S-4002 TKF MODEL TACKER SEWER MACHINE PARTS AND SERVICE MANUAL MACHINE SERIAL No: 97.2441.2.001 PART NUMBER 02 / 2022...
Page 3
However, the satisfaction and goodwill of our customers are of pri- mary concern to AMF Reece, Inc. In the event that a warranty matter is not handled to your satisfaction, please contact AMF Reece office: AMF Reece - Cars s.r.o.
S-4002 TKF A - INTRODUCTION 1. BASIC INFORMATION ............................. 1-1 2. SAFETY DEVICE AND LABELS ........................1-2 3. GENERAL MACHINE PARTS DESCRIPTIONS .................... 1-3 4. TECHNICAL CONDITIONS ..........................1-4 5. INSTRUCTIONS FOR OPERATOR SAFETY AND MAINTENANCE ............1-5 6. SPECIAL ACCESSORIES ..........................1-6 B - MACHINE INSTALLATION 1.
Page 6
S-4002 TKF 9. MACHINE HEAD CLAMP-FEET ADJUSTMENT ..................1-36 9.1. Clamp Height Adjustment .......................... 1-36 9.2. Adjustment of the Distance Between the Clamp-Feet ................1-36 10. CHANGING THE DRIVE BELT ........................1-37 11. STEPPER - MOTORS HOME POSITION ADJUSTMENT ................1-38 11.1.
A - INTRODUCTION 1. BASIC INFORMATION The sewing machine S-4002 TKF is designed and produced to be very reliable. Important design goals have been to provide a safe machine that is simple and inexpensive to maintain. The patented rotary needle bar shaft drive, a major benefit, delivers longer needle bar life. The added benefits of lower vibration and less noise, translate into less operator fatigue.
Page 8
S-4002 TKF A - INTRODUCTION 2. SAFETY DEVICE AND LABELS S 4002 TKF YEAR OF PRODUCTION VOLTAGE POWER OUTPUT CURRENT AMF REECE, a.s. CZECH REPUBLIC Warning Air pressure regulator Covers removed, possible injury Manometer with pressure sensor Warning when opening cover eyes injury danger Label TÜV SÜD...
S-4002 TKF A - INTRODUCTION 3. GENERAL MACHINE PARTS DESCRIPTIONS Eye guard Control panel Stand Table top Foot pedal Main Switch Halogen lamp Button Control box Emergency Stop Button Machine head Released: 11/2020 E-mail: info@amfreece-cars.cz...
S-4002 TKF A - INTRODUCTION 5. INSTRUCTIONS FOR OPERATOR SAFETY AND MAINTENANCE When installing the machine we recommend the minimum clearances noted above around the machine. Read all of the instructions that follow. DO NOT PUT THE MACHINE INTO OPERATION UNTIL YOU ARE COMPLETELY FAMILIAR WITH ALL INSTALLATION AND OPERATING INSTRUCTIONS.
S-4002 TKF A - INTRODUCTION 6. SPECIAL ACCESSORIES - machine device, which is not included in the standard equipment of the machine and a customer can order it Needles 750 SC 80/12, 70/10 • the manufacturer recommends to use these needles when sewing the thin materials •...
S-4002 TKF B - MACHINE INSTALLATION 1. CONTENT OF THE SHIPPING BOX 1. The shipment contains one box. 2. There is a carton with accessories, service manual with parts section and thread stand in the box. 3. During unpacking the shipment, follow the labels which are on a cover.
S-4002 TKF B - MACHINE INSTALLATION 3. POWER AND AIR CONNECTION 1. The machine is equipped with a hand valve . If a customer needs to use a quick coupler , he must order connector A variety of connectors can be used separately or in combination to adapt to the available input supply hose.
S-4002 TKF C - CORRECT USAGE 1. POWER UP / HOME POSITION 1. Turn the main power switch on by turning clockwise to the I position. 2. The machine is ready for operation when the control panel display lights, the Ready message appears on the display.
