Summary of Contents for Sencore AFN Series
- Page 1 AFN Platform Encoders / Decoders / Multiplexers / Turn-Around Devices User Manual February 2024 www.sencore.com | +1.605.978.4600 Revision 5.0...
-
Page 2: Table Of Contents
AFN Platform – User Manual Table of Contents Table of Contents Notices Trademark Acknowledgments Publication Disclaimer Copyright Safety Instructions Electric Shock Hazard Important Safety Instructions WARNING: Installation Site Installation Requirements Equipment Placement AC Power Circuit Overload General Servicing Precautions Electrostatic Discharge Understanding AFN AFN-1000 Chassis AFN-250 Hardware... - Page 3 AFN Platform – User Manual Inputs - ASI Inputs - KLV Source Outputs Page Decoded Outputs UHD Single-Channel Mode Decode IP Outputs ASI Outputs Output Service Configuration and PID Remapping System Page Latency and GOP AFN Link Guide Terminology: Things to be aware of: Setup Example: Turn Around Mode SRT Guide...
-
Page 4: Notices
All trademarks shown in this manual are trademarks of their respective owners. Publication Disclaimer Sencore assumes no responsibility for errors or omissions that may appear in this publication. We reserve the right to change this publication at any time without notice. This document is not... -
Page 5: Important Safety Instructions
AFN Platform – User Manual Important Safety Instructions ● Read these instructions. ● Keep these instructions. ● Heed all warnings. ● Follow all instructions. ● Do not use this apparatus near water. ● Clean only with dry cloth. ● Do not block any ventilation openings. ●... -
Page 6: Equipment Placement
AFN Platform – User Manual Equipment Placement ● Make sure the mounting surface or rack is stable and can support the size and weight of this equipment. ● The mounting surface or rack should be appropriately anchored according to manufacturer's specifications. Ensure this equipment is securely fastened to the mounting surface or rack where necessary to protect against damage due to any disturbance and subsequent fall. -
Page 7: General Servicing Precautions
AFN Platform – User Manual General Servicing Precautions WARNING: Avoid electric shock! Opening or removing this equipment's cover may expose you to dangerous voltages. Be aware of the following general precautions and guidelines: ● Wristwatch and Jewelry - For personal safety and to avoid damage of this equipment during service and repair, do not wear electrically conducting objects such as a wristwatch or jewelry. -
Page 8: Understanding Afn
AFN Platform – User Manual Understanding AFN AFN-1000 Chassis The AFN-1000 chassis is designed to have eight (8) modular cards that make up the back panel along with two (2) power input modules and (2) power supplies that can be accessed through the removable front panel. -
Page 9: Carrier Options
If an active carrier needs to be removed or a carrier needs to be returned to Sencore for upgrade or repair, a blank carrier can be inserted so that the chassis can remain functional. -
Page 10: Getting Started
AFN Platform – User Manual Getting Started Plugging in Power To supply power, plug in standard IEC power cables to the power input modules on the rear panel. It is highly recommended to utilize both power inputs. Accessing the User Interface Networking configurations can be retrieved and changed via front panel. -
Page 11: Inputs Page
AFN Platform – User Manual Inputs Page Clicking the blue icon at the top left of the user interface brings up the inputs page. This page allows the configuration of all the input settings. Depending on the hardware configuration there may be multiple input options that need to be configured. -
Page 12: Input Service Configuration
AFN Platform – User Manual Input Service Configuration For baseband inputs that need to be encoded the configurations are changed by clicking the Edit buttons. Input ● Name - sets the name of the service ● Startup - turns the encoder engine ON and OFF ●... -
Page 13: Gop Structure
AFN Platform – User Manual GOP Structure ● Gop Type - Set to 1, 2, or 3 (1-IP, 2-IBP, 3-IBBP) ● GOP Length - Set the number of frames between I frames Audio Settings ● Mode - Encode, Passthru, and OFF (Only 2 Passthru allowed per service) ●... -
Page 14: Inputs - Asi
AFN Platform – User Manual If the parameters are configured correctly and the incoming TSoIP is available, the service will show up on the input page: More information on configuring IP Inputs can be found in the AFN Link and SRT Guide section of the manual. - Page 15 AFN Platform – User Manual For KLV inputs, click the Add KLV Source button and a configuration window will pop up. KLV PID is assigned by the user. Rate is the space (bps) allocated for the KLV PID. Address and Port must match the multicast information from the KLV transmitter. KLV can only be mapped to outputs on the same slot/card.
