- Page 1 3D FLASH+ Mounting and Installation Guideline Document TBS-061 NOTE: The latest version of this document always available at: https://cloud1.tbs-biometrics.com/index.php/s/TWldCHnZtkRn0LV Release Author Comment July 15, 2023 First version Nov 01, 2023 Update for Fingerprint Recognition Sensor...
-
Page 2: Table Of Contents
TBS Installation Manual – 3D FLASH+ Content Chapter Page Introduction ............................3 Legal and Safety Instructions ......................4 Mounting and Installation ......................... 5 Recommended Mounting Information ....................5 Prepare the Unit for Installation ......................5 Choose the Installation Type....................... 6 Direct Installation to Wall (without Backunit) .................. -
Page 3: Introduction
TBS Installation Manual – 3D FLASH+ Introduction The TBS Terminal series brings Access Control and Time & Attendance applications featuring biometrics to a new level. They combine highest security with user convenience and the most flexible configuration options on the market. This document describes the mounting and installation of the 3D FLASH+. -
Page 4: Legal And Safety Instructions
TBS Installation Manual – 3D FLASH+ Legal and Safety Instructions Allowed Applications TBS products are not designed, authorized or warranted to be suitable for use in medical, military, aircraft, space or life support equipment, nor in applications where failure or malfunction of a TBS product can reasonably be expected to result in personal injury, death or severe property or environmental damage. -
Page 5: Mounting And Installation
TBS Installation Manual – 3D FLASH+ Mounting and Installation Recommended Mounting Information ▪ The recommended mounting height for the 3D FLASH+ is 131 cm (51 inches) from ground to the bottom of 3D FLASH+ (device mounted vertically, no tilting!). ▪ This relates to a person size of about 150 cm to 200 cm when scanning in the short distance;... -
Page 6: Choose The Installation Type
TBS Installation Manual – 3D FLASH+ Choose the Installation Type ▪ Installation can be accomplished by mounting directly to a wall (surface mount). You can choose your installation type from two versions: with or without backunit. ▪ A backunit is included in each package (first picture from the left below). When using it, first the backunit is mounted to the wall. -
Page 7: Direct Installation To Wall (Without Backunit)
TBS Installation Manual – 3D FLASH+ Direct Installation to Wall (without Backunit) ▪ Place the installation plate on the desired wall location and screw it into the wall as indicated in the Surface Mount diagram below. Please ensure that the bottom tab in the plate faces outward into the room and the cable routing opening in 3D FLASH+ (marked in green) matches the... -
Page 8: Installation With Backunit
TBS Installation Manual – 3D FLASH+ Installation with Backunit 3D FLASH+ can be mounted on the backside unit, as described above. Please use the backunit directly to mark the drilling positions on the wall, and use the 6 large screws for installation. -
Page 9: Power And Signal Wiring
TBS Installation Manual – 3D FLASH+ Power and Signal Wiring 3D FLASH+ Wiring Layout and Cables This chapter describes the general wiring layout and the cables provided with the device. Figure: Overview of cable connections on the backside of 3D FLASH+ •... - Page 10 TBS Installation Manual – 3D FLASH+ • • TBS 3D FLASH+ Mounting and Installation Guideline TBS-061 Rev 11-2023 page 10 of 17...
-
Page 11: General Wiring Requirements
TBS Installation Manual – 3D FLASH+ General Wiring Requirements IMPORTANT: For all signal wiring, including ethernet cables, it is recommended to connect cables of less than 30m length to avoid surge current spikes that may damage the equipment. The 3D requires at least the following wiring: FLASH+ ▪... -
Page 12: Power Supply Wiring Recommendations
TBS Installation Manual – 3D FLASH+ Power Supply Wiring Recommendations TBS recommends using a AWG16 gauge and 15-24 VDC power supply. The voltage specified is the one measured on the product block connector: 15-24 VDC (-15% / +10%). The voltage drop due to the cable shall be considered. Table 3 shows the maximum distance between power supply and one unique device, depending on cable gauge and power supply rating. -
Page 13: Connecting Third Party Controllers
TBS Installation Manual – 3D FLASH+ Connecting Third Party Controllers 4.7.1 RS485 Serial Interface TBS recommends using RS485 and to protect communication using OSDP standard. RS-485 cable can be connected up to 1.2 km length (when using AWG#24 twisted pair). The RS-485 terminating resistor (SW1) must be set to ON for both products at both ends of the line. -
Page 14: Appendix
TBS Installation Manual – 3D FLASH+ Appendix Maintenance Cleaning Prior to disinfection the devices should be cleaned to remove dust or dirt. Use warm water with a few drops of soap or a combined cleaning & disinfection liquid normally used to wash hands. - Page 15 TBS Installation Manual – 3D FLASH+ General HW error. Intrusion detected. Resolve using DeviceConfig under Maintenance / Security / Intrusion Prevention page. Unknown sensor error. Sensor lost from USB interface. Sensor incorrect behaviour - sensor thread stops etc. Wrong sensor configuration. Runtime sensor error.
-
Page 16: Tbs Port Assignments
TBS Installation Manual – 3D FLASH+ TBS port assignments The following table lists all TCP/UDP ports that are used in TBS software and firmware as part of the biometric subsystem infrastructure. In case an installation is not going to use all TBS components TBS offers, some of the available services will not be needed, and the respective ports do not have to be open. -
Page 17: References To Other Tbs Documents
TBS Installation Manual – 3D FLASH+ References to other TBS documents TBS 3D FLASH+ Mounting and Installation Guideline Permanent link: https://cloud1.tbs-biometrics.com/index.php/s/i1FHUoF0OSwfTrV The QR code printed on the product opens this link, leading to the 3D FLASH+ product folder from where this manual is available. TechNote ‘TN 3D FLASH+ Getting Started’...