S-4002 TKF C - CORRECT USAGE 2. NEEDLE INSTALLATION WARNING! Before performing this adjustment, switch the main machine power off to prevent accidental starting of the machine. Disconnect the air supply and dissipate any stored energy. Use needles ordering number 02.0750.2.110 (750SC 90/14) only - see accessories.
S-4002 TKF C - CORRECT USAGE 3. THREADING WARNING! Switch the main machine power off to prevent accidental starting of the machine. Disconnect the air supply and dissipate any stored energy. When threading, see the pictures below. Change the thread tension by nut according to the sewing conditions.
S-4002 TKF D - MACHINE CONTROLS 1. PROCESS OF SEWING 1. Bring the machine to the home position according to the section C1. 2. Be certain that the machine is threaded correctly according to the section C3 and insert the work under the clamp feet.
S-4002 TKF D - MACHINE CONTROLS 2. OPERATOR CONTROL PANEL PUSH BUTTONS AND SWITCHES Machine status / error number signalization. Press the button to switch to the Error Explanation Screen Tack program number selection / indication. Tack name. Daily counter signalization. Press the button to switch to the Counter Screen.
Page 21
S-4002 TKF D - MACHINE CONTROLS By pressing the button you switch to the Counter Screen: tack Total counter of sewn on the machine tack Daily counter Daily counter counting direction (ascending or descending) Daily counter reset Released: 02/2022 1-15...
S-4002 TKF D - MACHINE CONTROLS 3. TACK PARAMETERS SCREEN Tack program number selection / indication Tack name Initial slow sewing speed Number of stitches being sewn at initial slow sewing speed Sewing speed Number of stitches of the first sewn bar tack...
S-4002 TKF D - MACHINE CONTROLS 5. SERVICE MENU Switch to Program Copy Screen (refer to Chapter D5.2) Switch to Software Information Screen (refer to Chapter D5.3) Password Entering (refer to Chapter D5.1) Tack Switch to Step-by-Step Sewing Screen (refer to Chapter D5.4) Switch to Machine Parameters Screen (refer to Chapter D5.5)
S-4002 TKF D - MACHINE CONTROLS 5.1. Password Submitting Screen tack tack All the parameters are protected by the password of level II. Consequently, the parameters can be viewed but cannot be changed. Level II password is requested for the change.
S-4002 TKF D - MACHINE CONTROLS 5.2. Program Copy Screen tack Copying of a program 5.3. Software Information Screen Software version numbers 5.4. Tack Step-by-Step Sewing Screen tack Activation of step-by-step sewing mode Proceed to next stitch Released: 02/2022 1-20...
S-4002 TKF D - MACHINE CONTROLS 5.5. Machine Parameters Screen Language selection Mechanical bite adjustment – this value must be set according to the adjusted mechanical bite of the sewing head Foot-pedal control setting – sewing start sewing starts when...
S-4002 TKF D - MACHINE CONTROLS 5.6. Sensors Test Screen 5.7. Valves Test Screen 5.8. Y - Motors Adjustment Screen Axis home position sensor Axis current position Axis movement test Axis home position establishment Axis home position electronic correction Axis Y row...
S-4002 TKF D - MACHINE CONTROLS 5.9. Sewing Motor Adjustment Screen Sewing motor movement test Sewing motor home position establishment Sewing motor home position electronic correction Sewing motor home position sensor status Sewing motor continual run Sewing motor enable / disable...
S-4002 TKF D - MACHINE CONTROLS 5.10. Automatic Home Position (only for service mechanics) This machine is equipped with automatic home position of stepper motor axes. tacks This operation is factory set to 200 Master reset (factory set) Machine cycling (testing, running - in)
S-4002 TKF E - STANDARD MACHINE ADJUSTMENT 1. MACHINE HOME POSITION 1. The needle bar is in the upper position. The needle descends to the right side of the throat plate slot during the first stitch. 2. MACHINE ADJUSTMENT BASICS 1.
S-4002 TKF E - STANDARD MACHINE ADJUSTMENT 3. NEEDLE BAR 3.1. Needle Bar Crank Position Turn the hand wheel until the mark is at 12 o‘clock. The needle bar need to be in the top position. If the needle bar is...
