3D LIGHT Mounting and Installation Guideline
NOTE:
The latest version of this document always available at:
https://cloud1.tbs-biometrics.com/index.php/s/ZeFnJkb4L4y4gNT
Release
Author
Feb 15, 2018
TM
June 29, 2018
TM
Nov 07, 2018
TM
Oct 22, 2020
TM/AG
Nov 25, 2021
TM/AG
April 19, 2022
TM/AG
Dec 02, 2022
TM/AG
Document TBS-040
Comment
First version
Supported interfaces added, mounting instructions revised
Wiegand requires external pull-ups
Added Thermal option and wall mount picture with dimensions
Updated powering table, GPIN & port assignments
Name change from 2D EYE to 3D LIGHT
Tamper Switch & Wifi Support added
Advertisement
Table of Contents
Related Manuals for tbs electronics 3D LIGHT
Summary of Contents for tbs electronics 3D LIGHT
- Page 1 Added Thermal option and wall mount picture with dimensions Nov 25, 2021 TM/AG Updated powering table, GPIN & port assignments April 19, 2022 TM/AG Name change from 2D EYE to 3D LIGHT Dec 02, 2022 TM/AG Tamper Switch & Wifi Support added...
-
Page 2: Table Of Contents
Recommended Mounting Information ....................5 General Wiring Requirements ......................5 Standard Installation to Wall Surface ....................6 Attaching 3D LIGHT to Wall Bracket ....................7 Connections ............................8 Back View with Connectors ......................... 8 Power Input and I/O Interface Block ....................9 LAN Connector .......................... -
Page 3: Introduction
This document describes the mounting and installation of the 3D LIGHT. The reader can be equipped with a thermal sensor to read body temperatures of users. The configuration options are explained in the TechNote ‘TN 3D LIGHT Thermal Getting Started’, which is available here: https://cloud1.tbs-biometrics.com/index.php/s/YdewuYw1boV3XOA... -
Page 4: Legal And Safety Instructions
TBS company representative or TBS hotline. TBS reserves the right to make changes to information published in this document at any time and without notice. • • TBS 3D LIGHT Mounting and Installation Guideline TM/AG Rev 12-2022 page 4 of 15... -
Page 5: Mounting And Installation
To handle smaller persons in your installation, please adapt mounting height accordingly. ▪ Strong ambient light and / or direct light into the front side of the 3D LIGHT should be avoided. Sunlight, halogen lamps or other strong illumination may reduce the performance of the 3D LIGHT and may result in increased failure-to-capture rates or failed authentication events. -
Page 6: Standard Installation To Wall Surface
Standard Installation to Wall Surface Detach the installation plate from the 3D LIGHT by removing the screw (M3 x 6mm) at the bottom of the unit. Separate the wall plate from the rear cover by sliding the plate downward. The screw will be re-used to attach the 3D LIGHT to the wall plate following installation of the wall plate and wiring. -
Page 7: Attaching 3D Light To Wall Bracket
Attaching 3D LIGHT to Wall Bracket Slide the 3D LIGHT into the installation wall bracket (back plate) from the top. Lock the 3D LIGHT with bracket using M3 x 6mm screw on bottom. Please use security type screws if needed. -
Page 8: Connections
4. External USB Socket In case of 3D LIGHT: connection for WiFi dongle In case of 3D LIGHT THERMAL: connection for thermal sensor module 5. Tri-pod mount: ¼ - 20 UNC (standard consumer camera mount) 6. Power Input and I/O Interface 7. -
Page 9: Power Input And I/O Interface Block
7. Wiegand Output Connector 8. DC Power Input Connector 9. Relay Connector 10. Reboot Switch 11. External Audio Output Connector (not supported) 12. Serial Debug Port • • TBS 3D LIGHT Mounting and Installation Guideline TM/AG Rev 12-2022 page 9 of 15... -
Page 10: Lan Connector
RJ-45 connector for 10/100Base-T Ethernet communication, minimum CAT5 cable. to Switch UTP Connector Hook is facing downside RS-485 Termination Resistor Switch Switch for 100 Ohm termination resistor activation when 3D LIGHT is connected to the end of RS-485 wire connection. Default: Turned off • •... -
Page 11: Rs-485 Connector
‘high‘ state. This GPIN transition could be used to provide an input to 3D LIGHT via external buttons. One possible application could be to create 'touchless time & attendance buttons': using foot pedals or wall switches, the ‘Coming’... -
Page 12: Wiegand Output Connector
(26/37bit) are supported. IMPORTANT: DATA0 / DATA1 lines are not pulled up internally in the 3D LIGHT. If the Wiegand receiver does not already have an internal pull-up resistor, DATA0 and DATA1 should be pulled up by 1K Ohm resistor. -
Page 13: Appendix
The TBS Terminals are made for permanent powering. The TBS power supply (or another model with similar specifications) must be able to drive the peak power as per the below table. By standard, 3D LIGHT is always delivered with an external power supply with these ratings: Type:... -
Page 14: Tbs Port Assignments
(2) Port is not mandatory in FW 2.xx since DCC channel is used for enrollment (3) PC where the sensor management tool is running should have this port open for inbound • • TBS 3D LIGHT Mounting and Installation Guideline TM/AG Rev 12-2022 page 14 of 15... -
Page 15: References To Other Tbs Documents
TBS 3D LIGHT Mounting and Installation Guideline Permanent link: https://cloud1.tbs-biometrics.com/index.php/s/zbMFeqpLitKR3K3 The QR code printed on the product opens this link, leading to the 3D LIGHT product folder from where this manual is available. TechNote ‘TN 3D LIGHT Thermal Getting Started’...