-
Page 16: Outputs Page
AFN Platform – User Manual Outputs Page Clicking the yellow icon at the top left of the user interface brings up the outputs page. This page allows configuration of all the output baseband and transport stream settings. Depending on the hardware configuration, there may be multiple output options that can be configured. -
Page 17: Uhd Single-Channel Mode Decode
AFN Platform – User Manual UHD Single-Channel Mode Decode For 4K applications that use a single Video PID the Decoder must be set to Single Mode: In single channel mode the 4 SDI outputs will be independent and not mirrored pairs. IP Outputs Multiple IP outputs can be created, configured, and deleted from this page: No more than 210 Mb/s and/or 20 transport streams is recommended for reliable delivery. -
Page 18: Asi Outputs
AFN Platform – User Manual ASI Outputs 4 ASI outputs can be created, configured, and deleted from this page: The maximum bandwidth of the 4 ASI outputs is 210Mb/s. Mirrored outputs do not allocate any bandwidth. Page 18 (36) -
Page 19: Output Service Configuration And Pid Remapping
AFN Platform – User Manual Output Service Configuration and PID Remapping By clicking the Edit button to the left of the Service bar the user can access the Service Configuration tab. This allows the user to set configurations independent to every output. Page 19 (36) -
Page 20: System Page
AFN Platform – User Manual System Page Clicking the green icon at the top left of the user interface brings up the system page. This page allows configuring all the host system settings. Under the Network tab, the network information can be configured for the host carrier and any other SHC0100-0100’s installed in the chassis. -
Page 21: Latency And Gop
AFN Platform – User Manual Latency and GOP ● GOP Type has a direct correlation with Latency performance ● GOP Type options are 1 - IP frames, 2 - IBP frames, and 3 - IBBP frames ● For optimal latency performance GOP type should be set to 1 ●... -
Page 22: Afn Link Guide
AFN Platform – User Manual AFN Link Guide Terminology: ● AFN Link refers to the ability for an AFN Platform to accept a Transport Stream (TS) via TSoIP input and multiplex the incoming service(s) with other TSoIP inputs and the native service(s) that are being encoded by the AFN Video Encoder cards. -
Page 23: Setup Example
AFN Platform – User Manual Setup Example: Link a pair of 8 channel AFN chassis to create a transport stream with 16 services on ASI. ● User sets the output for the Upstream AFN ○ In this example it is 8 services with a mux rate of 85 Mb/s ●... - Page 24 AFN Platform – User Manual ● Available services will be displayed. ● These Network Input services will be available and are preceded by [Net]. ● The Services can be added to the mux to create a 16 channel MPTS. Page 24 (36)
- Page 25 AFN Platform – User Manual Page 25 (36)
-
Page 26: Turn Around Mode
AFN Platform – User Manual Turn Around Mode When AFN is configured for network inputs, they can be turned around to assigned outputs. Turn Around Mode is configured under the Edit Output button on the output pages. When Turn Around Mode is turned ON the user can select what input is to be passed along to the output. Turn Around Mode will just pass TS Mux Rate, Tables, and TSID information. -
Page 27: Srt Guide
AFN Platform – User Manual SRT Guide Terminology: ● Secure Reliable Transport - SRT is an open-source video transport protocol and technology stack that optimizes streaming performance across unpredictable networks with secure streams and easy firewall traversal, bringing the best quality live video over the worst networks. - Page 28 AFN Platform – User Manual devices on the same fast switch on a LAN, the RTT should be almost 0. Within the Continental US, RTT over the Internet can vary depending on the link and distance but can be in the 60 to 100 ms range. Transoceanic RTT can be 60-200 ms depending on the route.
- Page 29 AFN Platform – User Manual will require exchanging more control packets, as well as resending media packets, and therefore a higher percentage value. ○ **SRT Bandwidth Overhead should not exceed 50% ● Sample Bandwidth Overhead Calculation – As an example, the streaming video is at a bit rate of 1000 kbps and audio at 128 kbps.
-
Page 30: Configuring An Srt Stream
AFN Platform – User Manual Configuring an SRT Stream With the source and destination devices set up (including having established call modes and any firewall settings), follow these steps to configure an SRT stream: 1. Measure the Round Trip Time (RTT) using the ping command. If the RTT is <= 20 ms, then use 20 ms for the RTT value. -
Page 31: Caller Example
AFN Platform – User Manual Caller Example: Page 31 (36) -
Page 32: Listener Example
AFN Platform – User Manual Listener Example: When the Listener successfully receives the media the SRT Rx Stats will populate: SRT Stats This section describes the various parameters that have an effect on an SRT stream’s performance. ● Status: Connected or Disconnected ●... -
Page 33: Caller Specific Stats
AFN Platform – User Manual ● Send/Receive Rate: Rate of connection in Mbps Caller specific Stats ● Buffer Avail.: The amount of buffer not being utilized by the connection ● Flow Window: Number of packets transmitted per ● Send Loss: Packets lost by the caller ●... -
Page 34: Biss-Ca
AFN Platform – User Manual BISS-CA The AFN platform supports BISS-CA encryption. The configurations are located on the outputs page under the Encryption tab. Any output slot can be configured for independent BISS-CA settings. Under the Add Session button the user configures: BISS-CA is a modern stream protection system that uses rolling keys to prevent unauthorized access to the stream. - Page 35 AFN Platform – User Manual When BISS-CA is configured correctly the CA Keys will be listed: Page 35 (36)
-
Page 36: Biss-Ca (Cont.)
AFN Platform – User Manual BISS-CA (cont.) The Encryption can be added to outputs by clicking the Edit button next to the service to open the Service Configuration window: Receiver Each IP or ASI input can support BISS-CA decryption as a receiver. A receiver is factory configured with a private key called the Buried Key.