S-4002 TKF E - STANDARD MACHINE ADJUSTMENT 4. BITE Before the bite adjustment, remove the pulley cover and the head cover 4.1. Bite Cam Adjustment 1. Check if the machine is in the home position. 2. Tilt the machine on the table .
S-4002 TKF E - STANDARD MACHINE ADJUSTMENT 4.2. Bite Width Adjustment To adjust the bite width, first remove the head cover. The S-4002 is fitted with a regular bite throat plate , that allows a bite range of 1.5 mm (1/16“) to 2.3 mm (3-32“).
S-4002 TKF E - STANDARD MACHINE ADJUSTMENT 5. LOOPER ADJUSTMENT Before making the loopers adjustment, follow the below described points: 1. Turn the hand wheel and observe the position of the connecting link at both ends of the looper link arm travel .
Page 36
S-4002 TKF E - STANDARD MACHINE ADJUSTMENT The first looper adjustment 1. Bring the machine to the home position and loosen the screws of the looper cam adjust the looper cam to the lowest position. 2. Loosen the looper set screw...
Page 37
S-4002 TKF E - STANDARD MACHINE ADJUSTMENT The second looper adjustment 10. Insert the second looper on the looper shaft. 11. Loosen the looper holder screw and move the holder so that the needle passes the center of the looper recess. There must be clearance 0,4 mm between the needle and the looper recess.
S-4002 TKF E - STANDARD MACHINE ADJUSTMENT 6. THREAD DRAW-OFF 6.1. Adjustment of the Draw-Off Lever Position The correct adjustment ensures a long enough thread tail for starting the sewing of the next tack. Remove the covers because this mechanism adjustment is performed in the rear of the head. Air supply is necessary for this adjustment.
S-4002 TKF E - STANDARD MACHINE ADJUSTMENT 7. THREAD TENSION The thread tension influences the appearance of the tack. A thread tension change may be needed if the thread and fabric change. Check to be certain all parts, which contact the thread, are smooth and polished with no burrs or sharp edges.
S-4002 TKF E - STANDARD MACHINE ADJUSTMENT 7.2. The Correct Position of the Tension Mechanism 1. Remove the tension assembly from the shaft 2. Check if the distance between the stud slot edge and the pin is 3.5 mm If incorrect, it is necessary to adjust the position on the pin.
S-4002 TKF E - STANDARD MACHINE ADJUSTMENT 8. THREAD TRIMMING Trimming mechanism ensures the correct thread trimming after sewing the last stitch. The trimming hook moves in the direction of arrow, both thread loop legs A and B are pulled forward.
S-4002 TKF E - STANDARD MACHINE ADJUSTMENT 9. MACHINE HEAD CLAMP FOOT ADJUSTMENT 9.1. Clamp Height Adjustment Make sure the air-supply is switched on and the clamp foot are in up position. If the clamp foot are not in up position, push the button from the machine touch-screen panel.
S-4002 TKF E - STANDARD MACHINE ADJUSTMENT 10. CHANGING THE DRIVE BELT 1. Remove the pulley cover after loosing the M4 screws 2. By turning the handwheel adjust the position of the shaft so that the screw on the pulley...
S-4002 TKF E - STANDARD MACHINE ADJUSTMENT 11. STEPPER - MOTORS HOME POSITION ADJUSTMENT 11.1. Bedplate Y-Axis 1. Remove the cover-plate. 2. Press Y-axis home button – now check that the bedplate front inner edge is in one line with the throat- plate front edge as per the picture –...
S-4002 TKF E - STANDARD MACHINE ADJUSTMENT 11.3. Sewing-Motor Home Position Adjustment 1. Check the distance of the sensor from the machine case edge to be 22 mm – refer to the picture below. For adjustment loosen the screw ; maintain the distance 0.3 – 0.5 mm between the sensor and ring 2.
S-4002 TKF F - MAINTENANCE Warning: • Check for damage to electrical cables • Check safety covers for damage and replace if needed immediately • Keep your hands out of the sewing area • Do not modify the machine in any way, which could eliminate safety parts •...
