DRAWER PULLOUT
TOOLS REQUIRED:
#2
ESTIMATED ASSEMBLY TIME:
15 MIN
CARE AND MAINTENANCE:
Clean with a damp cloth and
wipe parts dry.
WATCH TUTORIALS OF OUR
PRODUCTS BEING INSTALLED
WWW.REV-A-SHELF.COM/VIDEOS
Parts List
No.
Description
A
Wood Drawer
B
Slide Set
C
#8 X 3/4" Pan Head Screws
A.
B.
INSTALLATION INSTRUCTIONS: DRAWER PULLOUT
12400 Earl Jones Way
Louisville, KY 40299
rev-a-shelf.com
Customer Service: 800-626-1126
Qty
1
1
4
C.
I-4WDBSC-0423
