- Page 1 G2 EX transponder Manual 14.07.2023...
-
Page 2: Table Of Contents
Contents G2 EX transponder (Manual) 2 / 20 Contents General safety instructions ........................ 3 General................................ 5 How it works ............................... 5 Incorporating the transponder in different locking systems ............ 6 Higher-ranking locking level ........................ 7 Explosion protection transponder ....................... 9 General ................................. 9 Industrial standards ............................ -
Page 3: General Safety Instructions
Blocked access Access through a door may stay blocked due to incorrectly fitted and/or in- correctly programmed components. SimonsVoss Technologies GmbH is not liable for the consequences of blocked access such as access to in- jured or endangered persons, material damage or other damage! - Page 4 Only trained personnel may install and commission the product. Incorrect installation SimonsVoss Technologies GmbH accepts no liability for damage caused to doors or compon- ents due to incorrect fitting or installation. Modifications or further technical developments cannot be excluded and may be implemented without notice.
-
Page 5: General
Advantages over passive technologies include lower power requirements in the cylinder and the greater operating range. SimonsVoss supplies different transponder models. These models are described in this document. The second transponder generation G2 replaces the first generation G1. G2 features a more efficient communication protocol than G1. -
Page 6: Incorporating The Transponder In Different Locking Systems
2. General G2 EX transponder (Manual) 6 / 20 Digital Cylinder AX 5 cm to 20 cm Locking Cylinder 3061 15 cm to 40 cm SmartHandle AX 5 cm to 30 cm SmartHandle 3062 5 cm to 40 cm SmartLocker AX 5 cm to 30 cm Padlock AX 5 cm to 20 cm Padlock 15 cm to 40 cm SmartRelais 3 Advanced... -
Page 7: Higher-Ranking Locking Level
2. General G2 EX transponder (Manual) 7 / 20 Company: Branches: Home: locking devices locking devices locking devices Locking System 1 Locking System 2 Locking System 3 Fig. 1: A transponder for several separate locking systems 2.3 Higher-ranking locking level Transponders can be authorised for more than three [G1] or four [G2] locking systems. - Page 8 2. General G2 EX transponder (Manual) 8 / 20 Company D Company C Company B Company A Central locking system Fig. 2: Higher-ranking transponder Four companies are based in an office building with a main lock which is used by all the companies. Each company manages its own locking system with its own password.
-
Page 9: Explosion Protection Transponder
3. Explosion protection transponder G2 EX transponder (Manual) 9 / 20 3 Explosion protection transponder 3.1 General This is a transponder which has the same functions as Transponder 3064, see the manual on the website: https://www.simons-voss.com/en/documents.html It is also approved for use in Explosion Protection Zone 1. This transponder is a special product which can be carried and used in Zone 1 potentially explosive areas. - Page 10 3. Explosion protection transponder G2 EX transponder (Manual) 10 / 20 Protection level of the device This applies to areas where a potentially explosive atmosphere may occur due to gases, vapours or mist. The information given refers to an ambient temperature between -20 °C and +40 °C in the area of use.
-
Page 11: Transponder With Integrated Rfid Chip
4. Transponder with integrated RFID chip G2 EX transponder (Manual) 11 / 20 4 Transponder with integrated RFID chip Transponders can be supplied with different integrated RFID chips as an option. These RFID Chips do not necessarily need to be programmed with the LSM software. -
Page 12: G2 Battery Replacement Transponder
5. G2 battery replacement transponder G2 EX transponder (Manual) 12 / 20 5 G2 battery replacement transponder A G2 battery replacement transponder can be created in the LSM software (Version 3.0 or higher) for G2 locking systems. If the battery is low, the locking device will switch to freeze mode and can no longer be opened with normal transponders. -
Page 13: Additional Functions
6. Additional functions G2 EX transponder (Manual) 13 / 20 6 Additional functions The functions described below can be activated in the LSM software. 6.1 Time zone control Transponders can be programmed to have locking authorisation for digital access control locking devices at certain times only (time zones). Such time zones are added to the LSM software and the transponders are then allocated to the relevant time zone group. -
Page 14: Loss Of The Transponder
7. Loss of the transponder G2 EX transponder (Manual) 14 / 20 7 Loss of the transponder 7.1 Emergency opening You may carry out an emergency opening with the SmartCD and PDA and by entering the locking system password. 7.2 Replacement transponder [G1] If a transponder is lost, it can be blocked in the locking plan and a replacement transponder added. -
Page 15: Battery Warning For Transponders
8. Battery warning for transponders G2 EX transponder (Manual) 15 / 20 8 Battery warning for transponders When the transponder battery is low, short audible signals are heard in rapid succession on the locking cylinder (not the transponder) after the locking cylinder disengages each time the transponder is used. -
Page 16: Technical Data
9. Technical data G2 EX transponder (Manual) 16 / 20 9 Technical data Weatherproof plastic Material (polyamide) Housing: black Colours Housing Buttons: different col- ours Diameter 42.0 mm Height 13.7 mm Temperature range -20°C to +60°C Ambient conditions Protection rating IP66 Environmental Class This applies to areas... -
Page 17: Dimensions
9. Technical data G2 EX transponder (Manual) 17 / 20 Digital Cylinder AX 5 cm to 20 cm Locking Cylinder 3061 15 cm to 40 cm SmartHandle AX 5 cm to 30 cm SmartHandle 3062 5 cm to 40 cm SmartLocker AX 5 cm to 30 cm Range... -
Page 18: Declaration Of Conformity
10. Declaration of conformity G2 EX transponder (Manual) 18 / 20 10 Declaration of conformity The company SimonsVoss Technologies GmbH hereby declares that the articles (TRA2.G2.EX, TRA2.G2.EX.RFID.*) comply with the following guidelines: 2014/53/EU -RED- 2014/34/EU -ATEX- ATEX marking:... -
Page 19: Help And Other Information
Our technical support will be happy to help you (landline, costs depend on provider): +49 (0) 89 / 99 228 333 Email You may prefer to send us an email. support-simonsvoss@allegion.com FAQs You will find information and help in the FAQ section: https://faq.simons-voss.com/otrs/public.pl Address SimonsVoss Technologies GmbH Feringastr. 4 D-85774 Unterfoehring Germany... - Page 20 Our commercial success lies in the courage to innovate, sustainable thinking and action, and heartfelt appreciation of employees and partners. SimonsVoss is a company in the ALLEGION Group, a globally active network in the security sector. Allegion is represented in around 130 countries worldwide (www.allegion.com).
