAFETY INFORMATION 2.2 SAFETY ALERT SYMBOLS This is the safety alert symbol and will be accompanied with a descriptive pictorial. It 2.1 INTRODUCTION is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. The Flail Mower consists of a rotating shaft with many blades attached to it. -
Page 5: Maintenance Safety
Improper maintenance or modifications to the design or performance of this machine will void the warranty. FOR SAFETY to the sharp and pointed parts during ONLY use genuine IronCraft replacement parts on this machine. of personnel and good performance repairing the machine. -
Page 6: Safety Signs And Labels
SAFETY SIGNS AND LABELS OPERATING PROCEDURES The types of safety signs and locations on the equipment are shown in the illustrations that follow. Ensure your tractor is in good operating condition. Before operating the machine, the following areas Good safety requires that you familiarize yourself with the various safety signs, the type of warning should be checked off: and the area, or particular function related to that area, that requires your safety awareness. -
Page 7: Flail Mower Adjustment
3.1 ADJUSTING THE HEIGHT 3.3 REGULATING THE TENSION OF THE DRIVING BELT To get the most out of your flail mower, it should be set within the recommended height. NOTICE To save fuel and power, and reduce wear and tear, The machine shall always stand still for regulating the tension. -
Page 8: Starting Up
3.4 STARTING UP MAINTENANCE PROCEDURES 4.1 FLUIDS AND LUBRICANTS Before starting the machine, control and adjust the following items: • Tension of trapezoidal driving belt • Oil level of gear • Point of lubrication Fluids and Lubricants • All bolts, nuts and screws GREASE Use multi-purpose lithium based grease. -
Page 9: Maintenance
4.2 MAINTENANCE 4.3 STORAGE TIPS NOTICE • The machine inside and outside shall be cleaned carefully so as to avoid corrosion. • Don’t spray water on the rolling bearing if you clean the machine with high pressure sprayer. All maintenance, repairing, cleaning and lubricating shall be conducted when the tractor and motor are stopped and the key is taken away. -
Page 10: Operation After Storage
4.4 OPERATION AFTER STORAGE ILLUSTRATED PARTS CATALOG The manual contains a parts list for your machine. It is divided into major sections, which corre- Before the machine is started up, check the following items regularly: spond to the groups shown in the Table of Contents and the accompanying illustration. The first page of each major section lists the contents of that section, each of which consists of ex- Check oil level and add it if ploded views and related tabular listings. - Page 11 Code Description QTY. Code Description QTY. EF1001 TOP LINK BRACKET EF1037 RH SKID SHOE EF1002 TOP LINK PIN EF1036 LOWER LINK PIN EF1005 RH A-FRAME EF1035 LOWER LINK BUSHING EF1004 LH A-FRAME EF1029 GREASE ZERK M6 EF1006 HOOK EF1022 HAMMER BLADE EF1053 PTO SHIELD EF1027...
-
Page 12: Limited Warranty
After one year, seals are considered to be wearing parts, and the replacement is the owner’s re- sponsibility. ii. Gearboxes that are subject to warranty may be replaced with new or rebuilt gearboxes at the discretion of IronCraft iii. Shearbolts must be approved Grade 2 , 1 /2 “ x 3 “ shearbolts. -
Page 13: Safety Acknowledgement Form
SAFETY ACKNOWLEDGEMENT FORM Operator Name Signature Date ATTN ALL OPERATORS: Print your name, sign and date in the boxes below to acknowledge that you have read and fully understand the safety instructions presented in this manual, and have been trained on how to safely operate this attachment. Operator Name Signature Date... -
Page 14: Maintenance Log
MAINTENANCE LOG DESCRIPTION OF MAINTENANCE SERVICED BY DATE Use this log sheet to document all routine maintenance and repair services performed on this machine. DESCRIPTION OF MAINTENANCE SERVICED BY DATE Maintenance Log Ironcraftusa.com Maintenance Log Ironcraftusa.com... - Page 15 7 rocky MT rd Athens, Tennessee 37303 (p) 423-405-5150 (f) 423-405-5904 www.ironcraftusa.com Revised September 22, 2023 ©2023 IronCraft Attachments. A ll rights reser ved. FL135_092023_v1...
