Xtra.CDI Shutdown Transponder
Quick Start Guide
GX-200
FOLLOW THESE STEPS FOR A QUICK
SETUP OF THE XTRA.CDI SHUTDOWN
TRANSPONDER
Before you start
Listed below are the model numbers of the engines currently in production.
De Haardt has verified that this manual is applicable to these models.
If you want to connect the Xtra.CDI Shutdown Transponder to a different
engine model, it is recommended to contact: support@de-haardt.com
GX-200
RDG4
RHES
RHG4
RHQ4
Safety notice
All products are designed as supplement to make karting safer, but cannot replace safe track procedures.
If equipment fails, the normal operating procedure must still be adequate to safely operate the track.
Visit www.de-haardt.com for more information about the Xtra.CDI Shutdown Transponder and products.
For technical issues or questions about the Xtra.CDI Shutdown Transponder.
contact: support@de-haardt.com.
Advertisement
Table of Contents
Related Manuals for De Haardt GX-200
Summary of Contents for De Haardt GX-200
- Page 1 Before you start Listed below are the model numbers of the engines currently in production. De Haardt has verified that this manual is applicable to these models. If you want to connect the Xtra.CDI Shutdown Transponder to a different engine model, it is recommended to contact: support@de-haardt.com...
- Page 2 M5 bolts and lock-nuts. This ensures optimum radio sensitivity. Connecting the engine The recommended way to power the transponder can be derived from the model number of the engine using the figure below GX-200 RHG4 RDG4 RHES RHQ4 Proceed to...
- Page 3 Powering the Xtra.CDI Shutdown Transponder from the ignition coil Take the ‘SUPPLY’ cable with the two wires ends and combine the blue wire with the blue wire of the ‘ENGINE+BRAKE’ cable. Combine brown ‘SUPPLY’ wire with the brown ‘ENGINE+BRAKE’ wire. Usage of the yellow/green wire is not needed for the setup of the Xtra.CDI Shutdown Transponder, leave the wire hanging.
- Page 4 Powering the Xtra.CDI Shutdown Transponder using a power coil Connect the two wires from the factory installed power coil with the ‘SUPPLY’ cable with the two wire ends of the Xtra.CDI Shutdown Transponder using cable terminals. Even though polarity does not apply here, it is recommended to color match the wires whenever possible.
- Page 5 Connecting the Xtra.CDI Shutdown Transponder to the engine Connect the three wired ‘ENGINE+BRAKE’ cable from the Xtra.CDI Shutdown Transponder to the engine. blue wire (1) to the chassis of the engine, and connect Connect the wires (2) with the two black wires from the engine. the two brown GX200 with power coil...
- Page 6 Set the kart number with the Xtra.Remote Control Before setting the kart number make sure other karts in the area are turned off. Turn on the Xtra.Remote Control by pressing the button. Press the button to enter the configuration menu and enter the default PINcode ‘0000’.