Page 47
S-4002 TKF F - MAINTENANCE 6. Remove the filter cover with cleaning pad . Remove the dust from the cleaning pad or in case of considerable dirt, wash it using a mild detergent. Perform the same cleaning on the rear fan.
S-4002 TKF F - MAINTENANCE 2. PERIODIC MAINTENANCE once a day (8 hours of operation) - cleaning of the sewing mechanism area and inner frame of the machine - lubrication of mechanisms - see section G4. once a week (40 hours of operation)
S-4002 TKF F - MAINTENANCE 4. MACHINE LUBRICATION 1. It is necessary to lubricate the places shown below before the machine is switched on for the first time or after a long idle period. Use oil ESSO TERESSO 32 or similar quality.
Page 50
S-4002 TKF F - MAINTENANCE 5. Tilt the machine head on the rest pin and lubricate the places shown in the picture. looper shafts looper cam surfaces bite cam surfaces Tilt the sewing head back into the sewing position. 6. After lubrication it is important to sew minimum 10 tacks on scrap fabric to dispel any excess oil. Wipe all visible excess oil from the mechanism in the work area.
S-4002 TKF F - MAINTENANCE 5. MACHINE DISPOSAL 1. To ensure machine ecological disposal, it is necessary to remove nonmetallic parts from the machine. To take these parts out, it is necessary to perform the partial dismantling of the machine, remove covers, dismantle the machine arm and remove the frame.
Page 55
S-4002 TKF TROUBLESHOOTING 1. MECHANICAL FAULTS..........................2. ELECTRICAL FAULTS..........................3. ERROR MESSAGES OF THE CONTROL PANEL................... 4. ERROR MESSAGES OF THE SERVO....................5. MOTOR INTERFACE..........................Revised: 02/2022 E-mail: info@amfreece-cars.cz...
Page 56
S-4002 TKF TROUBLESHOOTING 1. MECHANICAL FAULTS FAULT POSSIBLE CAUSE PROBABLE SOLUTION Thread breakage Needle, looper, throat plate damaged Change damaged parts Incorrect needle and sewing Check the adjustment of the mechanism adjustment mechanisms Thread tension is too tight Adjust correct tension Incorrect threading See section C3 for checking.
Page 57
S-4002 TKF TROUBLESHOOTING FAULT POSSIBLE CAUSE PROBABLE SOLUTION Thread not Trimming knife damaged Replace knife Trimmed at the Wrong adjustment of pulling hook See section E8 end of the cycle Throttle valve regulating tension disc is See section E7 too loose.
Page 58
Call support or replace servodriver U10 part number 06.8024.0.605 Switch the machine off for 5 minutes Error in sewing motor circuit then turn it back on. If fails, call AMF Reece service. Sewing doesn’t stat Make sure the machine is ready for...
Page 59
S-4002 TKF TROUBLESHOOTING FAULT POSSIBLE CAUSE PROBABLE SOLUTION Machine is sewing with Connector is not connected properly Check the connector X4 connection no pneumatic response. to the slot X4 Check the G1 DC powerline for PLC error. correct voltage value and PLC indication LEDs.
Page 60
S-4002 TKF TROUBLESHOOTING 3. ERROR MESSAGES OF THE CONTROL PANEL Error Nr. DESCRIPTION Error 01 Machine is not in home position. Press home button to bring the machine to the home position. Error 04 Low air pressure. Air pressure is bellow 4.0 bar. Check the air supply.
Page 61
The following messages can be seen on the servo, which is placed inside the control box. In order to eliminate these messages, switch off the machine for 1 minute. Then switch the machine on again. The error message should not appear on the display. If the message appears - call AMF Reece service. PWR - Power supply indication:...
Page 62
S-4002 TKF TROUBLESHOOTING Alarm Alarm reset Error detection function Detection details and cause of error code possible Power supply The DC voltage of the main circuit fell beloww the specificed value while undervoltage the RUN Command Input was ON Overvoltage The DC voltage of the main circuit is abnormally high Overcurrent flowed to the IGBT.
