- Page 1 AC-AEX-DEARC-KIT User Manual AUDIO EXTENDER KIT FOR ARC & eARC...
-
Page 2: Table Of Contents
Contents Important Safety Instructions ................................. 3 Safety Classifications in this Document ............................3 Electrical Shock Prevention ................................3 Weight Injury Prevention ..................................3 Safety Statements ....................................4 Features ........................................5 Product Overview ......................................6 Box Contents ......................................6 Technical Specifications ..................................6 Transmitter Front and Rear Panel Overview .......................... -
Page 3: Important Safety Instructions
Important Safety Instructions Before installing, configuring, and operating this device and other vendor equipment, AVPro Edge strongly recommends that each dealer, integrator, installer, and all other necessary personnel access and read all the required technical documentation, which can be located by visiting AVProEdge.com. Read and understand all safety instructions, cautions, and warnings in this document and the labels on the equipment. -
Page 4: Safety Statements
Safety Statements Follow all of the safety instructions listed below and apply them accordingly. Additional safety information will be included where applicable. Read and keep these instructions. Heed and follow all warnings. Clean devices and equipment only with a dry cloth. Devices not designed for exposure to moisture should NEVER be installed in prone locations. -
Page 5: Features
32 uncompressed audio channels with bi-directional control communication. Allowing the AC-AEX-DEARC-KIT to extend HDMI eARC, Digital, or Analog audio signals paired with CEC, RS232, or IR control over 100 meters using a single UTP Category cable. -
Page 6: Product Overview
Product Overview Box Contents (1x) AC-AEX-DEARC-T (Transmitter) (1x) AC-AEX-DEARC-R (Receiver) (1x) 12V-2.0A Power Supply (2x) 3-Pin Terminal Block Connector for RS-232 Ports (2x) Mini-TOSLINK connectors (1x) 3.5mm Mono IR Emitter (1x) 3.5mm Stereo IR Eye (4x) Mounting Brackets (8x) Mounting Screws Technical Specifications Video Video Transport Not Supported... - Page 7 Weight 2 lbs (Packaged Kit – Shippable Weight) *Specifications are subject to change without notice. Mass and dimensions are approximate.
-
Page 8: Transmitter Front And Rear Panel Overview
Transmitter Front and Rear Panel Overview AC-AEX-DEARC-T (Transmitter) – Front Panel AC-AEX-DEARC-T (Transmitter) – Rear Panel • Red LED status indicator light POWER STATUS MONITOR • Illuminates when power is present (PoC or 12V/2A) • Blue LED status indicator light •... - Page 9 • 3.5mm TRS connector port (IR In) • 3.5mm TS connector port (IR Out) • IR IN & OUT IR IN accepts IR signals from IR Eye or Control System, dipswitch selectable • IR OUT outputs IR Signals from AC-AEX-DEARC-R IR Input •...
-
Page 10: Receiver Front And Rear Panel Overview
Receiver Front and Rear Panel Overview AC-AEX-DEARC-R (Receiver) – Front Panel AC-AEX-DEARC-R (Receiver) – Rear Panel POWER STATUS • Red LED status indicator light MONITOR • Illuminates when power is present (PoC or 12V/2A) • Blue LED status indicator light ARC STATUS •... - Page 11 • 3.5mm TRS connector port (IR IN) • 3.5 mm TS connector port (IR Eye) • IR IN accepts IR signals from IR Eye or Control System, dipswitch IR IN & OUT selectable • IR OUT outputs IR Signals from AC-AEX-DEARC-T IR Input •...
-
Page 12: Wiring And Connections
Wiring and Connections HDMI Cables The AC-AEX-DEARC-KIT uses the standard 19-pin HDMI female connector port for the inputs and outputs. Ensure all HDMI cables and devices can support the signal being sent. For maximum performance, an Ultra High Speed HDMI cable rated for 48Gbps is more than sufficient for Note: high bitrate audio signal transport and will match HDMI cables handling HDMI 2.1a Video... -
Page 13: Usb Port
USB Port The Type-C USB port on both the Transmitter and Receiver are courtesy ports intended for troubleshooting purposes when directed by AVPro Edge Technicians. No cables should be connected to these ports during normal operation. RS-232 Wiring and Control The RS-232 control ports on both the Transmitter and Receiver are used to pass bidirectional control signals to and from any RS-232-compatible device. -
Page 14: Connecting The Devices
Connect Cat 5e (or better) cabling from the AC-AEX-DEARC-T RJ-45 output port to the RJ-45 input port on the AC-AEX-DEARC-R. Connect the 12V 2A power supply to one unit from the AC-AEX-DEARC-KIT. The companion unit is automatically powered via the Power-over-Cable feature. -
Page 15: Device Configuration
Device Configuration AC-AEX-DEARC-T SETTINGS Recessed into the bottom casing of the AC-AEX-DEARC-T are 4 dipswitches which are used to configure the operating parameters of the unit. Each dipswitch/dipswitch combination controls a different aspect of unit operation. 1 = Up (ON) 0 = Down (OFF) IR-EYE I-PASS... - Page 16 Audio menu settings in the Smart TV will determine the audio format to be sent to the AC-AEX-DEARC-KIT. For example, selecting 2-Channel PCM Stereo will send a combined Left and Right audio mix through BOTH eARC/ARC and the TOSLINK (if equipped) and analog audio (if equipped) outputs.
-
Page 17: Ir Configuration
Device Configuration AC-AEX-DEARC-R SETTINGS Recessed into the bottom casing of the AC-AEX-DEARC-R are 4 dipswitches which are used to configure the operating parameters of the unit. Each dipswitch/dipswitch combination controls a different aspect of unit operation. TABLE 2 IR-EYE I-PASS EXT. -
Page 18: Ac-Aex-Dearc-R Settings
AC-AEX-DEARC-R SETTINGS HDMI AUDIO CONFIGURATION DIPSWITCH 2 – Use to select between eARC audio output or conventional HDMI audio-only outputs: A - 0 (DEFAULT) – eARC OUT • The HDMI port operates as an eARC/ output with compatible devices such as AVRs or Pre-amp processors. -
Page 19: Troubleshooting
Troubleshooting • Verify Power – Check that the power supply is properly connected and is outputting 12V. • Verify Connections – Check that all cables are properly connected and/or terminated where applicable. • Verify Terminations – Ensure you are using a minimum of CAT 5e UTP or STP without breaks such as keystones, punch downs, or other interconnectors. -
Page 20: Damage Requiring Service
Damage Requiring Service These devices should be serviced only by AVPro Edge qualified personnel if: • Objects or liquids have breached the interior of the devices • The devices have been exposed to rain or moisture • The devices do not operate normally or exhibit a marked change in performance •... -
Page 21: Coverage Details
Coverage Details AVPro Edge will replace or repair (at the customer’s choice) defective products. If the product is out of stock or on backorder it can be replaced with a comparable product of equal value/feature set (if available) or repaired. Your warranty begins at receipt of the product (as confirmed by shipping firm tracking). -
Page 22: Limitation On Liability
Limitation on Liability The maximum liability of AVPro Global Holdings LLC under this limited warranty shall not exceed the actual purchase price paid for the product. AVPro Global Holdings LLC is not responsible for direct, special, incidental, or consequential damages resulting from any breach of warranty or condition, or under any other legal theory to the maximum extent permitted by law.
