- Page 1 XTRA.CDI SHUTDOWN TRANSPONDER User Manual Article No. 200.480 Document version: Date: 2022-09-06...
- Page 2 Email: info@de-haardt.com All rights reserved. Safety All De Haardt’s products are designed as supplement to make karting safer, but cannot replace safe track procedures. If equipment fails, the normal operating procedure must still be adequate to safely operate the track.
-
Page 3: Table Of Contents
Xtra.CDI Shutdown Transponder User Manual Table of Contents GET STARTED ..........................4 ........................... 4 RODUCT OVERVIEW ............................. 6 NSTALLATION 1.2.1 Mounting ............................6 1.2.2 Connector pinout ..........................7 1.2.3 Engine connections ......................... 7 1.2.4 Network port ..........................10 CONFIGURATION ........................11 ) ............ -
Page 4: Get Started
Transponder. Every functionality the Xtra.CDI Shutdown Transponder offers will be explained. The Xtra.CDI Shutdown Transponder is used to limit the maximum speed of a go-kart with a combustion engine to increase the safety on and around a karting track. The Xtra.CDI Shutdown Transponder is controlled wireless with different De Haardt products. - Page 5 Xtra.CDI Shutdown Transponder User Manual Xtra.Cable Harness CDI Transponder (optional) Figure 2: Xtra.Cable Harness CDI Transponder The Xtra.Cable Harness CDI Transponder is not included by default. It needs to be ordered separately. v1.0...
-
Page 6: Installation
Xtra.CDI Shutdown Transponder User Manual 1.2 Installation The Xtra.CDI Shutdown Transponder communicates wireless with the Xtra.Remote Control and the Xtra.Black Box. For an optimal wireless coverage the location is very important and must be chosen carefully! 1.2.1 Mounting Transponder is to be fitted on a flat surface with three countersunk M5 bolts and lock-nuts. -
Page 7: Connector Pinout
User Manual 1.2.2 Connector pinout The Xtra.CDI Shutdown Transponder features a connector to make the connections with the engine. Each connector pin must make the correct connection to ensure the Xtra.CDI Shutdown Transponder functions properly. See Table 1. Pin number... - Page 8 Xtra.CDI Shutdown Transponder User Manual 1.2.3.1 Electrical connection for conventional engines Figure 3 shows how the Xtra.CDI Shutdown Transponder must be connected to a conventional engine. The following Honda engines are supported and tested. Conventional engines GX120 GX160 GX200 Figure 3: Connecting conventional engine...
- Page 9 1.2.3.2 Electrical connection for CDI engine When the Xtra.CDI Shutdown Transponder is connected to a CDI engine the connections can vary depending on the kind of power supply. This being: a battery or a power coil. Figure 4 shows how an engine with a battery is connected and Figure 5 shows how an engine with a power/charge coil is connected.
-
Page 10: Network Port
Xtra.CDI Shutdown Transponder User Manual 1.2.4 Network port Other De Haardt devices can be connected to the network port of the Xtra.CDI Shutdown Transponder. Figure 6: Xtra.CDI Shutdown Transponder network port WARNING! Always put the protection cap on the Xtra.CDI Shutdown Transponder’s network port when this port is not used! Be sure that the protection cap is fully covering all outside metal parts of the network port connector. -
Page 11: Configuration
User Manual 2 Configuration To use the Xtra.CDI Shutdown Transponder with its full potential, it needs to be configured to the needs of the end user. Configuring the Xtra.CDI Shutdown Transponder is done using the Xtra.Remote Control. See the manual of the Xtra.Remote Control for instructions on configuring the Xtra.CDI Shutdown Transponder. -
Page 12: Technical Specifications
Xtra.CDI Shutdown Transponder User Manual 3 Technical specifications This chapter describes the technical specifications of the Xtra.CDI Shutdown Transponder. 3.1 Specification overview Description Min Typical Max Unit Operational temperature °C Operation voltage* Input current** Radio Range safety band*** Radio frequency 1... -
Page 13: Support
Xtra.CDI Shutdown Transponder User Manual 4 Support For support, one can contact the support department of De Haardt by email: support@de- haardt.com v1.0...