Page 63
S-4002 TKF TROUBLESHOOTING 5. MOTOR INTERFACE The following interface is in between the PLC and individual motor drivers: Axis indexer Y spare Spare Axis indexer X spare PLC controll Axis Y Axis X option Needle drive Revised: 02/2022 E-mail: info@amfreece-cars.cz...
Page 65
S-4002 TKF TABLE OF CONTENTS NEEDLE BAR ........................3-2 CLAMPING ......................... . 3-4 THREAD TRIMMER ......................3-6 FEED MECHANISM ......................3-8 LOOPER MECHANISM ......................3-10 BITE MECHANISM ......................3-12 BASE ..........................3-14 BEDPLATE TOP ........................3-16 BEDPLATE BOTTOM ......................3-18 HEAD ..........................
S-4002 TKF EXTRA PARTS Revised: 02/2022 3-42 E-mail: info@amfreece-cars.cz...
Page 107
S-4002 TKF EXTRA PARTS PART NUMBER DESCRIPTION QTY. 03.5524.0.032 CLAMPING BITE 1,5-2 mm 08.6000.6.025 SCREW M6-25 24.3218.0.000 CLAMP ARM 24.3219.0.000 DISTANCE 22.3251.0.000 BRACEKT ASSEMBLY 24.3217.0.000 CLAMP FOOT-NAROW BITE 24.3215.0.000 CLAMPING MAT - NAROW BITE 08.6800.4.000 WASHER 4,1 08.6200.4.006 SCREW M4-6 24.3306.0.000...
Page 109
S-4002 TKF INDEX PART NUMBER PAGE DET PART NUMBER PAGE DET PART NUMBER PAGE DET 22979047 3-41 06.8800.0.001 3-29 08.6002.5.008 3-27 27513603 3-25 07.6045.0.037 08.6002.5.022 01.1125.0.000 07.6045.0.037 3-21 08.6002.6.012 01.1382.0.000 3-11 07.6045.0.053 3-23 08.6012.4.010 3-15 01.1397.0.000 3-11 07.6321.0.025 3-13 08.6032.4.008 3-35 01.2084.0.000 3-17...
Page 110
S-4002 TKF INDEX PART NUMBER PAGE DET PART NUMBER PAGE DET PART NUMBER PAGE DET 08.6700.5.000 3-21 08.6852.5.000 3-37 12.0010.3.080 3-23 08.6700.5.000 3-13 08.6852.8.000 3-31 12.0010.3.099 3-39 08.6700.8.000 3-11 08.6962.4.025 3-29 12.0010.3.105 3-39 08.6700.8.000 3-29 12.0008.3.023 3-27 12.0010.3.106 3-39 08.6702.0.000 3-29 12.0008.3.023...
Page 111
S-4002 TKF INDEX PART NUMBER PAGE DET PART NUMBER PAGE DET PART NUMBER PAGE DET 12.8000.1.061 3-25 22.0100.0.000 3-11 24.0001.0.000 12.8000.1.083 3-15 22.0100.0.000 3-13 24.0002.0.000 15.4410.0.400 3-19 22.0104.0.000 3-27 24.0002.0.000 3-19 15.6005.0.990 3-29 22.0105.0.000 3-11 24.0009.0.000 3-23 17.0011.1.149 3-19 22.0108.0.000 3-27 24.0010.0.000...
Page 112
S-4002 TKF INDEX PART NUMBER PAGE DET PART NUMBER PAGE DET PART NUMBER PAGE DET 24.0178.0.000 24.0181.0.000 24.0184.1.000 24.0185.0.000 24.0188.0.000 3-11 24.0189.0.000 3-11 24.0190.0.000 3-11 24.0191.0.000 3-15 24.0192.0.000 3-19 24.0193.0.000 3-19 24.0197.0.000 3-11 24.0198.0.000 3-35 24.0408.0.000 24.0500.0.000 24.0510.0.000 24.0546.0.000 24.1000.0.000 3-19 24.1430.1.000 3-23...
