Thank you for your purchase of the YAMAHA ME2000 memory expansion kit for the DM2000 mixer.
By replacing the original CPU board with this ME2000 expansion board, you will expand your
mixer's automix memory to 7MB—a sevenfold increase that will make your mixer even more versa-
tile and even easier to use.
The ME2000 expansion kit must be installed by an authorized ser-
viceperson. Please contact a local Yamaha dealer or a service
center to arrange for installation. Do not attempt to install the
ME2000 on your own.
Please read through the following precautions carefully before having the serviceperson install this
ME2000 expansion kit. Be sure to retain the manual in a safe place.
Precautions
WARNINGS
Failure to observe the following warnings may lead to fatality or serious injury from fire or
electric shock.
G
Do not attempt to disassemble or modify the
ME2000 board. Do not apply excessive force to
board connectors or other board components.
(Mishandling of the board may lead to shock, fire
hazard, or equipment failure.)
CAUTIONS
Failure to observe the following cautions may lead to injury, or may result in damage to
equipment or other property.
G
Be careful to avoid catching or snagging fingers
while carrying out the installation.
G
When handling the ME2000 board, do not touch
the board's metallic leads (pins). (Pins are sharp
and may cause hand cuts.)
G
The ME2000 board is electrostatic-sensitive.
Before handling the board, you should briefly
touch the main unit's metal casing with your bare
hand so as to drain off any static charge from
your body.
ME2000
Owner's Manual
G
G
G
Be sure to unplug the DM2000 main unit from the
power supply before installing the ME2000 board
(to eliminate shock hazard).
Before starting installation, be sure to save all
important data from the DM2000 unit to an exter-
nal MIDI device. This installation process will
clear all of the unit's user memory and will reset
all settings to their defaults.
Be sure to install the included lithium battery. This
is a backup battery that is required maintain the
data in the DM2000's expanded memory.
1
ME2000

Advertisement

loading

Related Manuals for Yamaha ME2000

Summary of Contents for Yamaha ME2000

  • Page 1 Thank you for your purchase of the YAMAHA ME2000 memory expansion kit for the DM2000 mixer. By replacing the original CPU board with this ME2000 expansion board, you will expand your mixer’s automix memory to 7MB—a sevenfold increase that will make your mixer even more versa- tile and even easier to use.

  • Page 2: Fcc Information (U.s.a.)

    The above statements apply ONLY to those products distributed by Yamaha Corpora- tion of America or its subsidiaries. * This applies only to products distributed by YAMAHA CORPORATION OF AMERICA.
  • Page 3 Yamaha cannot be held responsible for damage caused by improper use or modifications to the device, or data that is lost or destroyed. Please dispose of used batteries in accordance with local regulations. Illustrations in this manual are for explanatory purposes only, and may not match the actual appearance of the product.

  • Page 4: System Software

    Studio Manager: The ME2000 is not compatible with Studio Manager versions prior to V1.1.1. If your version is older than V1.1.1, please replace it by installing the Studio Manager version included on the accompany- ing CD-ROM. For information about how to carry out the installation, refer to Studio Manager’s installation guide.
  • Page 5 ~The following instructions are intended for use by authorized serviceper- sons only.~ This kit is not user-installable. Users should contact a local Yamaha dealer or a service center to arrange for installation by a Yamaha-authorized serviceperson. Detach and Raise the Control Panel When removing each screw, note its location and be sure to return it to the same place when reassem- bling.
  • Page 6 If the MB2000 peak meter bridge is installed on the DM2000, remove it. First disconnect the bridge cable from the METER connector on the DM2000. Then remove the 4 screws holding the bridge in place (as shown below), and remove the bridge. 2 Screws DM2000 METER Connector 2 Screws ME2000...
  • Page 7 Axis Screw <Front View> Hold onto the LCD, and lift up the rear of the control panel. Secure the raised control panel in place, so that it does not fall back down. ME2000 7 Screws Position- ing Screw 10 Screws...
  • Page 8 Remove the 5 screws holding the CPU board in place, and remove the CPU board. Set the ME2000 expansion board into position, and fasten it into place with 5 screws (the 5 screws you removed above, or the 5 screws included in the kit).
